- Page 1 ST33 Series Bill Validators Operation Manual © 1998-2000 CashCode Co. Inc. PT# MAN-ST33 Rev.C 01/00...
-
Page 2: Table Of Contents
5. Banknote Jam ..... ..…………………………………………………………….. 6. Maintenance ....…...……………………………………...………………………. 7. Mounting ....……………..………………………………...……………………… 9. Input And Output Circuitry ………..…………………………………..……………...…… 10. Harness Connection ……..……………………………………..…………….………….. 10 11. Connector Pinout …………………………………………………………………..……. 11 12. DIP Switch Settings…………………………………………………………..………….. 12 ©1998-2000 CashCode Co. Inc Page 2/2 PT# MAN-ST33 Rev.C 01/00... -
Page 3: Overview
5 The Bill Validator stacks accepted banknotes into a high security lockable and removable cassette (LRC). The S ecurity Lock design of the Cassette guarantees reliable protection against unauthorised access to its contents. C assete Lock (optional) ©1998-2000 CashCode Co. Inc Page 3/3 PT# MAN-ST33 Rev.C 01/00... -
Page 4: Main Parts
P ow er & Iso la ted B ox C atch P ulse Inte rface C on nector C a sh C od e In te rfa ce ® C o n n e cto r ©1998-2000 CashCode Co. Inc Page 4/4 PT# MAN-ST33 Rev.C 01/00... -
Page 5: Precautions
Bill Validator until the axis is free. 3. Take the Cassette off the Bill Validator by moving it out along the slots in the Bill Validator. ©1998-2000 CashCode Co. Inc Page 5/5 PT# MAN-ST33 Rev.C 01/00... -
Page 6: Banknote Jam
DO NOT USE STRONG THINNERS LIKE ACETONE OR GASOLINE AS IT MAY CAUSE DAMAGE TO PLASTIC PARTS OF THE BILL VALIDATOR. ©1998-2000 CashCode Co. Inc Page 6/6 PT# MAN-ST33 Rev.C 01/00... -
Page 7: Mounting
The figure «Layout Of Mounting Holes» shows the template for panel of the external equipment where the Bill Validator is to be mounted. All the dimensions are in millimetres and inches (in parenthesis). ©1998-2000 CashCode Co. Inc Page 7/7 PT# MAN-ST33 Rev.C 01/00... -
Page 8: Input And Output Circuitry
P ulse O utp ut 2 (B lu e) The additional non-isolated TTL-level CREDIT PULSE output has exactly the same circuitry as ® output circuitry of the CashCode Serial Interface (see unit 8.2) ©1998-2000 CashCode Co. Inc Page 8/8 PT# MAN-ST33 Rev.C 01/00... - Page 9 + 2 0V D C m a x O utput C P U O u t Io l= 2m A ...10 0m A + 5 vD C LED Pow er Source 2 00 o hm ©1998-2000 CashCode Co. Inc Page 9/9 PT# MAN-ST33 Rev.C 01/00...
-
Page 10: Harness Connection
A M P 1 0 2 6 8 1 -4 & A M P 1 0 2 5 3 6 -7 . W ire Ju m p e r, p in 1 - p in 4 ©1998-2000 CashCode Co. Inc Page 10/10 PT# MAN-ST33 Rev.C 01/00... -
Page 11: Connector Pinout
Not connected ----------- Out of Service Output Not connected ----------- Accept Enable Input LED Power Source Output Send Input Not connected ----------- Not connected ----------- Not connected ----------- Not connected ----------- ©1998-2000 CashCode Co. Inc Page 11/11 PT# MAN-ST33 Rev.C 01/00... -
Page 12: Dip Switch Settings
S W 2 O P E N Each switch is assigned to control the settings shown below. * This is an example only - please check your USER MANUAL for your model. ©1998-2000 CashCode Co. Inc Page 12/12 PT# MAN-ST33 Rev.C 01/00...
