1 USB Modem Introduction ............................................................... 3
1.1 Introduction .................................................................................. 3
1.2 Safety Warning and Notice ......................................................... 3
1.3 RF Safety Information ................................................................. 5
1.4 System Requirements ................................................................. 7
1.5 Technical Specifications ............................................................ 8
2 Installation ......................................................................................... 9
2.1 Unpacking .................................................................................... 9
2.2 Software Installation ................................................................... 9
2.2.1 Insert the SIM Card into the Modem .................................... 9
2.2.2 Connecting the Modem and computer ................................ 9
2.2.3 First Time Software Installation ........................................ 10
2.3 Using your Modem .................................................................... 10
2.4 LED Indicator ............................................................................. 11
2.5 Removing the Modem Safely .................................................... 11
2.6 Uninstalling the Software ......................................................... 11
3 Functions & Operation ................................................................. 12
3.1 Main Interface ............................................................................ 12
3.2 Task Bar Icons ........................................................................... 13
3.3 Connecting to the Internet ......................................................... 14
3.4 Text Messages .......................................................................... 15
3.4.1 Read Text Messages ........................................................ 16
3.4.2 Create New Message ....................................................... 16
3.4.3 Text Message Interface Guide ......................................... 17
Content
Content
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Zte K4505-Z
Summary of Contents for Zte K4505-Z
-
Page 1: Table Of Contents
Content 1 USB Modem Introduction ............... 3 1.1 Introduction .................. 3 1.2 Safety Warning and Notice ............3 1.3 RF Safety Information ..............5 1.4 System Requirements ..............7 1.5 Technical Specifications ............8 2 Installation ..................9 2.1 Unpacking ..................9 2.2 Software Installation .............. - Page 2 3.5 Contacts ..................17 3.6 Home Page ................18 3.7 Settings ..................18 3.7.1 Connection Settings ............18 3.7.2 Security Settings ............... 19 3.7.3 Network Settings .............. 19 3.7.4 Message Settings ............. 19 3.7.5 Alert Settings ..............20 3.7.6 Check for Updates ............20 3.8 Help ....................
-
Page 3: Usb Modem Introduction
1 USB Modem Introduction 1.1 Introduction Thank you for choosing the K4505-Z USB modem. Please read this manual carefully and keep it for future reference. The pictures, symbols and contents in this manual are for reference only. They are correct at the time of publication but might not be completely identical with your modem. - Page 4 or the manufacturer of the medical device before using the modem near such devices. • Be aware of the regulations when using the modem at places such as oil warehouses or chemical factories, where there are explosive gases or explosive products being processed. Turn off your modem as instructed.
-
Page 5: Rf Safety Information
dismantling or repair of the modem will void the warranty. 1.3 RF Safety Information The USB Wireless modem is a transmitting device with similar output power to a mobile phone. It uses an internal antenna to connect to the mobile network. To get the best performance from your device, do not cover or shield the device in any way as this will lead to increased output power. - Page 6 population. The guidelines are based on standards that were developed by independent scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR.
