Table of contents Safety precautions 4 Service & Support 23 Symbols used............ 4 General safety precautions........ 4 Appliance-specific safety precautions .... 5 Appliance installation .......... 7 Instructions for use.......... 7 Using for the first time 10 Appliance description 10 Construction ............ 10 Cooking space............. 10 Operating and display elements....... 11 Accessories ............ 12...
Safety precautions Symbols used General safety precautions Unauthorized repairs could result in unforeseen dangers for the user, for which the manufacturer cannot ac- ▪ Read the operating instruc- cept liability. Repairs should only be tions before using the appli- undertaken by an authorized ser- vice technician, otherwise any sub- ance for the first time.
1 Safety precautions ently installed electrical install- lishments; by guests in hotels, ation in accordance with the motels and other accommod- installation regulations. ation establishments; in bed ▪ If the mains cable of this ap- and breakfast establishments. pliance is damaged, it must ▪...
Page 6
1 Safety precautions ▪ WARNING: Children should ▪ The contents of feeding only use the appliance in a bottles and baby food jars combined operating mode must be stirred or shaken (depending on model) under and the temperature must be adult supervision due to the checked before consumption temperatures generated.
1 Safety precautions ▪ If the appliance is installed any other the cooking space and the way, the results will also vary with the adjacent parts, see the «Care changed power output. and maintenance» section. ▪ The appliance is equipped with a con- nection cable which must be connected Appliance installation to an on-site junction box.
Page 8
1 Safety precautions ▪ The appliance corresponds to recog- Caution: Risk of burns! nized technology standards and the rel- ▪ The appliance gets very hot when in evant safety regulations. Proper use of use. The appliance door also gets hot. the appliance is essential to avoid dam- ▪...
Page 9
1 Safety precautions Caution: Risk of injury! ▪ Be careful not to put fingers in the door hinges, as there is otherwise a risk of injury if the appliance door is moved. Particular care should be taken when children are around. ▪...
Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective film from out of the cooking space. ▸ Clean the cooking space and the accessories. ▸...
3 Appliance description Operating and display elements Function buttons Microwave functions Operating time, timer, clock Decrease value (power level, operating time, weight, clock) Increase/Decrease value with slider Increase value (power level, operating time, weight, clock) Cancel, switch off, pause, childproof lock Start, quick start Display elements Defrost...
4 Operation Accessories Incorrect handling can cause damage! Do not use knives or cutting wheels on the accessories. Do not use any metal accessories in the microwave mode. Glass turntable with roller ring ▪ Serves as base for the microwave mode. ▪...
4 Operation Using the appliance functions Microwave Programmes: Defrost meat and Defrost bread, with weight entered in kg Follow the following steps to set the power level (setting range 100—900 W, Touch 2× for Defrost meat (d-01) or selectable in 100 W steps) and operat- touch 3×...
5 Microwave operation Microwave operation Do not use any metal accessories in the microwave mode. Power range 100—900 W (selectable in 100 W steps) Recommended value 500 W / 2 mins Accessory Glass turntable Foods and liquids are heated using microwaves. Uses ▪...
6 More applications Forbidden for microwave mode ▪ Cast iron pots ▪ Metal cookware ▪ Aluminium foil ▪ Baking trays ▪ Cookware with gold rim or metal decor ▪ Meat thermometer Tips for microwave mode Put the food in the cooking space before switching on the microwave. ▸...
6 More applications Timer The timer functions like an egg timer. It can only be set when the microwave is not in use. Setting and starting the timer ▸ Touch the button 1×. – The 00:00 display element appears in the display. ▸...
7 Care and maintenance Care and maintenance Risk of burns from hot surfaces! Allow the appliance and accessories to cool down before cleaning. The appliance may not be used if the appliance door or door de- tection is damaged. Inspect these parts regularly. Only use soft cloths for cleaning.
8 Trouble-shooting Replacing the illumination For safety reasons, the illumination must be replaced by our Customer Services. Trouble-shooting Resolving problems Problem Possible cause Solution ▪ Appliance is not ▪ A household fuse or circuit ▸ Change the fuse. working breaker has tripped. ▸...
9 Technical data Technical data External dimensions ▸ See installation instructions Electrical connection ▸ See identification plate 1 Disposal 10.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way.
Index Accessories ............12 Notes ..............21 Cleaning ............ 17 Appliance Disposal............ 19 Operating elements ......... 11 Appliance door Operation............12 Cleaning ............ 17 Appliance installation ......... 7 Power failure ............. 18 Power interruption..........18 Before using for the first time ......7 Queries ..............
Page 23
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
Page 24
Applicable power level (W) and weight (kg) selection Value selection for functions: clock, operating time and programme number selection 1155424-01 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
