ISTRUZIONI PER LA SICUREZZA ISTRUZIONI PER LA SICUREZZA Questo dispositivo STB è stato realizzato in modo tale da soddisfare gli standard di sicurezza. AVVERTENZA! Leggere attentamente le seguenti precauzioni relative alla sicurezza. 1. Per non danneggiare il cavo di alimentazione o la spina attenersi alle seguenti indicazioni.
COLLEGAMENTO DELL’STB COLLEGAMENTO DELL’STB 1. POSIZIONAMENTO DEL RICEVITORE Schema di collegamento Il RICEVITORE deve essere posizionato in un ambiente adeguatamente ventilato. Non posizionarlo in un armadietto completamente chiuso per non bloccare il flusso dell’aria ed evitare surriscaldamenti. Il dispositivo deve essere protetto dalla luce diretta del sole, dall’eccessiva umidità, da manipolazioni improprie e dagli animali domestici.
DESCRIZIONE DESCRIZIONE Pannello anteriore Pannello posteriore 1. MODEM Il modem è un terminale che condivide una linea con un apparecchio Questo tasto serve per accendere e spegnere il ricevitore (Standby). telefonico utilizzando uno sdoppiatore. 2. 7 Display segmento Questo display a LED visualizza il numero di canale corrente. Viene utilizzato per la PPV e per il trasferimento di informazioni relative Mentre il ricevitore è...
Questo tasto serve per inserire i dati del ricevitore nel sistema di menu e confermarli. 11. APP È il tasto che consente di accedere al gestore dell’applicazione SAMSUNG. 12. LIST Premendolo mentre si guarda il televisore, viene visualizzato un elenco di canali.
FUNZIONI DI BASE FUNZIONI DI BASE 1. Schermo 3. Selezione informazioni audio Prima di visualizzare il programma televisivo, è necessario eseguire l’installazione. ● Premere il tasto ALT per visualizzare l’elenco delle In un primo tempo sarà infatti possibile vedere solo le immagini dei menu. informazioni audio.
FUNZIONI DI BASE FUNZIONAMENTO DEL RICEVITORE 6. Informazioni sul programma Menu principale EPG - Guida elettronica avanzata ai programmi Dopo avere installato il sistema dell’antenna e l’STB con i connettori appropriati: La guida elettronica al programma fornisce per tutti i canali le ●...
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 1.1 Seleziona paese 1.3 Manuale scansione Per sintonizzare i nuovi canali, è disponibile l’opzione “Seleziona Per sintonizzare i nuovi canali e i segnali più deboli, è disponibile paese” che consente di selezionare la nazione dove hanno sede i l’opzione “Manuale scansione”...
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 2. Organizzazione canale 2.4 Sposta e modifica canale ● Selezionare l’elenco Interattivo/TV/RADIO premendo i Il menu “Organizzazione canale” ha quattro opzioni: tasti Il menu “Organizzazione canale” viene utilizzato per eliminare Frequenze e Canali oppure per spostarli e modificarli in base alle ●...
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 3. Chiave elettronica 3.2 Modifica codice PIN Per modificare il codice PIN, selezionare la seconda opzione, La funzione “Chiave elettronica” consente di impostare le “Modifica codice PIN”. limitazioni della visualizzazione e impedisce l’accesso non autorizzato all’STB tramite l’uso del PIN (Personal Identification In questo modo si accederà...
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 4. Impostazioni di sistema 4.3 Impostazioni media È possibile definire varie impostazioni per i supporti. È possibile modificare le impostazioni predefinite del sistema in Posizionare il cursore sul sottomenu e premere il tasto OK. base alle proprie esigenze.
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 4.5 Informazioni di sistema 4.8 Impostazione modem Nel caso in cui sia necessario contattare il service provider o un Per impostare il modem, seguire le istruzioni fornite di seguito. centro di assistenza, è possibile che vengano richieste alcune ●...
RISOLUZIONE DEI PROBLEMI SPECIFICHE TECNICHE In alcune aree, il segnale terrestre digitale potrebbe essere debole. Alimentazione Per ricevere questi segnali, è consigliabile utilizzare un’antenna con potenziatore Tipo : SMPS del segnale incorporato. Tensione di ingresso : CA 100-240V~, 50/60Hz Potenza fusibili : 250V T1.6AH È...
