Model XK-299-VCM-SO
24 Keys
USB Virtual COM Device
Individual Key Backlighting
Designed, Sold, and Supported in USA
From P.I Engineering,
USA:
www.xkeys.com
UK:
www.x-keys-uk.com
Box Contents
This package contains:
1- X-keys XK-24 VCOM
1- Replacement key set (2 tall, 1 wide, 1 key puller)
2- Angled feet
1- Legend Sheet
1- Product Manual (this document)
Software
Download the latest version of the V-COM/TrueCOM Programming Utility and
SDK package from the software tab on this page:
xkeys.com/xkeys/xkrs232.php
Set up your COM port (Settings - Set Port).
1.
Click the visual representation of the keys on screen to program them.
2.
When done, click the "Write Macros" button (also available from the File
3.
menu).
Please consult the help file in the programming utility for details. If you do not
find the information you require in the help file, please contact us:
tech@xkeys.com
Developers
P.I. Engineering offers a free Software Development Kit with code samples in
C#, C++ and VB.NET. Please visit the Developers section on our website:
xkeys.com/develop.php.
VCOM XK-24 Programmable Keypad
Product Manual
The No Slogan Company
Advertisement
Table of Contents
Related Manuals for X-keys XK-299-VCM-SO
Summary of Contents for X-keys XK-299-VCM-SO
- Page 1 The No Slogan Company USA: www.xkeys.com www.x-keys-uk.com Box Contents This package contains: 1- X-keys XK-24 VCOM 1- Replacement key set (2 tall, 1 wide, 1 key puller) 2- Angled feet 1- Legend Sheet 1- Product Manual (this document) Software Download the latest version of the V-COM/TrueCOM Programming Utility and SDK package from the software tab on this page: xkeys.com/xkeys/xkrs232.php...
- Page 2 Department (sales@xkeys.com) for more information. Horizontal and Vertical Double-keys The included double-keys replace two single keys on the X-keys. To install a double key cap, remove two adjacent keys with the provided key-puller. Pressing the key puller over an adjacent key and working it under the cap to be removed is the recommended method.
- Page 3 X-keys XK-24 – 24 programmable keys X-keys XK-12 Joystick – 12 keys with a precision joystick X-keys XK-12 Jog & Shuttle – 12 keys with jog & shuttle X-keys XK-3 Foot Pedal – three programmable pedals X-keys XK-4 Stick – four programmable keys X-keys XK-8 Stick –...
- Page 4 Under this warranty, P.I. Engineering will, at its sole option, repair or replace any X-keys product which is defective, provided that you are responsible for (i) the cost of transportation of the product to P.I.