-
Page 7: System Requirements
RF exposure guidelines when used with the ZTE accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. While there may be differ- ences between the SAR levels of various phones and at various positions. -
Page 8: Technical Specifications
1.5 Technical Specifications HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Networks HSPA+/HSUPA/HSDPA/UMTS 850/900/1900/2100 MHz Frequency GSM/GPRS/EDGE 850/900/1800/1900 MHz Bands 77mm x 28mm x 12mm Dimensions Approx. 30g Weight HSPA+ Mode up to 21.6Mbps HSUPA Mode up to 5.76Mbps HSDPA Mode up to 7.2Mbps Data Rate UMTS Mode up to 384 Kbps EDGE Mode up to 236.8Kbps GPRS Mode up to 57.6Kbps Working Voltage... -
Page 9: Installation
2 Installation 2.1 Unpacking Check the following articles are in the package: Modem, USB Extension cable, Quick Start Guide and User Manual. 2.2 Software Installation 2.2.1 Insert the SIM Card into the Modem The SIM card is the Subscriber Interface Module provided by your Ser- vice Provider. -
Page 10: First Time Software Installation
In most cases the single cable should suffice. However, to increase the power delivered to the modem, use the double USB cable if required 2.2.3 First Time Software Installation After the modem is connected, your computer will launch the installation application software automatically. -
Page 11: Led Indicator
If your computer does not launch the software automatically click Start > Programs > Rogers Connection Manager > Rogers Connec- tion Manager to run the application software, or double click the short- cut icon on the desktop. Note: The modem can take up to 30 seconds to launch the user interface. If you click the icon during the auto-run sequence you may see an error message on your computer. -
Page 12: Functions & Operation
3 Functions & Operation 3.1 Main Interface The computer interface comprises three parts: Function Buttons, Sys- tem Information Bar, and User Information area. Function Buttons Use the Function buttons to carry out the corresponding operations: Connects to the internet Messages Interface View your Contacts Opens the Rogers Home Page Change system settings... -
Page 13: Task Bar Icons
System Information Bar Use the System Information Bar to monitor your network and modem status: Shows network signal Modem offline strength New SMS message in your Modem disconnected Inbox SIM card inserted Disconnected from the internet Connected to the internet SIM card not inserted Current network type:ED- SIM card is roaming... -
Page 14: Connecting To The Internet
Orange indicates the computer and modem are connected but the modem is offline Red indicates the modem is disconnected from the computer Red indicates no SIM card is inserted No network signal is detected New messages Green indicates successful connection to the Internet System Tray Menu Right Click the System Tray icon to access the following menu: Off-line/ On-line: Disconnect the modem from the network. -
Page 15: Text Messages
Connect to the Internet Click the Internet button and then click Connect to establish a connection to the internet. The card requires a few seconds to verify your connection and then shows State: Connected at the bottom of the interface. The data amount, time connected, etc. -
Page 16: Read Text Messages
saved on the computer. New Message: Compose a new message. Notes: Different SIM cards have different capacities. For more information, please consult your service provider. 3.4.1 Read Text Messages Click the Inbox button or the Text Messages icon on the Windows system tray to read the messages saved in the box. -
Page 17: Text Message Interface Guide
3.4.3 Text Message Interface Guide Enter Inbox, Sent Items, or Drafts to use the tabs at the bottom of the window: Read: Read the selected Text Message Reply: Reply to the selected Text Message Forward: Forward the Text Message to other recipients. Move: Save the Text Message on the computer or SIM card. -
Page 18: Home Page
group location. Groups can only be stored on the computer. • If a contact is selected, you can carry out the following additional steps using the tabs on the bottom of the screen: View: View the selected contact’s information. Delete: Delete the contact. Text MSG: Send a Text Message to the mobile phone number selected. -
Page 19: Security Settings
Set as Default: Set the selected Access Point as the default for con- necting to the internet. Note: Ensure that Rogers Internet is selected as the default when using the Rogers network. Your internet feature will not work if this setting is changed. -
Page 20: Alert Settings
you may need to modify some settings. Consult your service provider for more information. Message Center: Set the corresponding Message Centre number according to your service provider. You must input the correct Message Centre number to use the Text Message feature. The number is provided by your Service Provider. -
Page 21: Faq & Answers
4 FAQ & Answers If you have any problems with your connection or modem please consult the manual and check this section. If the problem still exists contact your service provider or check our website for more details at www.zte. com.cn. Problem... - Page 22 Problem Possible Causes Suggested Solution Description Check with your with service Message sent The Message Center provider and enter the correct failed. number is not correct. number in Message settings. You have no network Try moving location until you get coverage.
- Page 23 Problem Possible Causes Suggested Solution Description The Modem Consult you're your service pro- cannot connect to You don't have roaming vider before you go overseas the Internet when enabled on your plan. to enable roaming. abroad. The computer Check the audio card and adjust soundcard is disabled the volume.
-
Page 24: Declaration Of Rohs Compliance
ZTE CORPORATION is in compliance with the Di- rective 2002/95/EC of the European Parliament - RoHS (Restriction of...
