- Page 1 USE AND CARE GUIDE Sears Lucas 7pc Dining Set * Swivel Rocker Product Code: D71 M34951 UPC Code: 7 22938 10463 5 Date of Purchase: __ / __ / __ La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
-
Page 2: Table Of Contents
Thank you for your purchase THANK YOU FOR YOUR PURCHASE! We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team. -
Page 3: Safety Information
Safety Information SET UP YOUR FURNITURE WARNING: Do not sit or stand on the table. PROPERLY Ensure that all parts are assembled □ properly and fully tightened as per the instructions. When placing in the desired location, □ WARNING: Do not place heavy items on the ensure that all legs are resting on the same table top. -
Page 4: Care And Maintenance
Warranty (continued) We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production. For a copy of our full limited warranty, please contact our customer service team below. Contact the Customer Service Team at 1-866-391-4868 or visit www.bjifurniture.com. Care and Maintenance Do not allow water to build up in frames. -
Page 5: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY! Identify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for three persons to complete all the assembly. -
Page 6: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Chair seat Chair base Stem bracket Safety Information EVERY BOLT NEEDS TO BE USED WITH A WASHER. □ DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 3. □... -
Page 7: Assembly Instruction
Assembly Instruction Attaching the stem bracket NOTE: Do not fully tighten the bolts. □ Place the chair seat (A) on a soft, non-abrasive surface carefully. □ Attach the stem bracket (C) to the bottom of cross bar under the chair seat (A) by using M8 hex bolt (AA). - Page 8 Assembly Instruction (continued) Inserting the chair bucket □ Place the chair base (B) on a flat surface and align the stem under the seat frame with the hole on the base. Push down firmly to connect both pieces. Make sure the seat bottoms out in the base for safety.
-
Page 9: Customer Service
Please refer to part number when reordering Questions, problems, missing parts? Before returning to the store, call our Customer Service 8 a.m. - 5 p.m., EST, Monday-Thursday 8 a.m. – 4 p.m., EST, Friday 1-866-391-4868 Made in/ Hecho en CHINA Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com... - Page 10 USE AND CARE GUIDE Sears Lucas 7Pc Dining Set *Dining Table Product Code: D71 M34951 UPC Code: 7-22938-10463-5 Date of Purchase: __ / __ / __ La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
- Page 11 Thank you for your purchase THANK YOU FOR YOUR PURCHASE! We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team.
-
Page 12: Safety Information
Safety Information SET UP YOUR FURNITURE PROPERLY WARNING: Ensure that all parts are assembled □ 1. Do not crawl, stand, or sit on table tops. properly and fully tightened as per the 2. Do not set or lay heavy items on table instructions. -
Page 13: Care And Maintenance
Warranty (continued) In addition, purchase parts are not covered under this warranty. Proof of purchase (dated register receipt) is required for warranty claims. We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production. -
Page 14: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY! Identify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for 3 persons to complete all the assembly. -
Page 15: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table rim Table leg Tile in small size Tile in large size Safety Information EVERY BOLT NEEDS TO BE USED WITH A WASHER. □ DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 1. □... -
Page 16: Assembly Instruction
Assembly Instruction Attaching the table rim □ Carefully place the table rim (A) upside down on a soft, flat and non-abrasive surface. □ Attach the leg (B) to the table rim (A) using hex bolt (AA) and washers (BB). □ Tighten all M6 hex bolts (AA) with the hex wrench (DD). Attach the M6 PE caps (CC). - Page 17 Assembly Instruction (continued) Replacing the ceramic tile top WARNING: 1. Do not crawl, stand, or sit on tile table tops. 2. Do not set or lay heavy items on tile table tops. 3. Avoid extreme hot &cold items being placed on tile table tops. □...
-
Page 18: Customer Service
Please refer to part number when reordering Questions, problems, missing parts? Before returning to the store, call our Customer Service 8 a.m. - 5 p.m., EST, Monday-Thursday 8 a.m. – 4 p.m., EST, Friday 1-866-391-4868 Made in/ Hecho en CHINA Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
