Maytag Amana AE123G35AX Use And Care Manual

Room air conditioner & heat pump

Hide thumbs

Table of Contents

Quick Links

Download this manual

Contents

Introduction .................................................................. 1

Safety Information ....................................................... 1

Unpacking .................................................................... 2

Electrical Requirements .............................................. 2

Installation ................................................................... 3

Room Heat Pumps ....................................................... 3

Normal Care & Maintenance ...................................... 3

Installation Requirements ........................................... 5

Installation Instructions ............................................... 8

General Instructions .................................................. 13

Through-The-Wall Installation Instructions ............. 14

Operating Controls .................................................... 17

Before Calling Service .............................................. 19

When Service Is Required ........................................ 19

Any Questions? .......................................................... 19

Warranty ..................................................................... 20

Introduction

Room air conditioners cool, dehumidify, and filter air inside

your home. Heat pump and electric heat models offer both

heating and cooling. Opening sections of manual provide

general information for all room air conditioner models.

Operating Controls section describes operation of controls

for each model. After reading the opening sections, turn to

Operating Controls section and find the panel layout that

matches the model of your unit.

Read entire manual thoroughly before beginning installation

and operation of your new room air conditioner. Be sure you

have all necessary tools and materials on hand for the job.

Study illustrations to familiarize yourself with important

details of the installation process. Review manual for oper-

ating instructions.

NOTE

1. Mechanical experience is required to install air condi-

tioner.

2. Installation can take from 1 to 3 hours, depending on

installer's knowledge and skill.

3. If you encounter problems during installation, call our

consumer information line toll-free at 1-877-376-0214. If

your problem cannot be resolved by phone, contact an

authorized Amana

brand servicer. Contact and service

will be at your expense.

IO-371B

Effective: September 2013

is a registered trademark of Maytag Corporation or its related companies

Room Air Conditioner & Heat Pump

Use and Care Manual

Safety Information

Be sure electrical service is adequate for chosen model of air

conditioner. Complete electrical rating for unit is found on

serial plate located behind front grille. Electrical outlet must

be close enough to unit for power cord to reach without strain.

Air conditioner should be the only appliance on individual

circuit.

For personal safety and to avoid possible damage to appli-

ance or home, observe all safety instructions highlighted by

symbol shown below.

RECOGNIZE THIS SYMBOL AS A

SAFETY PRECAUTION.

After installing unit, reread instructions to ensure each step

is complete and that all parts are fastened in place. For best

results and to minimize installation time, perform all proce-

dures in the order shown.

WARNING

HIGH VOLTAGE

Disconnect ALL power before

servicing or installing this unit.

Multiple power sources may be

present. Failure to do so may cause

property damage, personal injury,

or death.

Table of Contents

Need help?

Do you have a question about the Amana AE123G35AX and is the answer not in the manual?

