Zonet ZRC0104C Series User Manual

Broadband switch router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
ZSR0104C Series
Broadband Switch Router User Manual
Page i

Advertisement

Table of Contents
loading

Related Manuals for Zonet ZRC0104C Series

Summary of Contents for Zonet ZRC0104C Series

  • Page 1 All manuals and user guides at all-guides.com ZSR0104C Series Broadband Switch Router User Manual Page i...
  • Page 2 All manuals and user guides at all-guides.com FCC Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: The Specifications Of Zsr0104C Series

    All manuals and user guides at all-guides.com The Specifications of ZSR0104C Series 1 RJ-45 10/100Mbps Ethernet Port 4 RJ-45 10/100Mbps Ethernet Ports Reload Button Reloading Factory Default Settings Client OS Support Win95/98/ME/2000/NT/XP/Mac/ Linux/Unix Configuration User-Friendly Web Configuration Tool Firewall Preventing Hacker’s Scan/Preventing DoS/Service Filter/Stateful Packet Inspection/IP Filter/MAC Filter Network Address Translation DHCP Client...

  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents FCC Interference Statement..........ii The Specifications of ZSR0104C SERIES......iii Chapter 1 Introduction........1 1.1 The ZSR0104C SERIES Broadband Switch Router .1 1.2 Physical Features of ZSR0104C SERIES ....1 1.3 Non-Physical Features of ZSR0104C SERIES.....1 1.4 Package Checklist............3 1.5 Installation Requirements ..........3 1.6 About this User’s Manual ..........3...
  • Page 5 All manuals and user guides at all-guides.com 3.2 Connect Ethernet Hub/Switch to ZSR0104C SERIES 7 3.3 Connect Wireless Access Point to ZSR0104C SERIES 7 3.4 Connect Cable/xDSL Modem to ZSR0104C SERIES7 3.5 Power up ZSR0104C SERIES ........8 Chapter 4 Use Your ZSR0104C SERIES ..8 4.1 Check the Web Proxy............8 4.2 Wizard Setup..............8 A.
  • Page 6 All manuals and user guides at all-guides.com 5.6 DHCP Server ..............25 DHCP Definition..................25 DHCP Server in LAN ................25 DHCP Client in LAN ................26 5.7 Virtual Server (Port Forwarding)........27 5.8 Firewall................29 DMZ Host Configuration..............29 Anti PING and TCP/UDP Echo Attack ..........31 Application Filter .................32 URL Filter ....................32 6.1 Troubleshooting ............34...
  • Page 7 All manuals and user guides at all-guides.com Appendix B: Common Port Numbers..... 51 Appendix C: Terminology ........ 52 Appendix D: Technical Support ....56 D.1 Hardware Problem ............56 D.2 Software Download............56 D.3 Installation/Application Problem ........56 Page vii...

  • Page 8: Chapter 1 Introduction

    All manuals and user guides at all-guides.com Chapter 1 Introduction Thank you for purchasing ZSR0104C SERIES Broadband Switch Router. This chapter covers a brief description of ZSR0104C SERIES features, package content, installation requirements, and the organization overview of this User’s Manual. 1.1 The ZSR0104C SERIES Broadband Switch Router ZSR0104C SERIES Broadband Switch Router is the ideal router for sharing a single IP address with multiple users, providing firewall security, and accessing WAN with high speed for Home and...
  • Page 9 All manuals and user guides at all-guides.com LAN clients. Therefore the LAN clients “share” the only one WAN IP address, and it is called Broadband Switch. ‧ Firewall ZSR0104C SERIES provides prevents Ping and TCP/UDP Echo Attack, Hacker’s Scan, and Denial of Service (DoS).

  • Page 10: Package Checklist

    All manuals and user guides at all-guides.com client will receive the same LAN IP address. ‧ Remote Management ZSR0104C SERIES can be configured and managed from the WAN side via a specific port. ‧ MAC Clone ZSR0104C SERIES allows users to specify the MAC address of the Network Interface Card if Internet Service Provider has the requirement.
  • Page 11 All manuals and user guides at all-guides.com concepts of ZSR0104C SERIES. Enjoy your use of ZSR0104C SERIES! Organization of This User’s Manual Chapter 1, Introduction It briefly describes the features of ZSR0104C SERIES. Chapter 2, Get to Know the Hardware It explains the LED and port functions on the front and back panels.

