Grizzly H6155 Parts Breakdown

H6155 Rotary Mini Grinder Parts Breakdown
3
1
7
10
REF PART # DESCRIPTION
1 PH6155001 1/8" COLLET
2 PH6155002 3/32" COLLET
3 PH6155003 COLLET NUT
4 PH6155004 COLLET SHIELD
5 PH6155005 HANGER
6 PH6155006 PLUG AND CORD
7 PH6155007 BRUSH CAP
8 PH6155008 CARBON BRUSH
9 PH6155009 VARIABLE SPEED LEVER
10 PH6155010 COLLET LOCK
11 PH6155011 ARMATURE
-10
-
4
2
8
11
21
21
5
6
9
12
13
20
REF PART #
12 PH6155012 RUBBER CAP
13 PH6155013 WINDING
14 PH6155014 ELECT CONNECTOR
15 PH6155015 CONNECTING WIRE
16 PH6155016 ON/OFF SWITCH
17 PHTEK4
18 PH6155018 STRAIN RELIEF
19 PH6155019 TOP HOUSING
20 PH6155020 BOTTOM HOUSING
21 PHTEK3
Model H6155 Rotary Mini Grinder
14
19
DESCRIPTION
TAP SCREW 10-24 X 3/8"
TAP SCREW #5 X 1/2"
15
16
17
18
