USER MANUAL NI PCIe-7856 R Series Digital I/O Module for PCI Express, 8 AI, 8 AO, 48 DIO, 1 MS/s AI, Kintex-7 160T FPGA This document provides compliance, pinout, connectivity, mounting, and power information for the PCIe-7856. Hardware Overview The following high-level block diagram represents the PCIe-7856. Figure 1.
Page 5
To connect non-referenced single-ended voltage signals to the PCIe-7856, you must connect the voltage ground signal to AI SENSE in order to keep the common-mode voltage in the specified range. Figure 3. Connecting Non-Referenced Single-Ended Signals to the PCIe-7856 Overvoltage Protection PGIA –...
Figure 7. Connecting to the DIO Channels DIO0 DIO1 Connecter 0 (MIO) DIO14 DIO15 Connection Accessory FPGA DIO0 DIO1 Connecter 1 (DIO) DIO30 Power DIO31 Connection Accessory NI PCIe-7856 1. Low-speed signal frequencies up to 10 MHz with logic levels configured as 1.2 V, 1.5 V, 1.8 V, 2.5 V, or 3.3 V.
Never connect the +5 V power terminals to analog or digital ground or any other voltage source on the NI PCIe-7856 or any other device. Doing so can damage the device and the computer. National Instruments is not liable for damage resulting from such a connection.
