NOTE:
The internal modem uses the
COM2 port in the system.
NOTE:
To hang up the modem, type
ATH0 and press Enter.
: 3
(cont.)
+,7( $3(5
.
.
.

Creating a Command Mode Icon

.
.
To create a command mode icon using HyperTerminal:
.
1. Click Start==>Programs==>Accessories ==> HyperTerminal.

.
.
2. Double-click the Hypertrm.exe icon.

.
.
The Connection Description dialog box is displayed.
.
.
3. Type Command in the Name option.

.
. 4. Click OK.

.
The Phone Number dialog box is displayed.
.
.
5. Click Connect Using==>Direct to Com 2.

.
.
6. Click OK.

.
.
The Modem Port Settings dialog box displayed.
.
7. Click OK.
.

.
The command mode screen is displayed with a blinking cursor in the upper-left corner.
.
Commands can now be sent to the modem, and the modem responds with a result code.
.
.
8. Click File, then Save to save the session.

.
.
9. Click File, then Exit to quit.

.
.
A command mode icon is displayed in the HyperTerminal dialog box.
.
.
.

Setting S Register Default Values

.
.
The S register default values function reliably under most circumstances. However, these values
.
may be modified if necessary.
.
.
For example, it may take an especially long time to get a dial tone in your office, so you may
.
choose to reset S7 for a longer wait time.
.
.
.

Modifying an S Register

.
.
You can modify or change the value of an S register from Command Mode (Terminal Mode) or
.
from a standard data or fax communication application. For example:
.
.
N
Type ATS11=70 then press Enter.

.
.
This sets S11 to a value of 70.
.
. N
If you then enter AT = 95. it resets S11 to a value of 95, since the modem remembered that

.
S11 was the last register referenced.
.
N
.
If you enter an S = command with no parameter (value), the register number defaults to zero

.
and the modem changes the value of S0. Therefore, the following commands are equivalent:
.
ATS0 = 3 and ATS = 3.
.
.
.
.
.
.
.
