INSTALLATION INSTRUCTIONS
30" (76.2 CM) FRONT CONTROL GAS
INSTRUCTIONS D'INSTALLATION DES
CUISINIÈRES À COMMANDES FRONTALES
Table of Contents
RANGE SAFETY .............................................................................2
INSTALLATION REQUIREMENTS .................................................4
Tools and Parts .............................................................................4
Location Requirements ................................................................4
Electrical Requirements ...............................................................6
Gas Supply Requirements ...........................................................6
INSTALLATION INSTRUCTIONS ...................................................8
Unpack Range..............................................................................8
Install Anti-Tip Bracket .................................................................8
Adjust Leveling Legs ....................................................................9
Level Range ..................................................................................9
Make Gas Connection ...............................................................10
Verify Anti-Tip Bracket Is Installed and Engaged ......................11
Electronic Ignition System .........................................................11
Remove/Replace Drawer ...........................................................12
Oven Door ..................................................................................12
Complete Installation .................................................................12
GAS CONVERSIONS ....................................................................13
Propane Gas Conversion ...........................................................13
Natural Gas Conversion .............................................................16
Adjust Flame Height ...................................................................19
IMPORTANT:
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
IMPORTANT :
Installateur : Remettre les instructions d'installation au propriétaire.
Propriétaire : Conserver les instructions d'installation pour référence ultérieure.
W11124015A
RANGES
DE 30" (76,2 CM)
Table des matières
SÉCURITÉ DE LA CUISINIÈRE ...................................................21
EXIGENCES D'INSTALLATION ...................................................23
Outils et pièces ...........................................................................23
Exigences d'emplacement .........................................................23
Spécifications électriques ..........................................................25
Spécifications de l'alimentation en gaz .....................................25
INSTRUCTIONS D'INSTALLATION .............................................27
Déballage de la cuisinière ..........................................................27
Installation de la bride antibasculement ....................................27
Réglage des pieds de nivellement .............................................28
Réglage de l'aplomb de la cuisinière .........................................29
Raccordement au gaz ................................................................29
Vérifier que la bride antibasculement
est bien installée et engagée .....................................................30
Système d'allumage électronique..............................................30
Dépose et réinstallation du tiroir ................................................31
Porte du four ..............................................................................31
Achever l'installation ..................................................................32
CONVERSIONS POUR CHANGEMENT DE GAZ ......................33
Conversion pour l'alimentation au propane ..............................33
Conversion pour l'alimentation au gaz naturel ..........................36
Réglage de la taille des flammes ...............................................39
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whirlpool WEG515S0FV0
Summary of Contents for Whirlpool WEG515S0FV0
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS 30" (76.2 CM) FRONT CONTROL GAS RANGES INSTRUCTIONS D’INSTALLATION DES CUISINIÈRES À COMMANDES FRONTALES DE 30" (76,2 CM) Table of Contents Table des matières RANGE SAFETY ................2 SÉCURITÉ DE LA CUISINIÈRE ...........21 INSTALLATION REQUIREMENTS ..........4 EXIGENCES D’INSTALLATION ...........23 Tools and Parts ................4 Outils et pièces ................23 Location Requirements ..............4... -
Page 2: Range Safety
RANGE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... - Page 3 In the State of Massachusetts, the following installation instructions apply: Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts. Acceptable Shut-off Devices: Gas Cocks and Ball Valves installed for use shall be listed. A flexible gas connector, when used,must not exceed 4 feet (121.9 cm).
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Location Requirements Gather the required tools and parts before starting installation. IMPORTANT: Observe all governing codes and ordinances. Read and follow the instructions provided with any tools Do not obstruct flow of combustion and ventilation air. listed here. - Page 5 Mobile Home - Additional Installation Requirements Cabinet Dimensions The installation of this range must conform to the Manufactured Home Construction and Safety Standard, Title 24 CFR, Cabinet opening dimensions shown are for 25" (64.0 cm) Part 3280 (formerly the Federal Standard for Mobile Home countertop depth, 24"...
