Color Menu

This menu provides precise control of the color settings including:
color temperature (preset & user define) and gamma.
Changing settings procedure (using either the Projector Control Panel or the Remote
Controller):
1.Press the MENU button to display OSD
menu.
2.Press the or button to select
COLOR menu.
3.To enter the sub-menu setting, press the
button or the MENU button.
4.Press the or button to select the
sub-menu item.
5.Press the or button to adjust the value of desired sub-menu item.
On the Color Temp and Gamma sub-menus, press the
the desired setting.
6.After you have done with the adjustment of a sub-menu item:
a.To resume changing another sub-menu item: press the
b.To exit from the current menu: toggle the MENU button.
The following table provides detail of the available sub-menu choices:
Sub-Menu Option
Color Temp
L(Low)
M(Middle)
H(High)
U(User)
User
Gamma
Gamma1
Gamma2
Note:
The color adjustment on the User setting can only be made if the Color Temp selection
is "User".
Description
Adjusts the whiteness of the screen.
Gives the white colors a red tint.
Gives the white colors a neutral tint.
Gives the white colors a blue tint.
Selects customized color temperature.
Manually adjusts color temperature.
Selects a gamma correction curve.
Improves computer's image mode.
Improves video's image mode.
Projector
User's Manual
or button to select
or button.
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
EN-21
