Safe Operation Practices • Set-Up • Operation • Service • Troubleshooting
Table of Contents
Safe Operation Practices ........................................ 2
Assembly & Set-Up .................................................. 6
Controls & Operation .............................................. 9
Service .....................................................................11
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
NOTE: This Operator's Manual covers several models. Features may vary by model. Not all features in this manual are applicable to all
models and the model depicted may differ from yours.
O
peratOr
Self Propelled Mower
All Wheel Drive
Model Series K and L
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
For Customer Service - 1-800-668-1238
'
M
s
anual
Troubleshooting .....................................................13
Parts/Warranty .............. See Separate Supplement
WARNING
Form No. 769-12043
(January 25, 2017)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Remington K Series
Summary of Contents for Remington K Series
-
Page 1: Table Of Contents
Safe Operation Practices • Set-Up • Operation • Service • Troubleshooting ’ peratOr anual Self Propelled Mower All Wheel Drive Model Series K and L Table of Contents Safe Operation Practices ........2 Troubleshooting .............13 Assembly & Set-Up ..........6 Parts/Warranty .... -
Page 2: Safe Operation Practices
Important Safe Operation Practices WARNING! This symbol points out Thoroughly inspect the area where the The blade control is a safety device. Never important safety instructions equipment is to be used. Remove all attempt to bypass its operation. Doing which, if not followed, could stones, sticks, wire, bones, toys and other so makes the safety device inoperative endanger the personal safety and/... - Page 3 Slope Operation Service for damage (e.g., bent, cracked, worn). Replace blade with the original equipment Slopes are a major factor related to slip and manufacture’s (O.E.M.) blade only, listed Safe Handling Of Gasoline: fall accidents, which can result in severe injury. in this manual.
- Page 4 Do not modify engine Notice Regarding Emissions Spark Arrestor WARNING: This machine is To avoid serious injury or death, do not modify Engines which are certified to comply with engine in any way. Tampering with the governor California and federal EPA emission regulations equipped with an internal setting can lead to a runaway engine and cause for SORE (Small Off Road Equipment) are...
- Page 5 1 — i ection mportant peration racticeS...
-
Page 6: Assembly & Set-Up
Assembly & Set-Up Thank You Thank you for purchasing your new equipment. It was carefully engineered If applicable, the power testing information used to establish the power rating of the engine equipped on this machine can be found at www.opei. to provide excellent performance when properly operated and maintained. - Page 7 Grass Catcher (If Equipped) Side Discharge Chute (If Equipped) Follow steps below to assemble the grass catcher (if needed). Make certain bag is Your mower may be shipped as a mulcher. turned right side out before assembling To convert to side discharge, make sure grass (warning label will be on the outside).
- Page 8 Adjustments Set-Up Handle Pitch (If Equipped) If equipped, the pitch of the handle can be Gas and Oil Fill-Up Cutting Height adjusted as follows: Refer to the Engine Operator’s Manual for Remove wing nuts (a) and carriage Dual Lever additional engine information. bolts (b) from handle.
-
Page 9: Controls & Operation
Controls & Operation Blade Control Dual Lever Drive Control Dual Lever Drive Control (Rear Wheel Drive Lever) (Front Wheel Drive Lever) Electric Starter Push Key* Recoil Starter Rear Discharge Door Rear Cutting Height Grass Catcher* Adjustment Lever Deck Wash* Side Discharge Chute* Bumper* * If Equipped Mulch Plug*... - Page 10 Operation Using Mower as Rear Wheel Drive Only: Squeeze the right lever drive control (c) Using Your Lawn Mower against the upper handle (b) to engage the rear wheel drive. Be sure lawn is clear of stones, sticks, wire, or Release both lever drive controls to other objects which could damage lawn mower disengage all wheel drive.
-
Page 11: Service
Service Maintenance Deck Care Deck Wash (If Equipped) Clean underside of the mower deck after each Your mower’s deck may be equipped with a General Recommendations use to prevent build-up of grass clippings or water port on its surface as part of its deck wash other debris. - Page 12 Blade Care Charging Battery (If Equipped) To ensure safe operation of your mower, periodically check the blade bolt for correct WARNING: When removing the WARNING: The battery contains torque. cutting blade for sharpening or corrosive fluid and toxic material; Belt Care replacement, protect your hands with handle with care and keep away from a pair of heavy gloves or use a heavy...
-
Page 13: Troubleshooting
Troubleshooting Problem Cause Remedy Engine fails to start 1. Blade control disengaged. 1. Engage blade control. 2. Spark plug boot disconnected. 2. Connect wire to spark boot. 3. Fuel tank empty or stale fuel. 3. Fill tank with clean, fresh gasoline. 4. - Page 14 Problem Cause Remedy Occasional skips 1. Spark plug gap too close. 1. Adjust spark plug gap. Refer to Engine Operator’s (hesitates) at Manual. high speed Idles poorly 1. Spark plug fouled, faulty, or gap too wide. 1. Reset gap or replace spark plug. 2.
