  • Page 1 AX-174 INSTRUCTION...

  • Page 2: Table Of Contents

    Contents Title Page 1. GENERAL INSTRUCTION ..................4 1.1. Precaution safety measures ................4 1.1.1. Preliminary ....................4 1.1.2. During use ....................5 1.2. Symbols ......................6 1.3. Instructions ....................6 2. DESCRIPTION ....................7 2.1. Instrument Familiarization .................. 7 2.2.
  • Page 3 3.2.5. Diode Test ....................13 3.2.6. Capacitance measurement ................14 3.2.7. Current measurement ................... 14 4. TECHNICAL SPECIFICATIONS ................. 15 4.1. General Specifications ..................15 4.2. Measurement specifications ................15 4.2.1. AC Voltage ....................16 4.2.2. DC Voltage ....................16 4.2.3.

  • Page 4: General Instruction

    1. GENERAL INSTRUCTIONS This instrument complies with IEC 61010-1:2001, CAT III 1000V and CAT IV 600V overvoltage standards. See Specifications. To get the best service from this instrument, read carefully this user’s manual and respect the detailed safety precautions. International symbols used on the Meter in this manual are explained in chapter 1.2.

  • Page 5: During Use

    -protection of the Multimeter aginst misuse. *For your own safety, only use the test probes supplied with the instrument. Before use, check that they are in good condition 1.1.2. During Use *If the meter is used near noise generating equipment, be aware that display may become unstable or indicate large errors.

  • Page 6: Symbols

    1.2. Symbols Symbols used in this manual and on the instrument: Caution: refer to the instruction manual. Incorrect use may result in damage to device or its components. AC ( Alternating Current) DC( Direct Current) AC or DC Earth Grodnu Double insulated Fuse Conforms to European Union directives...

  • Page 7: Description

    2. DESCRIPTION 2.1. Instrument familiarization Figure 2-1 The front panel is shown as in Figure 2-1, explanation being as follows: 1. LCD display Used for displaying the measuring results and various symbols. 2. Keypad Measurement function keys. 3. Rotary switch Used for selecting measurement functions.

  • Page 8: Lcd Display

    2.2. LCD Display Figure 2-2 LCD screen is shown as in Figure 2-2, with its every symbol’s meaning shown as in the Table 1 Symbol Meaning Indicator for auto power off Indicates negative readings Indicator for AC voltage or current Indicator for DC voltage or current Unsafe voltage, voltage ≥30V, or voltage overload (OL) When auto scan mode is selected...

  • Page 9: Keypad

    2.3. Keypad 2.3.1. SELECT 1) When the meter is turned off and the rotary switch is not in position of OFF, press SELECT key for 2 seconds to turn on the meter and press the key once more >2 sec. To turn the power OFF. 2) At EF/VOLT position Switches between Auto scan mode, AC and DC voltage, Non-contact electric field detector (EF mode)

  • Page 10: Data Hold Mode

    Measurement Auto ranging DC V 1,0 mV ~ 1 000 V AC V 300,0 mV ~ 1 000 V (60 Hz) Resistance 0 Ω ~ 6,000 MΩ Capacitance 1,000 nF ~ 600,0 µF DC µA 0,1 µA ~ 6000 µA AC µA 30 µA ~ 6000 µA (60 Hz) DC mA...

  • Page 11: True Rms Measurement

    3.1.4. TRUE RMS measurement All the measurement values of the true RMS meter on the AC voltage and AC current are true root- mean-square values. The basic meter can only measure the AC average value. 3.1.5. Auto power off setting When the meter is powered on, it is under auto power off mode.

  • Page 12: Non-Contact Electric Field Detector(Ef Mode)

    3.2.2. Non-contact electric field detector (EF mode) It should be a long-distance In measuring high-voltage. Pay attention to safety Electric field is a special substance exist in the charge and the variable ambient magnetic field. To detector Non-contact electric field (set up and connect the Meter as shown in Figure 3-2): 1) Set the rotary switch to the position of EF/VOLT.

  • Page 13: Continuity Check

    3.2.4. Continuity Check To avoid electrical Shock and/or damage to the instrument, disconnect circuit Power and discharge all high-voltage capacitors before testing for Continuity. Continuity is a complete path for current flow. The beeper sounds if a circuit is complete. These brief contacts cause the Meter to emit a short beep.

  • Page 14: Capacitance Measurement

    In a circuit, a good diode (Si) should still produce a forward bias reading of 0.5V to 0.8V; however, the reverse-bias reading can vary depending on the resistance of other pathways between the probe tips. 3.2.6. Capacitance measurement To avoid electrical shock and/or damage to the instrument, disconnect circuit Power and discharge all high-voltage capacitors before measuring capacitance.

  • Page 15: Technical Specifications

    4) Connect the black test lead to the COM terminal and the red test leads to the µA/mA terminal for a maximum of 600mA. For a maximum of 10A, move the red test lead to the A terminal. 5) Break the circuit path to be tested. Touch the black probe to the more negative side of the break;...

  • Page 16: Ac Voltage

    4.2.1. AC Voltage ACV: Range Resolution Accuracy 60Hz 40Hz~400Hz 600mV 0,1mV ±(1,0% +3) ±(1,0% +3) 10mV ±(1,0% +3) 600V 100mV ±(1,0% +3) 1000V ±(1,5% +5) Above accuracies can be guaranteed within 5%~100% of the full range. The true RMS meter has residual value within 10 counts when the test leads are shorten, but that will not affect the accuracy of measurement.

  • Page 17: Capacitance

    Test Condition: Forward DC current approximately 1mA. Reversed DC voltage approximately 2.8V 4.2.6. Capacitance Range Resolution Accuracy ±(5,0% +5) 60nF 10pF ±(3,0% +3) 600nF 100pF 6µF 10nF ±(5,0% +3) 60µF 100nF 600µF 1µF 60mF uncertainty 10µF 4.2.7. Current DCA: Range Resolution Accuracy ±(1.0% +3)

  • Page 18: Linear Frequency

    4.2.8. Linear Frequency Range Resolution Accuracy 6kHZ 0,001HZ ±(0,05% +8) 10KHZ 0,01HZ Above accuracies can be guaranteed withni 10%~100% of the full range. 5. MAINTENANCE This section provides basic maintenance information, including fuse and battery replacement instructions. Do not attempt to repair or service your Meter unless you are qualified to do so and have the relevant calibration, performance test, and service information.

  • Page 19: Battery Replacement

    5.3. Battery replacement To avoid false Reading, which could lead to possible electric shock or personal injury, replace the battery as soon as the battery indicator ( ) appears. Before replacing the battery, disconnect test leads and/or any connectors from any circuit under test, turn the meter off and remove test leads from the input terminals.
