- Page 1 S S T T A A G G E E D D E E S S I I G G N N E E R R TFX-24C User Guide Please read these instructions carefully before use World-wide Headquarters: 3000 North 29th Ct., Hollywood, Florida, USA, FL 33020 Tel: +1-954-929-1115 Fax: +1-954-929-5560 www.ChauvetLighting.com...
- Page 2 SCENE SETTER USER MANUAL INTRODUCTION: Congratulations on purchasing your new scene setter. It is a microprocessor controlled system that is fully DMX-512 and MIDI compatible. The scene setter is a 24 channel DMX-512 and standard MIDI controller.48 sets of program can be programmed in 4 pages and the total steps can not more than 4500.
-
Page 3: Rear Panel
REAR PANEL DC INPUT MIDI THRU 500 mA min DMX OUT AUDIO 1=Ground 1=Ground 2=Data- 2=Data+ 3=Data+ 3=Data- LINE IN 100mV 1Vp-p DMX polarity select REMOTE 1/4"stereo jack Full on Black out PAGE 2... - Page 4 OPERATING INSTRUCTION: RECORDING: 1. RECORD ENABLE 1) Press and hold RECORD KEY. 2) Press FLASH 1 FLASH 5 FLASH 6 FLASH 8 keys in sequence. 3) Release RECORD, the led is lighting, recording is ready. 2. ERASE ALL PROGRAMS 1) Press and hold RECORD KEY. 2) Press FLASH 1 FLASH 3 FLASH 2 FLASH 3 in sequence.
- Page 5 9. ADD STEP 1) In EDIT mode .record the step to be inserted. 2) Press STEP to execute the program till the step you want to insert before. 10. MODIFY STEP 1) In EDIT mode. Press STEP to execute the program till the step to be modify. 2) press UP or DOWN and desired FLASH ,the output will show on display ,you feel it is ok ,release FLASH.
- Page 6 17.MIDI OUT SETTING 1)Press and hold RECORD 2)Press 2th FLASH KEY 3 times, then release RECORD, when CHO appears on display, you can select MIDI IN channel from 1th FLASH to 16th FLASH. 3)After you press desired FLASH, the appropriate channel led is lit. 4)Press RECORD and EXIT to withdraw MIDI OUT setting.
- Page 7 B: closed loop mode: TRANSMITTER MIDI OUT NOTE: when sending file dump in open loop mode, you should set up receiving mode for the receiver, otherwise receiving is disable 7) When the power voltage is too low ,the display show LOP, now you should check whether the power is OK.
-
Page 8: Troubleshooting
CHAUVET. Troubleshooting • If the unit is not functional - check that unit is fully plugged in and then check fuses. No user serviceable parts inside, please refer to CHAUVET for service. Technical Assistance: 1-800-762-1084 (954) 929-1115 E-Mail tech@chauvetlighting.com POWER...
