Grizzly G8292 Parts List

Model G8292 Magnetic Switch
10
11
1
REF PART # DESCRIPTION
1 P4668001 SWITCH BOX
2 P4668002 SWITCH BOX COVER ASSEMBLY
2-1 P4668002-1 DATA LABEL, HNFB-18
3 P8292003 CONTACTOR TECO CN-18 110V
4 P4668004 FIELD SWITCH
5 P8292005 RELAY TECO RHN-18 23-32A
COPYRIGHT © JANUARY, 2008 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE
REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
Parts
5
9
REF PART #
6
7
8
9
10
11
#CR10363 PRINTED IN TAIWAN
3
4
8
7
6
2
DESCRIPTION
P4668006 CONTACTOR RETAINER
PS38M PHLP HD SCR M4-.7 X 10
P4571008 CAPTURED GROUND SCR M4-.7 X 10
PS10 PHLP HD SCR 10-24 X 1-1/2
P4571010 LIQUID-TITE STRAIN RELIEF
P4571011 RUBBER SEAL
2-1
