- Page 1 National Instruments PCIe-7856 Manual Get Pricing & Availability at ApexWaves.com Call Today: 1-800-915-6216 Email: sales@apexwaves.com https://www.apexwaves.com/modular-systems/national-instruments/r-series/PCIe-7856...
-
Page 2: Safety Guidelines
NI PCIe-7856 R Series Digital I/O Module for PCI Express, 8 AI, 8 AO, 48 DIO, 1 MS/s AI, Kintex-7 160T FPGA This document describes how to begin using the PCIe-7856. Safety Guidelines Caution Observe all instructions and cautions in the user documentation. Using the model in a manner not specified can damage the model and compromise the built-in safety protection. -
Page 3: Preparing The Environment
Notice The length of all I/O cables must be no longer than 3 m (10 ft). Preparing the Environment Ensure that the environment in which you are using the NI PCIe-7856 meets the following specifications. Note Refer to the device specifications on ni.com/manuals... -
Page 4: Unpacking The Kit
2. NI-RIO Media 3. Getting Started Guide Installing Software on the Host Computer Before using the PCIe-7856, you must install the following application software and device drivers on the host computer. LabVIEW 2018 SP1 or later LabVIEW FPGA Module 2018 or later NI R Series Multifunction RIO Device Drivers January 2019 or later | ©... -
Page 5: Installing The Pcie-7856
Touch any metal part of the computer to discharge any static electricity. Insert the PCIe-7856 into the applicable PCI Express system slot. Gently rock the PCIe-7856 into place. Do not force the device into place. You cannot install PCI Express devices in PCI slots. PCI Express devices support up- plugging into a PCI Express slot of higher lane width. -
Page 6: Verifying Hardware Installation
Verifying Hardware Installation You can verify that the system recognizes the PCIe-7856 by using Measurement & Automation Explorer (MAX). Launch MAX by navigating to Start»All Programs»National Instruments»MAX or by clicking the MAX desktop icon. Expand Devices and Interfaces. Verify that the device appears under Devices and Interfaces. - Page 7 The provided clock source must be stable and glitch-free. Ground connection Supply (+5 V ) 5 V power output connection for external devices No connection The PCIe-7856 is protected from overvoltage and overcurrent conditions. Note Refer to the device specifications, available at ni.com/manuals for more information.
-
Page 8: Where To Go Next
1 866 ASK MYNI (275 6964). For support outside the United States, visit the Worldwide Offices section of ni.com/niglobal access the branch office websites, which provide up-to-date contact information. | © National Instruments | 7 NI PCIe-7856 Getting Started Guide... - Page 9 NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the file on your media, or the National Instruments Patent Notice at . You can find patents.txt ni.com/patents...
