Installation and Operating Instruction for B.E.G. - Occupancy detector PD2-M-DALI/DSI-HVAC-FC

1. Product information

Occupancy detector for daylight-dependent lighting
control
DALI/DSI interface for controlling digitally dimmable
electronic ballasts as a group
One additional potential-free switching channel having
innovative functions: totally switching off electronic ballasts
when used for control of lighting or delay of the HVAC
function when used for control of HVAC devices becomes
possible
Alarm pulse: the detector triggers only when three move-
ments are detected within 9 seconds
Switching between DALI and DSI programming possible
with DIP switch and remote control
Orientation light function
Version as Master device
Detection area can be extended with Slave devices
Manual switching and dimming via push button possible
Additional functions can be set up using the optional
remote control.
Factory settings 10 min and 500 lux

2. Operation

The presence detector controls the light automatically according
to people present (movements) and the ambient brightness.
The integrated light sensor constantly measures the ambient light
and compares it with the set value brightness on the detector. If
the ambient light is sufficient, lighting will not be switched.
If the ambient light level is below the set value brightness, a
movement activates the lighting in the room.
The detector switches the light off despite of a person being pre-
sent if there is enough natural light for 5 min or if no movement
is detected for one follow-up time.

3. Safety information

Work on the 110-240 V mains supply may only be
R2
carried out by qualified professionals or by instructed
persons under the direction and supervision of quali-
40
50
30
!
60
60
15
fied skilled electrical personnel in accordance with
120
5
A
electrotechnical regulations.
Disconnect supply before installing!
This device is not suitable for disconnection.
Mounting the cover ring, after introduction of the
power cable (FC version).

4. Mounting

In Master/Slave operation the Master device must
!
always be installed at the site with less daylight.
The light sensor should be mounted on the opposite
!
side of the window.
68 mm
A circular opening of diameter 68 mm must be produced in the
ceiling. Having connected up the cables in accordance with
regulations, the detector is inserted into the opening as shown in
the drawing and fixed into position with the assistance of the
spring clips.
®
5. Position DIP switches, LEDs and
Potentiometers
Light
measurement

6. Self test cycle/Startup behavior

The product enters an initial 60-second self-test cycle, when the
supply is first connected. During this time the device does not
respond to movement and stays on.

7. Putting into operation / Settings

20%
R1
LUX
2000
1200
50 30
600
10
18 16
10
5
6
200
22
3
25
40
1
30
TE
R2
20%
R1
40
50 30
30
10
18 16
50
10
5
60
15
6
60
22
3
25
120
5
1
30
A
TE
R2
20%
40
50 30
30
10
50
5
60
15
60
120
5
A
R2
40
30
50
15
60
120
5
A
A
!
net
PD2-M-DALI/DSI-HVAC
LEDs
II III
I
D
A
B
C
PD2
3
2
False ceiling
mounting
Product code
Brightness value for constant light control
(Potentiometer A)
The brightness set value can be defined between
10 and 2000 lux. The potentiometer enables a free
selection of the brightness value.
Symbol :
Night-time operation
Symbol
: Day-time operation
(Light evaluation inactive)
LUX
2000
Follow-up time for light control (Potentiometer B)
1200
600
The follow-up time can be set to 1 to 30 minutes.
200
40
Symbol TEST: test mode
Irrespective of the brightness, every movement switches
the light on for 1s, then off again for 2s.
Follow-up time for orientation light (Potentiometer C)
R1
LUX
2000
The follow-up time can be set infinitely variably at
1200
18 16
600
between 5 and 60 minutes. Manually switching ON/
10
6
200
22
3
25
40
OFF the orientation light.
1
30
TE
"ON" for permanent orientation light
"OFF" for deactiviation of orientation light
Follow-up time for device control (Potentiometer D)
20%
R1
LUX
2000
1200
The follow-up time can be adjusted between 5 min. and
50 30
18 16
600
10
10
5
60
120 min. The delay is active from a set time of >15 mi-
6
22
3
25
nutes. This delay is about 5 min. If no other movements
1
30
TE
are detected during this time, the delay starts again.
Impulse function
The impulse function can be used to control external
HVAC systems. All 9 sec. will be set an impulse of
2.5 sec.
Alarm impulse
In order to initiate an alarm impulse, there have to be
three detected movements within a period of 9 sec.
This function can be used to display a presence in the
room on external visualizations. All 9 sec. will be set an
impulse of 2.5 sec.
The device does not fulfil the requirements of DIN
EN50131-2-2 and therefore cannot be used in
professional intrusion detection systems.
DIP switch functions
DIP 1
Full automatic mode
DIP 2
HVAC function
DIP 3
Operation mode DALI
* If you select "LIGHT", the switching relay R2 operates synchro-
nously to the DALI light channel. The potentiometer R2 has no
function in this setting.
Potentiometer A Brightness (constant light control) channel 1
Potentiometer B Follow-up time (light) channel 1
Potentiometer C Follow-up time (orientation light)
Potentiometer D Follow-up time (device control) channel 2
LED I
green
1
LED II red
LED III white

8. Wiring diagram

Standard mode with Master/Slave
L
N
M1
L
N NO NO
HKL
HKL
Master
L

9. Manual switching and dimming

N
By pressing the push button, the phase can be given to the S
terminal.
To turn on or off the light, press the push button briefly. The light
will remain on or off, as long as people are detected plus the
follow-up time.
With a long press of the push button the light will be dimmed
manually. When releasing the button, the current brightness value
is retained.
L
N NO NO
With renewed long press of the push button, the dimming direction
HKL HKL
is reversed.
Master
Taking the phase to the R terminal by using a button, the HVAC
channel can be switched with a short key press.

10. Range

200
40
2.50 m
5.00 m
Connected Slave devices must have the same phase
!
as the Master device.
EN
Semi-automatic mode
Light control*
Operation mode DSI
L
N
E1
DALI/DSI
DA
DA
T2
T1
R
S
+
-
R
N
L
DA
Slave
L
N
E1
DALI/DSI
DA
DA
T1
R
S
+
-
R
N
L
DA
Slave
2
3
1
3
1
2
Ø 10.00 m Ø 6.00 m
Ø 4.00 m
Ø 20.00 m Ø 12.00 m
