Instruction Manual
POWER FEEDER
MODEL G1128 AND MODEL G1129
PARTS LIST
COPYRIGHT © 1995 BY GRIZZLY IMPORTS, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY IMPORTS, INC.
REPRINTED MARCH, 1997. PRINTED IN TAIWAN
DISCONTINUED MACHINE PARTS LIST DISCLAIMER
THESE PARTS REPRESENT THE LAST CONFIGURATION OF THE MACHINE BEFORE IT WAS DISCONTINUED. MACHINE CONFIGURATIONS MAY HAVE
CHANGED AS PRODUCT IMPROVEMENTS WERE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS LIST MAY NOT
EXACTLY DEPICT YOUR MACHINE. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES. PREVIOUS PARTS
LIST VERSIONS ARE NOT AVAILABLE ONLINE.
Advertisement
Related Manuals for Grizzly G1128
Summary of Contents for Grizzly G1128
-
Page 1: Parts List
COPYRIGHT © 1995 BY GRIZZLY IMPORTS, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY IMPORTS, INC. REPRINTED MARCH, 1997. PRINTED IN TAIWAN DISCONTINUED MACHINE PARTS LIST DISCLAIMER THESE PARTS REPRESENT THE LAST CONFIGURATION OF THE MACHINE BEFORE IT WAS DISCONTINUED. - Page 2 G1128/G1129 Power Feeders...
- Page 3 G1128 Gear Box REF# PART# DESCRIPTION P1128005 FRAME P1128007 OIL CAP P1128008 O-RING P1128009 BUSHING P1128010 WORM GEAR SHAFT 10-1 P1128010-1 SHAFT P1128011 WORM GEAR 30T PR10M SNAP RING 22mm P1128014 O-RING P1128015 COVER PFH05M FLAT HD SCR M5-0.8 x 12...
- Page 4 20-5 20-4 20-3 20-1 20-2 20-2 20-5 20-4 20-5 20-4 20-3 20-1 20-5 20-4 20-3 38-1 26-1 20-3 38-1 26-1 G1128/G1129 Power Feeders...
- Page 5 G1128 Base Type I REF# PART# DESCRIPTION P1128101 HANDLE ASSEMBLY P1128102 HAND WHEEL PRP31M ROLL PIN 6 x 36 P1128104 BUSHING P6202 BEARING 6202 - 2RS P1128106 SPACER PSS02M SET SCREW M6 - 1.0 x 6 P1128108 ELEVATING SCREW P1128109...
- Page 6 G1128/G1129 Power Feeders...
- Page 7 G1128 Base Type II REF# PART# DESCRIPTION 010 P1128101 HANDLE ASSEMBLY 020 P1128102 HAND WHEEL 021 P1128021-1 HAND WHEEL 030 PRP31M ROLL PIN 6 x 36 040 P1128104 BUSHING 050 P1128050 BUSHING 060 P1128060-1 COLUMN CAP 070 PSS04M SETSCREW M6-1.0 X 12...
- Page 8 G1128/G1129 Power Feeders...
- Page 9 18 PS21M 19 P1128219 INNER COVER 20 P1128220 POWER CORD 21 PC200 22 P1128222 O-RING 23 PB08M G1128/G1129 Power Feeders G1128 Motor PART# DESCRIPTION PHLP HD SCRW 10 - 24 x PHLP HD SCRW M4 - 0.7 x 15 CAPACITOR HEX BOLT M6 - 1.0 x 20...
- Page 10 G1128/G1129 Power Feeders...
- Page 11 CHAIN 20.5 LINKS 50A P1128050A SPROCKET 12T 50B P1128050B SPROCKET 12T 50-1 P1128050-1 SPROCKET 10T P1129051 CHAIN 31 LINKS 51-1 P1128051-1 CHAIN 16 LINKS G1128/G1129 Power Feeders REF# PART# DESCRIPTION PR05M SNAP RING 15mm 53A P1128053A SPROCKET 12T 53B P1128053B SPROCKET 12T...
- Page 12 20-5 20-4 20-3 20-2 20-1 G1128/G1129 Power Feeders 20-5 20-4 20-3 26-2 26-1...
- Page 13 RACK P1129116 ELEVATING BRACKET P1129119 COLUMN P1128120 HANDLE ASSEMBLY 20-1 P1128120-1 HANDLE 20-2 P1128120-2 HANDLE BODY G1128/G1129 Power Feeders REF# PART# DESCRIPTION 20-3 P1128120-3 BALL 6mm 20-4 P1128120-4 SPRING 20-5 PSS17M SETSCREW M8 - 1.25 x 6 PW06M FLAT WASHER 12mm...
- Page 14 G1128/G1129 Power Feeders...
- Page 15 PINION 180 P1128180 SPECIAL SETSCREW 190 P1129190 VERTICAL COLUMN 200 P1128120 HANDLE ASSEMBLY 201 P1128120-1 HANDLE G1128/G1129 Power Feeders REF# PART# DESCRIPTION 202 P1128120-2 HANDLE BODY 203 P1128120-3 BALL 204 P1128120-4 SPRING 205 PSS17M SETSCREW M8 - 1.25 X 6...
- Page 16 G1128/G1129 Power Feeders...
- Page 17 17 P1128217 18 PS21M 19 P1128219 20 P1129220 21 P1129221 22 P1129222 23 PB08M 24 PLW04M G1128/G1129 Power Feeders G1129 Motor PART# DESCRIPTION FAN COVER PHLP HD SCRW M4 - 0.7 x 6 MOTOR 1 HP SEAL 30-52-10 F/R SWITCH...
