Summary of Contents for Nolan N-Com B601S Series

  • Page 3 USER INSTRUCTIONS AND SAFETY Congratulations on your purchase of an N-Com product. N-Com B601 was made using the most advanced technologies and the best materials. Long-running tests and thorough system development have allowed the highest audio quality to be achieved. For additional information about B601 visit the website www.n-com.it Firmware version: 1.0 REFERENCE STANDARDS...
  • Page 4: Table Of Contents

    Contents WARNINGS AND SAFETY ........................5 1.1.Road safety ......................................5 1.2.Switching on the system in safe environments ........................ 5 1.3.Interferences ...................................... 5 1.4.Appropriate use ....................................5 1.5.Qualified personnel ..................................6 1.6.Accessories and batteries ................................6 1.7.Disposal ........................................ 6 CONTENT OF THE PACKAGING ......................7 INSTALLATION ............................
  • Page 5: Warnings And Safety

    WARNINGS AND SAFETY Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N- Com B601. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and the like.
  • Page 6: Qualified Personnel

    Caution: An incorrect installation of the system in the helmet may alter the aerodynamic and safety characteristics of the helmet itself, thus creating dangerous conditions. Install the N-Com system according to the instructions provided in the product documentation. In case of doubt, please contact your local N-Com dealer. Warning: Listening to other equipment should not interfere with driving the vehicle, which must be the top priority at all times.
  • Page 7: Content Of The Packaging

    CONTENT OF THE PACKAGING The N-Com B601 package contains: e-box B601 Electronic plate PC connection cable Microphone Battery holder Rechargeable battery Key, screw, clamp Microphone-Stop Adhesive Velcro pads...
  • Page 8: Installation

    INSTALLATION Important: Prior to installing the N-Com system, it is recommended to write down the identification code affixed to the product (see chapter 16.5). You can download the installation video from www.n-com.it N-Com / Download section.  Remove the “N-Com” protection plate located on the helmet shell (Fig. 1) and open the helmet chin guard (flip up helmets).
  • Page 9: Installing The Microphone

    3.1. Installing the microphone JET HELMETS OR FLIP-UP HELMETS  Prepare the microphone by inserting the microphone clamp, being careful to position it properly (Fig. 6).  Position the microphone in its support as shown in figure 7, being careful that the fluorescent clamp is facing toward the inside of the helmet.
  • Page 10 Fig. 12 Fig. 13 Fig. 11  Insert the microphone connector in the micro USB electronic plate (Fig. 14).  Before you place the speaker in its housing, apply the Velcro pad to the polystyrene cheek pad (Fig. 15).  Position the loudspeaker in the special housing obtained in the polystyrene cheek pad (Fig. 16). ...
  • Page 11: Removing The System

     Before you place the speaker in its housing, apply the Velcro pad to the polystyrene cheek pad (right side).  Position the loudspeaker in its housing obtained in the polystyrene cheek pad (right side).  Replace the polystyrene cheek pad (right side), positioning the cable in the groove you see in the cheek pad.
  • Page 12: Basic Functions

    BASIC FUNCTIONS Note: Before using the N-Com device for the first time, recharge the battery completely for at least 10 hours. To obtain best performances from the battery, it is recommended to completely recharge the battery the first few times. Afterwards, you can recharge the battery for shorter periods. Whenever possible, it is best to recharge the battery completely.
  • Page 13: Configuration Menu

    CONFIGURATION MENU All Bluetooth pair ups and other adjustments are carried out in this mode. To put the system in “Configuration mode” (starting from a switched off system) press the “ON” key and keep it pressed for 4 seconds, until you hear the voice announcement “ Configuration ”. Once in the “Configuration”...
  • Page 14: Mobile Phone

    MOBILE PHONE To pair up a mobile phone to the B601 system, follow the procedure illustrated in Chapter 6. Answering a phone call Briefly press any key when you hear the incoming call signal. When you hear the ringtone, say any word out loud. Vocal answer (VOX phone) You can enable / disable the “VOX phone”...
  • Page 15: Conference Call Function

    7.2. Conference call function When a call comes in on a mobile phone connected via Bluetooth to B601, the intercom is temporarily turned off. However, if you wish to share the phone call with the other helmet, simply turn on the intercom manually during the phone call. During the phone call, briefly press “ON”...
  • Page 16: Music Via Bluetooth

    10. MUSIC VIA BLUETOOTH To pair up an Mp3 device to the B601 system, follow the procedure illustrated in Chapter 6. Play music (Play) Press “” and keep it pressed for about 2 seconds. Pause function (Pause) When the player is playing music, press “” for 2 about seconds. Next track (Skip) When the player is playing music, press “”...
  • Page 17: Intercom

    12. INTERCOM The N-Com B601 system allows communication with other N-Com systems, up to a maximum distance of about 150m (in open field, with no obstacles). The range of the communication varies depending on the N-Com systems used. Important: The procedure described below refers exclusively to the pairing up and operation between the B601 and the “900”...
  • Page 18: Universal Intercom" Intercom

    13. “UNIVERSAL INTERCOM” INTERCOM The N-Com B601 system can be connected via Bluetooth to intercom systems of other brands or to N-Com systems other than the “900” / “600” series, thanks to the UNIVERSAL INTERCOM function. Important: N-Com systems other than the “900” / “600” series must be paired up to the N-Com B601 by following the procedure “Pairing up the Universal Intercom”.
  • Page 19: Battery And Recharge

    14. BATTERY AND RECHARGE 14.1. Low battery signal During its operation, the system alerts the user with a voice message when the battery is low. From the first message, the system has a 1-hour autonomy. Warning is given every 10 minute. 14.2.
  • Page 20: Summary Table Of Controls

    15. SUMMARY TABLE OF CONTROLS    Button  Turning on 2 sec Turning off 3 sec Increase Volume Decrease Volume Answer phone call* Voice call 2 sec Speed Dialling Menu ** Hang up/reject a phone call 2 sec Manual Device Connection 2 sec Phone Conference Activation...
  • Page 21: Limited Warranty

    16. LIMITED WARRANTY With this LIMITED WARRANTY CERTIFICATE, Nolangroup warrants this Product to be free from defects in material and workmanship at the time of its original purchase by the buyer. We invite you to: Read the cautions pertaining to safety and proper use. ...
  • Page 22: Validity Of This Limited Warranty

    16.3. Validity of this limited warranty This warranty is valid only if the enclosed warranty form is duly and completely filled out with the following information: Product identification code  Name and stamp of the authorized dealer.  Product purchase date. ...
  • Page 23: Warranty Registration Form

    17. WARRANTY REGISTRATION FORM Product name B601 S SERIES Identification code Buyer’s Information Name Last name Address Phone e-mail Dealer’s stamp Date of purchase...
  • Page 24 www.n-com.it...
