PREPARATIONS > Connecting the radio antennas

Connecting the radio antennas

Connecting the FM antenna

Model For
U.S.A., Canada, Asia, Korea, China, Taiwan, Brazil, General, and Central and South America
Connect the supplied FM antenna to the unit.
Fix the end of the FM antenna to a wall.
The unit (rear)
HDMI OUT
1 2 3
(1 MOVIE) (5 STB) (6 GAME)
eARC/ARC
AUDIO 2 AUDIO 3 AUDIO 4 AUDIO 5 PHONO
(3 MUSIC)
COAXIAL
GND
SPEAKERS
EXTRA SP2
SURROUND BACK
SURROUND CENTER FRONT
/ZONE 2/BI-AMP
Related links
"Connecting the AM antenna" (p.73)
HDMI NETWORK
(4 NET RADIO)
4 5 6 7
(8 SERVER)
ZONE OUT PRE OUT ANTENNA
ZONE 2 FRONT SUBWOOFER
( 2 RADIO )
AM
1
2
EXTRA SP1
F. PRESENCE
/ZONE 2
FM antenna
FM
75
