M-system M8BS2-164 Instruction Manual page 2

TERMINAL CONNECTIONS
Connect the unit as in the diagrams below.
■ EXTERNAL DIMENSIONS unit: mm (inch)
• M8BS2-164-M2
5–M3 POWER
TERMINALS
AC POWER UNIT
• M8BS2-164-R
3–M3.5 POWER
TERMINALS
8.6 (.34)
7.2 (.28)
16–M3.5
OUTPUT TERMINALS
CH1
+ − + − + − + − + − + − + − + −
1 2 3 4 5
1
2
3
4
5
A B A B A B A B A B A B A B A B
C D C D C D C D C D C D C D C D
CH1
CT PROTECTOR (CTR) *
7.3 (.29)
32–M3.5 INPUT TERMINALS
*1. Included with M8CTx.
7.2 (.28)
16–M3.5
OUTPUT TERMINALS
CH1
+ – + – + – + – + – + – + – + –
1 2 3
1 2 3 4 5 6
A B A B A B A B A B A B A B A B
C D C D C D C D C D C D C D C D
CH1
CT PROTECTOR (CTR) *
7.3 (.29)
32–M3.5 INPUT TERMINALS
*1. Included with M8CTx.
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
480 (18.90)
460 (18.11)
440 (17.32)
7.3 (.29)
32–M3.5
OUTPUT TERMINALS
CH8 CH1 CH8
+ − + − + − + − + − + − + − + −
+ − + − + − + − + − + − + − + −
6 7 8 9 10 11 12 13 14 15
CH8
1
480 (18.90)
460 (18.11)
440 (17.32)
7.3 (.29)
32–M3.5
OUTPUT TERMINALS
CH8 CH1 CH8
+ – + – + – + – + – + – + – + –
+ – + – + – + – + – + – + – + –
7 8 9 10 11 12 13 14 15 16
CH8
1
M8BS2-164
OUTPUT 2 TERM.
OUTPUT 1 TERM.
16
OUTPUT 2 TERM.
POWER LED
OUTPUT 1 TERM.
EM-5495-4 Rev.4 P. 2 / 3
