Model X-Key-24-USB
24 Keys
Individual Key Backlighting
www.xkeys.com

Box Contents

This package contains:
1- X-keys XK-24
1- Installation CD
1- Replacement key set (2 tall, 1 wide, 1 key puller)
2- Angled feet
1- Legend Sheet
1- Product Manual

Quick Start for Windows

Run the MacroWorks 3 (MW3) installation program from the enclosed disc.
1.
Plug in the X-keys and wait for Windows to recognize it.
2.
Press the programming switch (located on the top edge of the XK-24) to
3.
open the MW3 programming window (or click on the MW3 taskbar icon and
select the device).
Press any key on the X-keys (or double-click on the key image) to begin
4.
recording a macro.
Type keystrokes or select text, shortcut, or function. Multiple lines of
5.
keystrokes, text, shortcuts, and functions may be entered on a single key.
Press the key again (or click Save) to complete programming.
6.
When finished, slide the programming switch down to close the
7.
programming window.
To quickly learn how to use MW3 watch the brief tutorials on the disc or on our
website. Consult the MW3 help file for complete instructions and tips on
programming and using your X-keys.

Mac Users

Install ControllerMate for X-keys from the enclosed disc or visit the Apple page
in the Software section of our website for a free download. ControllerMate for
X-keys is published by OrderedBytes in partnership with P.I. Engineering. For
full programming instructions and support, please visit
www.orderedbytes.com/controllermate/.
X-Key-24 Programmable Keypad
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-Key-24-USB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for X-keys X-Key-24-USB

  • Page 1 MW3 programming window (or click on the MW3 taskbar icon and select the device). Press any key on the X-keys (or double-click on the key image) to begin recording a macro. Type keystrokes or select text, shortcut, or function. Multiple lines of keystrokes, text, shortcuts, and functions may be entered on a single key.
  • Page 2 E-mail: tech@xkeys.com Compatibility X-keys USB devices require MacroWorks 3 for Windows XP, Vista, or 7 or ControllerMate for Mac OS-X. The X-keys XK-24 also has a “Hardware Mode” which gives it the ability to mimic a USB keyboard, mouse, or game controller (joystick) on any USB enabled operating system (including Linux).
  • Page 3 Compatible Accessories Please visit the Accessories page on our website for details on the following. X-keys USB Extender – up to 150 feet via CAT 5 cable Tall, wide, and quad keycaps Colored and transparent key caps Blank key spacers FCC Declaration of Conformity This device complies with Part 15 of the FCC rules.