  • Page 12: Chapter 2 Get To Know The Hardware

    All manuals and user guides at all-guides.com Chapter 2 Get to Know The Hardware This Chapter explains ZSR0104C SERIES LED and Port functions. 2.1 LED Indicators ZSR0104CP Front Panel ZSR0104C Front Panel Figure 2-1 Device Indicators Power: The Power LED illuminates whenever ZSR0104C SERIES is powered on. Status: The Status LED will be continuously on when the power is supplied.

  • Page 13: Back Panel

    All manuals and user guides at all-guides.com 2.2 Back Panel On the back panel, ZSR0104C SERIES has 4 RJ-45 10/100Mbps Ethernet LAN ports, and 1 RJ-45 10/100Mbps Ethernet WAN port. In addition, it has a Reload button and a Power Connector (7.5V 0.7A).

  • Page 14: Power Connector

    All manuals and user guides at all-guides.com SERIES power adapter into the power outlet. Step 3. It takes around 15 seconds to reset. The Power LED will turn on Green initially. Wait for it becomes Red then release the Reset button. Step 4.

  • Page 15: Power Up Zsr0104C Series

    All manuals and user guides at all-guides.com WAN port. 3.5 Power up ZSR0104C SERIES Connect the correct Power Adapter to ZSR0104C SERIES. Then plug the Power Adapter into an AC power outlet. The LED status will be as followed. Power LED and the 4 LAN port’s LED will turn on for the first second. The Power LED will be continuously on when the power is supplied.
  • Page 16 All manuals and user guides at all-guides.com Step1. Launch a web browser on your client PC connected to ZSR0104C SERIES. Then point the Web browser to http://192.168.1.1 (http://192.168.1.1 is ZSR0104C SERIES default IP address.) If the router IP address was configured with different IP address, use the configured IP address instead of 192.168.1.1.
  • Page 17 All manuals and user guides at all-guides.com Figure 4 –2 First please choose your local time zone to set time for your NAT. If have daylight saving click the checkbox and input the start date and end date. Then click “Next” button. Page 10...

  • Page 18: Cable Modem Connection

    All manuals and user guides at all-guides.com You will see 4 options as followed. If Internet access is through the cable modem, Please click the selection button of the “Cable Modem ”. Then click “Next” button. A. Cable Modem Connection Two option fields might be required to enter by some Internet Service Providers.

  • Page 19: Fixed-Ip Xdsl Connection

    All manuals and user guides at all-guides.com The default WAN Setting of ZSR0104C SERIES is Cable Modem Connection without Host Name and MAC Clone If you don’t know the MAC address of your Network Interface Card, follow the steps to obtain the information. The MAC address information might be helpful when you need to use MAC Clone.

  • Page 20: Ppp Over Ethernet (Pppoe) Connection

    All manuals and user guides at all-guides.com Fixed - IP is a WAN access type provided by some Internet Service Providers. You need to enter the information of IP address, Subnet Mask, Default Gateway, Primary DNS Server, and Secondary DNS Server. C.
  • Page 21 All manuals and user guides at all-guides.com b. Idle Time field: If the Idle Time was specified with non-zero number, ZSR0104C SERIES router disconnects the PPPoE session after there was no data traffic on WAN interface within the specified “Idle Time” minutes. c.
  • Page 22 All manuals and user guides at all-guides.com a. Idle Time field: If the Idle Time was specified with non-zero number, ZSR0104C SERIES router disconnects the PPTP session after there was no data traffic on WAN interface within the specified “Idle Time” minutes. b.

  • Page 23: Wan Setup Complete

    All manuals and user guides at all-guides.com Step 5. The ” DHCP Setting” page is used to configure DHCP Server and DHCP Client in LAN .If DHCP Server enabled, the LAN PC Client can automatically obtain the IP settings, including IP address, Domain Name, Subnet Mask, Primary DNS, and Secondary DNS from ZSR0104C SERIES.
  • Page 24 All manuals and user guides at all-guides.com Step 2. Click the “Advanced Setup “ (see Figure 4 – 2) and will be displayed, Figure 5 - 1. Step 3. The Router Status screen will show up and tell the current WAN and LAN IP settings of your ZSR0104C SERIES, including IP address, Subnet Mask, Gateway, Primary DNS, and Secondary DNS.

