LUXOMAT PD2-M-DALI/DSI-SM Operating Instruction

LUXOMAT
Installation and Operating Instruction for B.E.G. -Occupancy detectors PD2-M-DALI/DSI-SM/-FC and PD4-M-DALI/DSI-SM/-FC
1a. Features
* For connection of up to 50 lamps
* Suitable for dimmable electronic
ballasts and control modules
* DALI output
* Constant light control
* Manual switching/dimming
* Semi or completely automatic
operation
* Luminance (brightness) set point,
switch-off delay time for LIGHT and
orientation-light adjustable
* Sensor and power sections in one
housing
* Infrared remote control
2c. Self test cycle
2000
1200
600
200
40
The product enters an initial 60-second
self-test cycle, when the supply is first
connected. The occupancy detector is
ready for operation.
5. Option:
IR-PD-DALI
Wall bracket for remote control
IR-PD-DALI
®
1b. Mounting preparations
Work on the 230 V mains supply
may only be carried out by quali-
fied professionals or by instructed
persons under the direction and
supervision of qualified skilled elec-
trical personnel in accordance with
electrotechnical regulations.
Disconnect supply before installing!
When in Master / Slave mode of
operation, the Master-appliance
must always be installed at the
location where there is least
daylight.
120 60 50
A
3. Putting into operation / Settings
40
30
15
Follow-up time for light control
25 22
30 5 10
18
The time can be set infinitely variably at between
R1 16
10
1 and 30 minutes.
6
TEST 3
1
16 10
5
Symbol TEST: Test mode (Every movement switches on
2
the light for a period of 1 second, switching it off for a
1
TEST 30
period of 2 seconds after that regardless of the level of
15
brightness)
Twilight-switch for light control (relay 1)
2000
1200
The switch-on value for the light can be set at between 10
600
and 2000 Lux. Using the rotary control, the luminance set
200
40
points can be set as desired.
Symbol : Night-time operation
Symbol : Daytime / Night-time operation
Orientation lighting
ON
60
The orientation lighting can be set at between 5 and
50
30
60 min. This rotary controller serves to determine the work-
10
5
ing time of the orientation lighting.
OFF
"ON" for permanent orientation lighting.
"OFF" for deactiviation of orientation lighting.
Pulse spacing PD-Slave
9s 2s
2 or 9 seconds can be set for the pause between 2 pulses
sent to the master. The setting can be made with activated
( ) or deactivated ( ) LED indicator.
LED ON
LED OFF
For devices with a separate slave input, 2 sec. can be set.
6. Settings by remote control when open
DSI/
DALI
Resetting when
open: Deletes
or
all values set
with the remote
control, light
OFF.
+
or
1
to
min
max
ON
OFF
1
to
min
50
1500
Lux Lux
max
t < 5 sec.
ON
OFF
PD2/PD4-M-DALI/DSI
2a. Installation of the LUXOMAT
DALI/DSI-SM
C
close
open
The detector must be in stalled on a solid and level surface.
The circular cover ring must be removed prior to assembly.
To do this, twist the lens (C) of the PD4 or (D) of the PD2
anticlockwise through approximately 5° and lift off.
Having connected up the wires in accordance with regula-
tions, secure the detector with 2 screws. After installation
replace the lens and lock (turn clockwise). Mains to be
connected.
Unlocking device - Activation of
the programming mode
Switching between DSI and
DALI program
Dimming of the lighting on the
desired luminance value
Automatic reading in the
current light value as new
luminance set point
50
Adjusting of the luminance set point 1500
–
Lux Lux
+ / – small steps
+ –
/ big steps
50
1500
max
Lux
Lux
30
Follow-up time light
min
ON
Orientation lighting on/off
OFF
max
Orientation lighting and its
10
min
follow-up time
ON
Preset/user mode
OFF
=> (see page 2, point 9)
Fully automatic /semi automatic
mode => (see page 2, point 8)
Locking device – Exit program-
ming mode
LED flashes
Permanent protection against
sabotage
PD2 / PD4-M- 2b. Installation of the LUXOMAT
®
PD2/PD4-M-DALI/DSI-FC
D
A circular opening of diameter 68 mm
must be produced in the ceiling. Having
connected up the cables in accor dance
with regulations, the detector is inserted
into the opening as shown in the drawing
opposite and fixed into position with the
assistance of the spring clips.
4. Settings carried out using remote control (optional)
Remote control LUXOMAT
120 60 50
A
40
30
15
5 1. Check Battery:
10
open battery compartment by pressing the plastic
16 10 springs together and removing the battery-holder.
5
2
1
TEST
30
15
2. IMPORTANT
1 2
Please pay attention, that the setting is Potentio-
25 22
2000
30
18 meter 1 at "TEST" and Potentiometer 2 not at
1200
16
R1
600
10 "SUN". All values which have been programmed
200
6
TEST 3 40
1
using the remote control will be deleted in the
event of power failure in the position "TEST/
SUN". Please switch Potentiometer 2 over to
1 2 "MOON" or any other value.
25 22 2000
30
18
1200
R1 16
600
10
6 200
TEST
3
1 40
Caution:
Settings with remote control override the
potentiometer settings.
7. Key functions in closed state
Lock device
Test mode
Reset to deactivate
Resetting when closed
The lighting relay is switched off, i.e. opened and the
follow-up times reset.
Permanent protection against sabotage
This function blocks the unit permanently (green LED is illumi-
nated). This operating mode can only be activated during the
t < 5 sec.
period of 5 seconds after pressing the "lock" button. This status
will only permit actuating the function "Light on/ Light off".
The procedure for leaving this mode is as follows:
1. Switch off the current
2. Apply current for 31 – 59 seconds
3. Switch of the current again
50
1500 4. Apply current
Lux Lux
5. Open detector
Light on /off when closed
=> (see page 2, point 10)
The light will remain switched on/off for as long as movements
are detected in the areas of coverage. Once the last movement
has been detected, the light will remain on for the duration of
the follow-up time as per setting.
The appliance will then return independently to the mode
selected (Fully or Semi-automatic).
GB
®
68 mm
IR-PD-DALI
®
