VEECT110VF..
Model
• USERS OPERATING INSTRUCTIONS
• INSTALLATION ADVICE
•
IMPORTANT - PLEASE READ AND FOLLOW
IMPORTANT - PLEASE READ AND FOLLOW
Before beginning, please read these instructions completely and carefully.
Do not remove permanently affixed labels, warnings, or plates from the product. This
may void the warranty.
Please observe all local and national codes and ordinances.
Please ensure that this product is properly grounded.
The installer should leave these instructions with the consumer who should retain
for local inspector's use and for future reference.
The electrical connection should always be accessible
Electrical installation must be in accordance with the National Electrical Code,
ANIS/NFPA70 - latest edition and/or local codes.
IN CANADA: Electrical installation must be in accordance with the current CSA C22.1
Canadian Electrical Codes Part 1 and/or local codes.
B U I L T - I N
C E R A M I C
C O O K T O P
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Verona VEECT110VFSS
Summary of Contents for Verona VEECT110VFSS
- Page 1 B U I L T - I N C E R A M I C C O O K T O P VEECT110VF.. Model • USERS OPERATING INSTRUCTIONS • INSTALLATION ADVICE • IMPORTANT - PLEASE READ AND FOLLOW IMPORTANT - PLEASE READ AND FOLLOW Before beginning, please read these instructions completely and carefully.
-
Page 2: Important Precautions And Recommendations
USER INSTRUCTIONS IMPORTANT PRECAUTIONS AND RECOMMENDATIONS Dear Customer, Thank you for having purchased After having unpacked the appliance, check to ensure that it is not damaged. If you have any doubts, do not use it and consult your supplier or a and given your preference to our professionally qualified technician. -
Page 3: Control Panel Description
³ features SCHOTT Fig. 1.1 VITROCERAMIC HOB (Fig. 1.1) Electrical insulation Class I COOKING POINTS 1. Zone Ø 145 mm (5" 3/4) - 1000 W 2. Zone Ø 180 mm (7" 1/16) - 1400 W CONTROL PANEL DESCRIPTION 3. Rear zone control knob 4. -
Page 4: Using The Vitroceramic Hob
· using the vitroceramic hob VITROCERAMIC HOB The main characteristic of this pyroceram cooker top is that it permits rapid vertical trans- mission of the heat from the heating elements below to the saucepans on top. The heat does not spread horizontally, however, and therefore the glass stays cold only a few centimetres from the hob. - Page 5 HINTS FOR SAFE USE OF THE HOBS – Before switching on, check which knob controls the required hob. You are advised to place the saucepan on the hob before switching on and to take it off after switching off. – To switch on, always lightly press the control knob then turn it. –...
-
Page 6: Cleaning And Maintenance
» cleaning and maintenance GENERAL RECOMANDATION Do not use steam jet cleaners because the humidity could Before you begin cleaning you must ensure that the hob is switched off. infiltrate into the appliance making It is advisable to clean when the appliance is cold and especially when cleaning it dangerous. -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE HAS TO BE INSTALLED BY A QUALIFIED INSTALLER. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a qualified installer, service agent, or the gas supplier. GENERAL INFORMATION 1. Installation must conform with local codes. 2. -
Page 8: Cooktop Dimensions
¿ installation to the cabinet COOKTOP DIMENSIONS 11” 21/64 (288 mm) (CUT-OUT) min 3” SCHOTT 10” 5/8 (76.2 mm) (270 mm) form cut-out BOX DIMENSIONS Fig. 4.1 (CUT-OUT) min 3” (76.2 mm) 10” 5/8 form cut-out (270 mm) Fig. 4.2... -
Page 9: Proximity To Side Cabinets
PROXIMITY TO SIDE CABINETS 1. The cooktop may be installed directly to existing base cabinets. 2. The cooktop CANNOT be installed directly adjacent to sidewalls, tall cabinets, tall appliances, or other side vertical surfaces. There must be a minimum of 3” (76.2 mm) side clearance (left or right) from the cooktop cut-out to such combustible sur- face above the counter heigh. -
Page 10: Electrical Connection
´ electrical connection This appliance must be connected to a grounded, metallic permanent wiring sys- tem or a ground connector should be connected to the ground terminal or wire WARNING lead on the cooktop. TO AVOID ELECTRICAL SHOCK This appliance is manufactured with a frame connected, green or bare ground wire. HAZARD, BEFORE INSTALLING THE Connect the cooktop cable to the junction box through the CSA or UL-listed conduit APPLIANCE, SWITCH POWER OFF AT... -
Page 11: Electric Diagram
ELECTRIC DIAGRAM... - Page 12 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances.
