FrontLoad Bill Validator Series - Operation and Service Manual
The FrontLoad bill validator consists of six main modules. Each module is available in different
variations, to suit your needs. The picture below illustrates the different modules.
Memory Card (for software update)
Validating Head
Bezel (CashCode Standard Bezel is shown)
Housing (for 600 Cassette
with Lock Bracket is shown)
Power Interface Module
Cassette (600 bills cassette is shown)
PAGE 1-5
Rev. 03-2004 Part 1. Operation Manual