-
Page 6: Electrical Requirements
Electrical Requirements Gas Supply Requirements WARNING WARNING Electrical Shock Hazard Explosion Hazard Plug into a grounded 3 prong outlet. Use a new CSA International approved gas supply line. Do not remove ground prong. Install a shut-off valve. Securely tighten all gas connections. Do not use an adapter. - Page 7 Flexible Metal Appliance Connector: Gas Pressure Regulator If local codes permit, a new CSA design-certified, 4 to 5 ■ ft (122 to 152.4 cm) long, ½" or ¾" (1.3 or 1.9 cm) I.D. The gas pressure regulator supplied with this range must be (inside diameter), flexible metal appliance connector may used.
-
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Unpack Range Install Anti-Tip Bracket WARNING WARNING Excessive Weight Hazard Use two or more people to move and install range. Failure to do so can result in back or other injury. 1. Remove shipping materials, tape, and film from the range. Keep cardboard bottom under range. -
Page 9: Adjust Leveling Legs
4. Drill two ” (3 mm) holes that correspond to the bracket Adjust Leveling Legs holes of the determined mounting method. See the following illustrations. 1. If range height adjustment is necessary, use a wrench Floor Mounting or pliers to loosen the 4 leveling legs. This may be done with the range on its back or with the range supported on 2 legs after the range has been placed back to a standing position. -
Page 10: Make Gas Connection
Complete Connection Make Gas Connection 1. Check that the gas pressure regulator shut-off valve is in the “on” position. WARNING Explosion Hazard A. Gas pressure regulator shut-off valve shown in the “on” position Use a new CSA International approved gas supply line. 2. -
Page 11: Verify Anti-Tip Bracket Is Installed And Engaged
Burner caps should be level when properly positioned. If Burners Do Not Light Properly: If burner caps are not properly positioned, surface burners Turn cooktop control knob to the "off" position. will not light. The burner cap should not rock or wobble ■... -
Page 12: Remove/Replace Drawer
To Replace: Remove/Replace Drawer 1. Insert both hanger arms into the door. Be sure that the hinge notches are engaged in the oven doorframe. Remove all items from inside the storage drawer, and then allow the range to cool completely before attempting to remove the drawer. -
Page 13: Gas Conversions
GAS CONVERSIONS Gas conversions from Natural gas to Propane gas or from Propane Gas Conversion Propane gas to Natural gas must be done by a qualified installer. WARNING WARNING Explosion Hazard Use a new CSA International approved gas supply line. Tip Over Hazard Install a shut-off valve. - Page 14 3. Remove plastic cover from gas pressure regulator cap. Remove the orifice spuds shipped in the literature package in the oven. Gas orifice spuds are stamped with a number 4. Turn gas pressure regulator cap counterclockwise with and have a groove in the hex area. Replace the Natural gas "...
- Page 15 5. Slide the front of the bake burner to the side to remove tab To Convert Oven Broil Burner (Natural Gas to Propane from front of oven. Lift the back of the bake burner off the Gas) (on some models) oven orifice and set the bake burner aside.
-
Page 16: Natural Gas Conversion
6. Place the broil burner on the broil burner orifice hood. Natural Gas Conversion Insert the broil burner ceramic igniter in the hole in the rear of the oven. 7. Replace the flame spreader with all 4 tabs facing up and WARNING the notches toward the rear of the oven. - Page 17 4. Turn gas pressure regulator cap counterclockwise with 4. Gas orifice spuds are stamped with a number on the side. " (1.6 cm) combination wrench to remove. Replace the Propane gas orifice spud with the correct Natural gas orifice spud. NOTE: Do not remove the spring beneath the cap.
- Page 18 4. Remove 2 screws from the bake burner. 10. Position the front of the oven bottom panel toward the front frame, and then lower the rear of the oven bottom panel into 5. Slide the front of the bake burner to the side to remove tab the oven.
-
Page 19: Adjust Flame Height
If the “Low” Flame Needs to Be Adjusted: Complete Installation (Propane Gas to Natural Gas) 1. Light 1 burner and turn to lowest setting. 1. Refer to the “Make Gas Connection” section for proper 2. Remove the control knob. connection of the range to the gas supply. Hold the knob stem with a pair of pliers. - Page 20 4. If the oven bake flame needs to be adjusted, locate the air Adjust Oven Bake Burner Flame (If Needed) shutter near the center rear of the drawer cavity behind the access panel. Loosen the locking screw and rotate the air 1.
