Installation and user guide
Wine IN25/IN25X
INFORMATION STATED
ON THE NAMEPLATE OF THE APPLIANCE
:
o Model : ......................................
o Serial N° : ................................
o Date of purchase : ..............................
IMPORTANT :
It is recommended to note the serial number
here above.
It will be necessary for ordering
03.2021
spare parts and for warranty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wine IN25 and is the answer not in the manual?

Questions and answers

Related Manuals for WINEMASTER Wine IN25

Summary of Contents for WINEMASTER Wine IN25

  • Page 1 Installation and user guide Wine IN25/IN25X INFORMATION STATED ON THE NAMEPLATE OF THE APPLIANCE o Model : ……………………………….. o Serial N° : ………………………….. o Date of purchase : ………………………... IMPORTANT : It is recommended to note the serial number here above.

  • Page 2: Table Of Contents

    ® ........15 3.1. Connecting the air conditioner WINE IN25 ..........15 3.2. Plugging in the wine conditioning unit WINE IN25 ........15 3.2.1. Temperature setting of the air conditioner WINE IN25 ......15 3.3. Standby mode ..................16 3.4.
  • Page 3 From conception to commercialisation, everything has been implemented to offer an exclusive and high quality product. Brainchild of a team who find in this a motivation to ever give satisfy you, we hope that your wine conditioning unit WINEMASTER ®...
  • Page 4 If the thermal safety functions to often, there is a risk for the compressor to be damaged. In all cases, it must be avoid that the outside temperature remains at 35°C, this high temperature should be limited to the summer period. Technical drawing USER MANUAL WINE IN25 Page 5...

  • Page 5: Cellar Equipment

    : 1 m per elbow Radius elbow ≥ 175 mm Do not reduced the duct size View 1. EVACUATED AIR 2. AIR INLET 3. WINE CELLAR 4. EVACUATION ROOM OR HAUSE OUTSIDE 20°C 35°C USER MANUAL WINE IN25 Page 6...

  • Page 6: Cellar Insulation

    The circulation of air allows maintaining the pre-selected temperature throughout the cellar. Cellar insulation 1.2. Insulation is essential for efficient functioning of the WINEMASTER ® . A good insulation enables to maintain a stable temperature and humidity level. The chart on the next page will allow you to...

  • Page 7: Insulation Of Walls, Ceiling And Floor

    The floor of the cellar must be able to support the shelves and the stored wine. Thus, it’s necessary to choose insulation with adequate compression strength. Improve the load capacity of the insulation (particularly under the shelve legs) by using : USER MANUAL WINE IN25 Page 8...

  • Page 8: The Door

    Avoid placing a wine cabinet or freezer who generates heat in the cellar. The central heating pipes should be re-isolated during their passage through the cellar. 2. INSTALLATION OF WINE CONDITIONING UNIT WINEMASTER ® THE UNIT HAS TO BE INSTALLED RESPECTING THE NATIONAL RULES OF ELECTRIC INTALLATIONS.
  • Page 9 View OUTSIDE WALL INSULATED WALL GRID INSULATED DUCT WINE CONDITIONING UNIT INSULTED DOOR Necessary material (not delivered) Material included in the box USER MANUAL WINE IN25 Page 10...

  • Page 10: Brackets Installation

    Drill the holes wall - Allow 400 mm distance above the brackets and 100 mm on each side - Leave 300 mm space under the brackets in order having enough access to replace the filter USER MANUAL WINE IN25 Page 11...

  • Page 11: Installing The Wine Conditioning Unit

    - Drill 2 holes of 155 mm - Put the 2 grid casing DETAIL OF GRID ASSEMBLING : BLOWING SUCTION ATTENTION! Each module consists of two grids (blowing and suction). Care must be taken to adapt the type of grid. USER MANUAL WINE IN25 Page 12...
  • Page 12 - Fit the elbow or the sleeve on the air - Put together the differents elements with the muff conditioner nozzle - Place the clamp and tight Sleeve and elbow PE Suction nozzle Reduction aspiration Frame Blowing nozzle soufflage Grid Telescopic muff Reduction USER MANUAL WINE IN25 Page 13...

  • Page 13: Examples

    If the power cable is damaged, it must be replaced by the manufacturer, its after sale service or qualified persons in order to avoid any danger. Installing the water drainage system 2.4. 1. DRAIN PIPE 2. STICKER CLIP 3. POWER CABLE 4. BRACKET USER MANUAL WINE IN25 Page 14...

  • Page 14: Using The Wine Conditioning Unit Winemaster

    - If the cellar temperature≤ to the thermostat setting: the fan doesn’t start. Only the ventilator works. The power outlet must be accessible after installation. Plugging in the wine conditioning unit WINE IN25 3.2. 3.2.1. Temperature setting of the air conditioner WINE IN25...

  • Page 15: Standby Mode

    The program of the thermostat will run an automatic defrost time several times a day. During this operation, the compressor is stopped, only the fan is functioning at low speed. The condensate water pro- duced during this period will be evacuated through the tube drain. USER MANUAL WINE IN25 Page 16...

  • Page 16: Maintenance Of The Air Conditioner Winemaster

    4. MAINTENANCE OF THE AIR CONDITIONER WINEMASTER ® Replacing the filter 4.1.  Remove the 2 black plastic screws under the air  Remove the cover  Pull the tab to release the filter  Replace with a FONDIS filter exclusively ...

  • Page 17: Warranty

    In case of electric failure, WINEMSTER reserves the right to send an expert technician to inspect the ap- pliance before replacing any defective parts. In case of refrigeration failure, WINEMASTER may require that the appliance is returned to the factory for repair. Any interventions will take place according to the guidelines set in the “after sale service “document.
