OWNER'S MANUAL
Sears Heath 5pc Dining set
* Action Lounge Chair
Product Code: D71 M35255
UPC Code: 7-22938-10520-5
Date of Purchase: __ / __ / __
If you have any problems with this product, DO NOT RETURN IT TO THE STORE.
CALL OUR CUSTOMER SERVICE HOT-LINE AT
866-391-4868
1
8am-5pm (EST), Monday-Thursday
8am-4pm (EST), Friday.
View the expanded assortment of outdoor living product on-line at
WWW.sears.com
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to
BJI, Inc. © 2014 La-Z-Boy Incorporated.
Page 1 of 5
Advertisement
Related Manuals for LAZBOY Heath 5PC Chat Set
Summary of Contents for LAZBOY Heath 5PC Chat Set
- Page 1 OWNER’S MANUAL Sears Heath 5pc Dining set * Action Lounge Chair Product Code: D71 M35255 UPC Code: 7-22938-10520-5 Date of Purchase: __ / __ / __ If you have any problems with this product, DO NOT RETURN IT TO THE STORE. CALL OUR CUSTOMER SERVICE HOT-LINE AT 866-391-4868 8am-5pm (EST), Monday-Thursday...
- Page 2 W A R R A N T Y THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR COMMERICAIL USE. In order to activate your warranty please register at www.bjifurniture.com. There you can review our full warranty details and other helpful information. Or, you may call us at 1 866-391-4868, 8am - 5pm (EST), Monday –...
-
Page 3: Parts List
PARTS LIST PART# DESCRIPTION PICTURE Q’TY Seat Frame Base Seat Cushion Back Cushion Lumbar Pillow M8x45mm Hex Head Bolt M8 Locking Nut M8 Bolt Cap Page 3 of 5... - Page 4 Hex Wrench Assembly Steps: Step1: Part# H x 4 Part# G x 4 Part# F x 4 Part# B x 1 Part# A x 1 NOTE: Once all the bolts are in place tighten completely. Page 4 of 5...
- Page 5 Step2: Part# D x 1 Part# C x 1 Part# E x 1 Now the Action Lounge Chair is ready for your enjoyment. Page 5 of 5...
- Page 6 OWNER’S MANUAL Sears Heath 5PC Chat Set * Stone Top Table Product Code: D71 M35355 UPC Code: 7-22938-10520-5 Date of Purchase: __ / __ / __ If you have any problems with this product, DO NOT RETURN IT TO THE STORE.
- Page 7 W A R R A N T Y THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR COMMERICAIL USE. In order to activate your warranty please register at www.bjifurniture.com. There you can review our full warranty details and other helpful information. Or, you may call us at (866) 391-4868, 8am - 5pm (EST), Monday –...
- Page 8 Stone Top M6x20mm Hex Head Bolt M6 Washer Bolt Cap Hex Wrench Assembly Steps: Step1: Part# F x 8 Part# G x 8 Part# A x 1 Part# B x 4 Part# E x 8 NOTE: DO NOT tighten the bolts completely at this step. Page 3 of 5...
- Page 9 Step2: Part# C x 1 Part# E x 8 Part# F x 8 Part# G x 8 NOTE: Once all bolts are in place tighten completely. Step3: Part# D x 1 Page 4 of 5...
- Page 10 Your table is now ready for your enjoyment! WARNING: Do not crawl, stand, or sit on stone table tops. Do not set or lay heavy items on stone table tops. Avoid extreme hot & cold items being placed on stone table tops. Page 5 of 5...
