- Page 1 USE AND CARE GUIDE Sears Caitlyn 7pc Dining set * Dining Table Product Code: D71 M12785 UPC Code: 7-22938-08614-6 Date of Purchase: __ / __ / __ La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
-
Page 2: Table Of Contents
Thank you for your purchase THANK YOU FOR YOUR PURCHASE! We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team. -
Page 3: Safety Information
Safety Information SET UP YOUR FURNITURE PROPERLY Ensure that all parts are assembled □ WARNING: properly and fully tightened as per the 1. Do not crawl, stand, or sit on tile table instructions. tops. When placing in the desired location, □... -
Page 4: Care And Maintenance
Warranty (continued) We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production. For a copy of our full limited warranty, please contact our customer service team below. Contact the Customer Service Team at 1-866-391-4868 or visit www.bjifurniture.com. Care and Maintenance Do not allow water to build up in frames. -
Page 5: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY! Identify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for 3 persons to complete all the assembly. -
Page 6: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table rim Table leg Connector ring Ceramic tile (large) Ceramic tile (small) Safety Information EVERY BOLT NEEDS TO BE USED WITH A WASHER. □ DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 2. □... -
Page 7: Assembly Instruction
Assembly Instruction Attaching the table legs □ Remove the plastic clamps from the table rim (A), and remove the ceramic tile top (D) form the table rim (A), and carefully place the ceramic top (D) & (E) on a soft surface. □... - Page 8 Assembly Instruction (continued) Attaching the connector ring □ Attach the connector ring (C) to the leg (B) using hex bolts (BB) and washers (CC). □ Ensure all bolts are aligned and assembled correctly Tighten all hex bolts (AA) and (BB) with the hex wrench (EE). Attach the hex bolt caps (DD) □...
- Page 9 Assembly Instruction (continued) Replacing the ceramic tile top WARNING: 1. Do not crawl, stand, or sit on tile table tops. 2. Do not set or lay heavy items on tile table tops. 3. Avoid extreme hot &cold items being placed on tile table tops. □...
-
Page 10: Customer Service
Please refer to part number when reordering Questions, problems, missing parts? Before returning to the store, call our Customer Service 8 a.m. - 5 p.m., EST, Monday-Thursday 8 a.m. – 4 p.m., EST, Friday 1-866-391-4868 Made in/ Hecho en CHINA Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com... - Page 11 USE AND CARE GUIDE Sears Caitlyn 7pc Dining set * Swivel Rocker Product Code: D71 M12785 UPC Code: 7-22938-08614-6 Date of Purchase: __ / __ / __ La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
- Page 12 Thank you for your purchase THANK YOU FOR YOUR PURCHASE! We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team.
-
Page 13: Safety Information
Safety Information SET UP YOUR FURNITURE PROPERLY Ensure that all parts are assembled □ WARNING: properly and fully tightened as per the 1. Do not crawl, stand, or sit on tile table instructions. tops. When placing in the desired location, □... -
Page 14: Care And Maintenance
Warranty (continued) We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production. For a copy of our full limited warranty, please contact our customer service team below. Contact the Customer Service Team at 1-866-391-4868 or visit www.bjifurniture.com. Care and Maintenance Do not allow water to build up in frames. -
Page 15: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY! Identify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for 3 persons to complete all the assembly. -
Page 16: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Right arm Left arm Back frame Seat frame T-Rocker Base Seat cushion Back cushion Safety Information EVERY BOLT NEEDS TO BE USED WITH A WASHER. □ DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 2 AND 3. □... -
Page 17: Assembly Instruction
Assembly Instruction Attaching the arms □ Attach the right arm (A) to the back (C) using M6 hex bolts (AA) and M6 washers (CC). □ Repeat these instructions to attach the left arm (B) to the back frame (C). - Page 18 Assembly Instruction (continued) Attaching the seat □ Attach the seat frame (D) to the right arm (A) using M6 hex bolts (AA) and M6 washers (CC). □ Repeat these instructions to attach the seat frame (D) to the left arm (B). □...
- Page 19 Assembly Instruction (continued) Attaching the T-Rocker □ Attach the T-Rocker (D) to the seat (D) using M8 hex bolts (BB), M8 washers (DD) and M8 nuts (EE). □ Tighten all the M8 hex bolts (BB) and M8 nut (EE) with the hex wrench (HH). Attach the M8 bolt caps (GG).
- Page 20 Assembly Instruction (continued) Inserting the T-Rocker □ Insert the T-Rocker (E) into the base (F). Make sure the seat bottoms out in the base for safety.
- Page 21 Assembly Instruction (continued) Adding the cushions □ Place the seat cushion (G), back cushion (H) onto the swivel rocker. □ Repeat these instructions to assembly the other swivel rocker. □ The swivel rockers are ready for enjoyment.
- Page 22 Please refer to part number when reordering Questions, problems, missing parts? Before returning to the store, call our Customer Service 8 a.m. - 5 p.m., EST, Monday-Thursday 8 a.m. – 4 p.m., EST, Friday 1-866-391-4868 Made in/ Hecho en CHINA Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