  • Page 25: Administration

    All manuals and user guides at all-guides.com 5.3 Time Click the “System/Time” button, will see the Figure 5-3 Figure 5 - 3 If you want to assign the timeserver, enter the IP address then click “Apply” button to save. If sntp server gets time from network, the system time will display now time, else time is NULL.

  • Page 26: Change Administrator's User Name And Password

    All manuals and user guides at all-guides.com The Administrator Setting page provides the following configuration options: a. Change Administrator’s User Name and Password b. WAN Side Administration Change Administrator’s User Name and Password. You can specify a new user name and password for the administrator. After enter the new user name, old password and new password twice, then click the “Apply”...

  • Page 27: Firmware Upgrade

    All manuals and user guides at all-guides.com 5.5 Firmware Upgrade A web-based interface, via Microsoft Internet Explore or Netscape web browser, is provided to allow the user upgrade the latest firmware to the NAT Router. The firmware upgrade could be executed from LAN site (local upgrade) or from WAN site (remote upgrade) Pre-requirements •...
  • Page 28 All manuals and user guides at all-guides.com Through the “Choose file” menu, locate the latest router firmware and open it. For example, the latest firmware file, zonet_2004.bin, is located and opened, the file name will appear at the entry of the firmware file name. Step 3.

  • Page 29: Reset

    All manuals and user guides at all-guides.com If click the “OK”, will appear firmware upgrade programming page, please wait for 35 seconds, the Nat will restart. When the firmware update is in process, please do not plug out the power adapter of ZSR0104C SERIES.

  • Page 30: Dynamic Dns (Domain Name System)

    All manuals and user guides at all-guides.com button on the confirmation page to make the ZSR0104C SERIES reboot. (See Figure 5 - 6) Figure 5 – 5 Figure 5 – 6 After clicking the OK button, Please remember: use 192.168.1.1 to access web page after reboot”. 5.7 Dynamic DNS (Domain Name System) If ZSR0104C SERIES acquired its WAN IP address via the DHCP or PPPoE schemes, its IP address is likely different from previous one after ZSR0104C SERIES is rebooted or PPPoE session is...
  • Page 31 All manuals and user guides at all-guides.com Step 1. Select DDNS service provider. ZSR0104C SERIES supports two DDNS service providers, www.no-ip.com www.dyndns.org. Browse the DDNS service provider’s web page and register a new account there. Your DDNS service provider will provide you the account ID and password.

  • Page 32: Dhcp Server

    All manuals and user guides at all-guides.com If dyndns.org was selected, User Name, Password and Host Name are mandatory; Enable Wildcard, Mail Exchanger and Backup MX are optional. Step 3. Update the IP address. When WAN public IP address changes, ZSR0104C SERIES will automatically inform your DDNS service provider the new IP address, or you can force the IP address update by clicking the Update button.

  • Page 33: Dhcp Client In Lan

    All manuals and user guides at all-guides.com receive the same LAN IP address, when ZSR0104C SERIES assigns IP addresses in the next time. B. The Pool Range of Assigned IP Address When DHCP is enabled, you can assign a group of LAN IP addresses. The group is called as “the pool.”...

  • Page 34: Virtual Server (Port Forwarding)

    All manuals and user guides at all-guides.com 5. DHCP Client List When DHCP is enabled. Will see how many DHCP clients get IP address form the NAT. If you want to enable DHCP in your PC, refer to A.1 Enable DHCP in Your PC in Appendix A: Configure TCP/IP in Your PC.
  • Page 35 All manuals and user guides at all-guides.com As illustrated as above, when ZSR0104C SERIES obtains traffic of Port 21 from the Internet, it will forward it to the FTP server with LAN IP address 192.168.1.2. If ZSR0104C SERIES receives traffic of Port 80, it will re-direct it to the Web server with LAN IP 192.168.0.3. To enable Virtual server, enter the port number to specify the service type, and the server’s LAN IP address for the traffic destination.

  • Page 36: Firewall

    All manuals and user guides at all-guides.com 5.10 Firewall 1. DMZ Host Configuration You can set up your personal computer or network-ready device to be a public or local DMZ hosts. In general, Internet applications use only one unique port and can pass through a NAT Router by enabling Virtual Server.
  • Page 37 All manuals and user guides at all-guides.com illustrated Then you will be able to communicate with your friend via NetMeeting. Besides, the other LAN clients behind ZSR0104C SERIES are still protected by its firewall, and the traffic initiated from the Internet is denied to access these LAN clients To activate Local DMZ Host, please check the Enable item and assign the LAN IP address of the LAN host.