Questions and answers

Summary of Contents for Maytag Amana AE123G35AX

Page 1: Table Of Contents
IO-371B is a registered trademark of Maytag Corporation or its related companies ©2010 , 2013 Goodman Company, L.P. Effective: September 2013 and is used under license to Goodman Company, L.P., Houston, TX. All rights reserved.
Page 2: Unpacking
OWNER'S PRODUCT IDENTIFICATION WARNING MODEL NUMBER SERIAL NUMBER MANUFACTURING NUMBER Owner's Name WARNING Address City State Date of Purchase Authorized Dealer WARNING Address City State HIGH TEMPERATURE STRESS HAZARD This room air conditioner is not meant to provide Phone Number unattended cooling or life support for persons or animals that are unable to react to failure of the WARNING...
Page 3: Installation
• Unit with a window mounting kit Unit Plug Receptacle Circuit Rating, Voltage Type Required Breaker, Time Rating On These models are designed for mounting though an Delay Fuse Nameplate opening in a wall. These units can be adapted to window installation by using the optional window mount- NEMA No.
Page 4 Note: The life of your unit may be greatly reduced if you live Air Filter Cleaning in a salt air or other corrosive type environment. Under these A dirty air filter reduces operating efficiency of unit. Filter conditions, the unit should be removed from its case and should be inspected at least once every week during opera- tion.
Page 5: Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions: Plug into a grounded 3 prong outlet. Do not use an extension cord. Do not remove ground prong. Unplug air conditioner before servicing.
Page 6 Window installation Electrical Requirements Window opening measurements: WARNING ■ 27" min. to 39" max. (68.6 cm to 99 cm) opening width. ■ 16¹⁄₄" min. (41.3 cm) opening height. A. 27" min. (68.6 cm) ¹⁄₄ B. 16 " min. (41.3 cm) Ground wire must be connected to ground screw located in lower right corner of air conditioner when air conditioner is in cabinet.
Page 7 WARNING Recommended grounding method This air conditioner must be grounded. This air conditioner is equipped with a power supply cord having a grounded 3 prong plug. To minimize possible shock hazard, the cord must be plugged into a mating, grounded 3 prong outlet, grounded in accordance with all local codes and ordinances.
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Unpacking Remove front panel by removing 2 Phillips screws on bottom left and right WARNING side of front. Remove shipping screws (2). Pull on handle to slide air condition out of cabinet. Place air conditioner on cardboard. 6. Remove any packing foam from inside of unit. Remove packaging materials.
Page 9 Attach Side Curtains Attach foam adhesive seal 1. Locate provided bag of screws. Attach foam adhesive seal along the bottom of the curtain bottom channel. 2. Insert top and then bottom of right-hand curtain housing in top and bottom curtain guides on air conditioner cabinet. Back View A.
Page 10 4. Use a ³⁄₁₆" drill bit to drill 3 st arter holes 1/2" deep through the 2. Insert one of the #10 x ³⁄₄" round-head screws through 3 holes in the cabinet and into the windowsill. hole and into lower window sash. Insert one of the #10 x ³⁄₄"...
Page 11 Option 1 —Wood, metal or plastic molding ■ Use 1" (2.5 cm) or thicker lumber for wood frame. When you are using wood, metal or plastic molding, the wood frame should line up with inside wall as shown. A. Outside width B.
Page 12 Complete Installation NOTE: Handle air conditioner gently. Attach bottom front of panel with front panel screws. WARNING Insert air conditioner into cabinet. NOTE: For through-the-wall installations, install molding around the room side of the air conditioner, if needed. WARNING A. Make sure the free end of the ground wire is outside of the cabinet.
Page 13: General Instructions
General Operating Instructions While operation of all units is similar, controls vary slightly Drain Cup Installation and Use from model to model. Operating Controls section shows Your air conditioner uses a system where the water removed control panel of unit purchased and gives detailed information from the indoor air (condensate) is channeled to the outdoor about operation of controls.
Page 14: Through-The-Wall Installation Instructions
Chassis and front cover must be re- moved from outer case for installation. Air Conditioner Dimensions (with chassis installed) is a registered trademark of Maytag Corporation or its related companies and is used under license to Goodman Company, L.P., Houston, TX. All rights reserved.
Page 15 Brick Veneer or Frame Wall Construction. CAUTION See CAUTION under General Instructions. Cut or build In order to reinstall the chassis and re- rough opening large enough to allow a framed, finished attach the air conditioner front cover, the opening 15 9/16-inches high and 22 13/16-inches wide. installed outercase must be square and When case is properly positioned in opening, secure it to level from side to side.
Page 16 Installation in Wall Thicker Than 5 ½ inches Outercase must project The side louvers in outer case provide ventilation to air a minimum ¾" beyond inside wall conditioner compressor and fan motor and must not be or molding to attach front frame blocked.
Page 17: Operating Controls
Operating Controls Controls Power Pad (Button) Operating your air conditioner properly helps you to obtain the best possible results. Turns air conditioner on and off. When turned on, the display will show the room temperature. This section explains proper air conditioner operation. IMPORTANT: Display •...
Page 18 How to set: Energy Saver Mode Press the DELAY 1-24 hr pad on the unit or the Controls the fan. on the remote control. Each touch of the INCREASE ON - The fan will cycle on and off with the compressor. / DECREASE pads on the unit or the INCREASE (+) / This results in wider variations of room temperature...
Page 19: Before Calling Service
BEFORE CALLING SERVICE WARNING The following is a list of problems that are sometimes encountered when using a room air conditioner. Possible cause and suggested remedies are given for each problem. If the problem cannot be fixed using the suggested remedies, see WHEN SERVICE IS REQUIRED section. PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY...
