Maintenance

SHOCK OR BURN HAZARD:
WARNING
range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.
BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with
CAUTION
bare hands or a damp cloth can cause burns.
Oven Light Replacement
To remove the cover:
1. Hold a hand under the cover so it doesn't fall when
released. With fingers of the same hand, firmly push
back the wire cover holder. Lift off the cover.
Do not remove any screws to remove the cover.
2. Replace bulb with a 40-watt appliance bulb.
Lift-Off Oven Door
If improperly removed, oven door hinges may suddenly open and can cause personal injury to
WARNING
appendages near the hinge. Follow instructions below to avoid a risk of injury when removing and
re-installing the oven door.
To remove the door:
1. Open the door to the full open position.
2. Pull the hinge locks up over the hinge hooks on
both sides.
3. Grasp the door firmly on each side, lift slightly and
pull it straight out and away from the oven.
To replace the door:
1. Firmly grasp both sides of the door at the top.
2. Insert and seat the upper and lower hinge arms into
the oven slots.
3. Push the hinge locks down from the hinge hooks.
4. Close the oven door and make sure it is working
properly. If it is not working properly, remove and
replace it following the above steps.
DO NOT ATTEMPT TO CLOSE THE DOOR UNTIL
THIS STEP IS COMPLETE. THE HINGE OR DOOR
14
To replace the cover:
1. Place it into groove of the
light receptacle. Pull wire
forward to the center of
the cover until it snaps into
place.
2. Connect electrical power to
the range.
Slot
Hinge
lock
Upper hinge arm
Wire cover holder
Lower hinge arm
49-88065