  • Page 38: Anti Ping And Tcp/Udp Echo Attack

    All manuals and user guides at all-guides.com To enable Public DMZ Host, check Enable below Public DMZ Host and enter the public IP address of the device you want to assign as the Public DMZ Host. Then click the button Apply to make your settings take effect.

  • Page 39: Application Filter

    All manuals and user guides at all-guides.com 3. URL Filter If you want to restrict your LAN clients from accessing certain websites, enter the keywords of the websites in the blank. ZSR0104C SERIES will examine the packet information when receiving the packet with port 80 from the WAN.
  • Page 40 All manuals and user guides at all-guides.com Checked this item, the LAN client can access to the following services. For example, forwarding port 21.The LAN client only can access ftp in the Internet. Please refer to Appendix B: Common Port Numbers. 5.

  • Page 41: Troubleshooting

    All manuals and user guides at all-guides.com 6. IP Filter A. Disable Checked this item, the LAN client can access to Internet. B. Blocking the following IP Checked this item, the following IP cannot access to Internet. For example, blocks IP address 192.168.1.2 this client cannot access Internet. C.

  • Page 42: Router's Hardware Failure

    All manuals and user guides at all-guides.com DNS (Domain Name System) Failure. Please refer to the solution for each reason and solve your problem. If the problem persists, please contact our authorized distributor or dealer for technical support. 1. Router’s Hardware Failure Solution: 1.

  • Page 43: Failed Connection On Zsr0104C Series's Wan Side

    All manuals and user guides at all-guides.com 3. Failed Connection on ZSR0104C SERIES WAN Side Solution: 1. Check if the WAN link/act LED is continuously on or flashing. 2. Verify that your WAN access type and the corresponding information are the same as the datasheet provided by your Internet Service Provider.

  • Page 44: Disable Web Proxy

    All manuals and user guides at all-guides.com Appendix A: A.1 Disable Web Proxy When the Web Proxy is disabled, your Web browser can obtain information from ZSR0104C SERIES without the Web Proxy block. This section is divided into 4 parts as followed, “Disable Web Proxy for Windows 95/98/ME/2000/NT,”...
  • Page 45 All manuals and user guides at all-guides.com Step 2. Click the Connections tab. Press the LAN Settings... button. (Figure A -22) Figure A–22 Step 3. Verify the item “Use a proxy server” is not checked. Then click the OK button to close each the Internet Options window.
  • Page 46 All manuals and user guides at all-guides.com D. B. Netscape Step 1. Open Netscape and click the Stop button. Choose Edit and then click Preferences... A Preferences window will pop up. (Figure A-24) Figure A–24 Step 2. In Category, find Proxies under the advanced item. (Figure A-25) Figure A–25 Page 39...

  • Page 47: For Windows Xp

    All manuals and user guides at all-guides.com Step 3. Check Direct connection to the Internet. Then click the OK button. (Figure A-26) Figure A–26 2. For Windows XP If you use Windows XP, follow the steps to disable Web Proxy in your Web browser. E.
  • Page 48 All manuals and user guides at all-guides.com Step 2. Click the Connections tab. Press the LAN Settings... button. (Figure A-28) Figure A–28 Step 3. Verify that the item Use a proxy server for your LAN is unchecked. Then click the OK button to close each the Internet Options window.
  • Page 49 All manuals and user guides at all-guides.com B. Netscape Step 1. Open Netscape and click the Stop button. Choose Edit and then click Preferences... A Preferences window will pop up. (Figure A-30) Figure A–30 Step 2. Choose Proxies under the advanced item. (Figure A-31) Figure A–31 Page 42...

  • Page 50: For Mac

    All manuals and user guides at all-guides.com Step 3. Check Direct connection to the Internet. Then click the OK button. (Figure A-32) Figure A–32 3. For MAC The instructions are based on Mac OS 8.5. It is similar to Mac OS 7.x and above. Follow the steps to disable the Web Proxy.

