Haier GE WH22X29556 Part Install Instructions

Part Install Instructions
Applicable To The Following Main Board:
WH22X29556
!
IMPORTANT SAFETY NOTICE
The information in this part instruction is intended for use by
individuals possessing adequate backgrounds of electrical,
electronic and mechanical experience. Any attempt to repair a
major appliance may result in personal injury and property damage.
The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in
connection with its use.
Parts Included:
•
Control Board
Overview – Procedure for programming new control boards
when all LED's are flashing.
1. Press Start button. LED's will stop flashing and the personality ID can be selected.
▪ Models with seven segment display will show the personality ID number in the display.
▪ Models without seven segment display will show the personality ID number on the
status LED's using binary coding. (See binary chart on reverse side)
2. Press and release the Start button to increment to the next personality ID number.
▪ The first personality may be "0" and all cycle status LED's will be off.
▪ When the end of the ID list is reached the control will wrap around to the beginning of
the personality ID number list.
3. Press and hold the Start button for three seconds when the correct personality ID number
is in the display or if the correct status LED's are lit for the personality ID number needed.
▪ This will save the personality ID number and the control will go to an idle state.
NOTE: If an error is made programming the control or the LED's are not flashing, enter Field
Service Mode as shown on the last page of these instructions. Use service mode test 17 to enter
the correct personality.
•
Instruction Sheet
!
WARNING
To avoid personal injury, disconnect power before servicing this
appliance. If electrical power is required for diagnosis or test
purposes, disconnect the power immediately after performing the
necessary checks. RECONNECT ALL GROUNDING DEVICES If
grounding wires, screws, straps, clips, nuts, or washers used to
complete a path to ground are removed for service, they must be
returned to their original position and properly fastened.
1
WH00X29557
