Summary of Contents for Tannoy DIMENSION TD10
- Page 1 DIMENSION TD10 SERVICE MANUAL...
- Page 2 Technical Manual Contents • Introduction – The Technical Manual explained Page 2 • Technical Specs – Specifications relating to this particular item. Page 3 • Instructions – For faultfinding, assembly & disassembly. Page 4 • Spares Drawing – All spare parts available to order for your loudspeaker as well as additional spares including the likes of spikes &...
- Page 3 Technical Manual Explained This Manual is designed to help you and your customers. In this manual you will find all information you will need regarding service to your Tannoy loudspeaker including technical specs, instructions for assembly, disassembly & faultfinding, spares drawings & parts lists as well as a detailed explanation of how to go about returning parts under warranty.
-
Page 4: Specifications
Specifications TD10 PERFORMANCE Recommended amplifier power 50 - 200 Watts RMS Continuous power handling 130 Watts RMS Sensitivity (2.83Volts @ 1 metre) 91dB Nominal impedance 6 Ohms Frequency response 38Hz - 54kHz -6dB usable output to 100kHz DRIVE UNITS Dual Concentric™ high frequency 25mm (1.00") 50-micron aluminium dome with Tulip WaveGuide™... -
Page 5: Fault Finding
Fault Finding Tannoy loudspeakers are designed and manufactured to be reliable. When a fault occurs in a hi-fi system the effect is always heard through the loudspeakers although they may not be the source of the fault. It is important to trace the cause of the problem as accurately as possible. - Page 6 Page 5...
- Page 7 TD 10 RE-WORK Tools Required: 3mm Hex Key, and 4mm Hex Key Procedure: Un-pack the product. Remove front velvet panel, (Tee-bar through socket aperture Fig 1,2). Remove driver and disconnect wires. Remove trim ring and unscrew T/P panel – (should be able to locate loose screws Re-attach crossover to centre brace –...
- Page 8 Method: 1. You - Fill in the complete product failure details on to the attached Field Failure Report template, including product serial number, and then fax or e-mail to Tannoy Service Department. Fax: +44 (0) 1236 428230 or E-mail: service@tannoy.com 2.
- Page 9 Customer Complaint / Fault Report Internal Use Only: Warranty Decision: Source Area: Report No: Customer Section: Product Description: Part Number: Date: Customer / Distributor: 20-Digit Product Barcode Number (MANDATORY): Detailed description of problem/ fault (MANDATORY): Insert pictures below: Please be aware that we cannot accept field-failure reports that do not have mandatory sections completed.
- Page 10 FOR GUIDANCE Diagnosis of low frequency driver failures resulting from misuse:- SYMPTOM PROBABLE CAUSE Charred voice coil Under powered amplifier clipping; Excessive peak amplifier power; DC at amp output (amp failure) Under powered amplifier clipping; Excessive peak amplifier power; Excessive low frequency equalisation applied F u s e d , b r o k e n o r b l a c k e n e d l e a d o u t w i r e s Excessive peak amplifier power;...
- Page 11 - Quote you a Returns Authorization Number and send you an Export Returns Authorization Form, by fax or e-mail. 3. Y - Fill in all the relevant details in the form and send it to Tannoy, before arranging shipment. 4. W –...
-
Page 12: Warranty Policy
If you suspect a problem with your loudspeakers then in the first instance discuss it with your Tannoy Dealer. The Dealer has the expertise and experience to help you troubleshoot the system and assess the situation. - Page 13 NOTES Page 12...
- Page 14 NOTES Page 13...