  • Page 51: Verify Ip Settings

    All manuals and user guides at all-guides.com A. Netscape Step 1. Launch Netscape Navigator and click the Stop button. Go through the path “Edit→ Preferences...” Step 2. In Category, find Proxies under the advanced item. Step 3. Check direct connection to the Internet and click the OK button. A.2 Verify IP Settings Verify IP settings in your client computer to make sure the network is working and learn your client PC’s LAN IP address and your ZSR0104C SERIES Router’s IP address.
  • Page 52 All manuals and user guides at all-guides.com Step 2. Run the WINIPCFG command. (Figure A-34) Figure A–34 Step 3. To release the previous IP settings in your computer, choose your network interface card in the menu. Then click the Release button. (Figure A-35) Figure A–35 Step 4.

  • Page 53: For Windows 2000 /Nt

    All manuals and user guides at all-guides.com 2. For Windows 2000 /NT If you use Windows 2000 or NT, follow the steps to verify the IP settings in your client PC. The steps and screenshots here are based on Windows 2000. It is similar to the other Windows Operating System.
  • Page 54 All manuals and user guides at all-guides.com Step 3. To release the previous IP settings in your computer, run the command “ipconfig / release.” (Figure A-39) Figure A–39 Step 4. To obtain new IP settings from WPD –140, run “ipconfig / renew.” As listed below, the IP address is your client computer’s LAN IP address, and the Default Gateway is ZSR0104C SERIES IP address.

  • Page 55: For Windows Xp

    All manuals and user guides at all-guides.com 3. For Windows XP If you use Windows XP, follow the steps to verify the IP settings in your client computer. Step 1. Go through the path “Start→Run.”(Figure A-41) Figure A–41 Step 2. Enter command and press the OK button. (Figure A-42) Figure A–42 Step 3.

  • Page 56: For Mac

    All manuals and user guides at all-guides.com Step 4. To obtain new IP settings from WPD –140, run “ipconfig / renew.” As listed below, the IP address is your client computer’s LAN IP address, and the Default Gateway is ZSR0104C SERIES IP address. Make sure that your IP Address is 192.168.1.xxx (xxx ranges from 2 to 254), your Subnet Mask is 255.255.255.0, and your Default Gateway is 192.168.1.1.

  • Page 57: For Unix/Linux

    All manuals and user guides at all-guides.com 5. For Unix/Linux If you use Unix or Linux, follow the steps to verify the IP settings in your client PC. Step 1. To release the previous IP settings of your computer, run the command “kill all dhcpcd”. Step 2.

  • Page 58: Appendix B: Common Port Numbers

    All manuals and user guides at all-guides.com Appendix B: Common Port Numbers Port Number Service Name Echo Systat Chargen 20 (21) TELNET SMTP Time TACACS 67(68) BOOTP TFTP Gopher Finger HTTP(WEB) Kerberos POP2 POP3 AUTH SQLServ News/NNTP 137(138)(139) NetBIOS-ns, NetBIOS-dgm, NetBIOS-ssn IMAP2 161(162)

  • Page 59: Appendix C: Terminology

    All manuals and user guides at all-guides.com Appendix C: Terminology ‧ Auth (TCP Authentication) It implements the Identification Protocol, which can identify active TCP connections in Linux environment. ‧ Boot It is the process when the computer starts executing instructions. ‧...
  • Page 60 All manuals and user guides at all-guides.com File Transfer Protocol enables you to transfer files in a bi-directional method over a TCP/IP network. ‧ Firewall It is a mechanism that protects a network from attacks from the other networks. Also, it can provide the Internet access control list that restricts clients’...
  • Page 61 All manuals and user guides at all-guides.com to a different network or subnet. ‧ IP Address It is a 32-binary digit number that provides the source or destination information on the Internet. ‧ ISP (Internet Service Provider) It is a company that provides individuals and companies the access to the Internet. ‧...
  • Page 62 All manuals and user guides at all-guides.com of Ethernet and is commonly implemented by xDSL box Internet Service Provider for Dial-Up Internet connections. ‧ PPTP (Point to Point Tunneling Protocol) It is a standard VPN protocol that secures a private network with encryption and authentication of User ID and Password.

  • Page 63: Appendix D: Technical Support

    D.1 Hardware Problem For help with the hardware problems, please contact our authorized local distributor or dealer. D.2 Software Download If there is the demand of software download, please visit our website http://www.zonet.com.tw and find the latest software version. D.3 Installation/Application Problem To solve the installation or application problems, please contact our authorized local distributor or dealer.
