Midi Pc Messages; Midi Realtime Messages - Wampler METAVERSE Full User Manual

MIDI PC MESSAGES

Patch Change (PC) messages can be used to recall Presets
(Patches) stored on the METAVERSE.
PC Function PC Number Description
Load a Preset 0-127 Loads Preset of matching PC number
When in Preset-write mode, sending a PC number will save the current
Save a Preset 0-127
settings to that Preset number

MIDI REALTIME MESSAGES

Realtime message can be used for the following functions:
Realtime Message Number Description
Will set the delay time based on received MIDI Clock, multiplied by the
subdivision setting
The delay time can sync with MIDI Clock. When enabled (see CC 99), the MIDI
MIDI Clock 248 Clock input will be multiplied by the current Subdivision setting, and the delay
time will update automatically to the incoming MIDI Clock.
BPM = 60000 / (delay time in ms)
Delay time in ms = 60000 / BPM
Start 250 Sync the tap tempo LED
WAMPLER METAVERSE
SENDING PC MESSAGES FROM DEVICE
When changing Presets with the Preset Switch or Tap Tempo
Switch configured to increment Presets, the device will:
1. Send a PC message matching the loaded Preset number from
the MIDI Out jack
2. This message will be on the same channel as the device
This allows the device to select Presets on other devices in a
rudimentary fashion without the need for a dedicated MIDI con-
troller device
SENDING TAP TEMPO CC MESSAGE FROM DEVICE
When pressing the Tap Tempo Switch while it is configured to
adjust tempo, the device will:
1. Send a CC 81 message value=0 when the tap tempo switch is
pressed
2. Send a CC 81 message value=127 when the tap tempo switch
is released
3. These messages will be on the same channel as the device
This allows the device to link tap tempo on supported devices
without the need for a dedicated MIDI controller device
Page 11
