Fin
tm
Solution Document/Installation Manual
3form Fin hardware has a versatile design that allows mounting to vertical or horizontal surfaces as wall fins, horizontal privacy
partitions on desktops or pony walls, shelving, or even floor-to-ceiling partitions. It is simple to install and accentuates the material
it holds. Based on the material selection the Fin hardware seamlessly integrates with high-powered LED lighting to edge-light the
material. This document has information on both material and lighting compatibility. For more information on the lighting please
refer to the 3flex Series Edge Lighting Solution Document.
For more information, please visit 3-form.com or call 800.726.0126
JULY 2016 | MAN-052 Fin | REV 004 © 2016 3form, Inc. All rights reserved.
