Midi - Wampler METAVERSE Full User Manual

LOADING A PRESET (FRONT PANEL)
To load a Preset using the front panel Preset Switch:
1. Press the front panel switch to load the next Preset
2. Subsequent presses will cycle through 8 user-settable Presets,
indicated by the Preset LEDs
LOADING A PRESET (MIDI)
To load a Preset via MIDI PC Message:
1. Send a PC message (0-127) via the MIDI Input jack
2. The Preset associated with the received PC message will be
loaded
Note: the Preset LEDs will show ON OFF OFF ON, which
indicates that a Preset in the 8-127 range has been loaded via a
MIDI PC message
PERFORMING A FACTORY RESET
To perform a Factory Reset
1. Power off the device, press and hold the Bypass Switch, Tap
Tempo Switch, and Preset Switch, and power the device on.
2. After power up, releases the switches. The device will start a
factory reset.
3. When LEDs blink, the factory reset is complete.
Note: the factory reset will:
• Reset all Presets to default Presets
• Reset Alt controls to default values
• Reset expression pedal configuration to default values (set to
control mix)
• Reset MIDI Channel to Omni mode
WAMPLER METAVERSE

MIDI

The METAVERSE offers complete control over every Program
via either MIDI CC Messages or PC Commands. It can accept a
Global Clock signal from a MIDI controller
MIDI CONNECTOR SPEC.
The METAVERSE communicates with TRS type A cables
(Tip = 5, Ring = 4, Sleeve = 2)
MIDI CHANNEL
By default the pedal is set to 'Omni Channel' mode which means
it will accept a MIDI command on any MIDI channel. To set the
MIDI Channel the device will receive commands on:
1. Power off the device, press and hold the Preset Switch, and
power the device on
2. After power up, releases the Preset Switch
3. The current MIDI Channel will be displayed on the Preset
LEDs which will correspond with the numbers 1-16 (No LEDs
on is Channel 1)
4. Press the Preset Switch to increment through the channel
options (all blinking is omni mode)
5. Press and hold the Preset Switch for 1 second to save the
MIDI Channel setting
0000 = channel 1 0001 = channel 2
0011 = channel 4 0100 = channel 5
0110 = channel 7 0111 = channel 8
1001 = channel 10 1010 = channel 11
1100 = channel 13 1101 = channel 14
1111 = channel 16
All four sweeping = omni
0010 = channel 3
0101 = channel 6
1000 = channel 9
1011 = channel 12
1110 = channel 15
Page 9