Warrenty Modulatore RF Questo prodotto Samsung e’ garantito per un periodo di dodici (12) mesi dalla data di acquisto, da difetti di fabbricazione o nei materiali. Nel caso di riparazione, il prodotto dovra’ essere riportato presso il rivenditore dal Uscita modulatore : CH 21~69 (preimpostato su CH 21) quale si e’...
Page 18
Instructions for use ....GB DTB-S500F / DTB-S501E...
Page 19
DTB-S500F / DTB-S501E Instructions for use DIGITAL TERRESTRIAL RECEIVER...
Page 20
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS This STB has been manufactured to satisfy international safety standards. WARNING! Please read the following recommended safety precautions carefully. 1. Follow these directions in order not to damage the power cord or plug. Do not modify or process the power cord or plug arbitrarily. MAINS SUPPLY AC 100-240V~, 50/60Hz Do not bend or twist the power cord too much.
Page 21
CONTENT GENERAL FEATURES Safety Instructions ........2 1.
CONNECTING YOUR STB CONNECTING YOUR STB 1. LOCATION OF THE RECEIVER Connecting Figure Your RECEIVER should be placed under proper ventilation. Don’t put in completely enclosed cabinet that will restrict the flow of air, resulting in overheating. The location should be safeguarded from direct sunlight, excess moisture, rough handling or household pets.
DESCRIPTION DESCRIPTION Front Panel Rear Panel 1. MODEM Modem is a terminal which shares a line with a phone using splitter. This key is used to turn the receiver on and off (Standby). It is used for handling PPV and transferring subscription information. 2.
Move the highlight bar for the MHP Application. Enter and confirm any data to the receiver in the menu system. 11. APP This key is the hard key for accessing the SAMSUNG application manager. 12. LIST Press while viewing TV and a list of channels is displayed.
BASIC FUNCTIONS BASIC FUNCTIONS 1. Display Screen 3. Select Soundtrack Before you can view the television program, you must perform the installation. ● Press the ALT key to see the soundtrack list. Therefore you will see only menu images at first. ●...
BASIC FUNCTIONS OPERATING THE RECEIVER 6. Program Information Main Menu EPG-Electronic Program Guide After installing your antenna system and STB with appropriate connectors. The electronic program guide gives you a channel list for the ● Plug in the AC main power and switch on the receiver. channels.
OPERATING THE RECEIVER OPERATING THE RECEIVER 1.1 Select Country 1.3 Manual Scanning To tune-in new channels, the STB has been provided with the To tune-in new channels and weak signals, the STB has option “Select Country”. been provided with the option “Manual Scanning” where Select the country where broadcasting services are provided.
OPERATING THE RECEIVER OPERATING THE RECEIVER 2. Channel Organising 2.4 Move & Edit Channel ● Select the TV/RADIO/Interactive list with keys. The “Channel Organising” menu has four functions: ● Select the TV/RADIO/Interactive list with or CH+/CH- The “Channel Organising” menu is used to delete the Frequencies and Channels or move&edit channel as you want.
OPERATING THE RECEIVER OPERATING THE RECEIVER 3. Parental Lock 3.2 Change PIN Code To change the PIN Code, select the second option This “Parental Lock” feature sets viewing restrictions and “Change PIN Code”. prevents unauthorized access to your STB through the PIN (Personal Identification Number), which is a 4 digit number.
OPERATING THE RECEIVER OPERATING THE RECEIVER 4. System Setup 4.3 Media Settings You can set the various media settings you want. This option enables you to change the factory preset system Place the cursor on this sub menu and press the OK key. settings as per your requirements.
OPERATING THE RECEIVER OPERATING THE RECEIVER 4.5 System Information 4.8 Modem Setup If you have to contact your service provider or a service center If you want to setup Modem, please follow the instruction below. they might ask for information available from this menu. ●...
TROUBLESHOOTINGS TECHNICAL SPECIFICATIONS In some region, the digital terrestrial signal may be weak. Power supply So you’d better use the antenna in which the booster was built, for watching the Type : SMPS weak signal channels. Input voltage : AC 100-240V~, 50/60Hz Fuse rating : 250V T1.6AH You can download and upgrade the system software of the receiver through...
Page 33
TECHNICAL SPECIFICATIONS MEMO RF modulator Modulator output : CH 21~69 (preset to CH 21) Video type : PAL BG, I, D/K (preset to PAL BG) UHF output level : 70±5 dBµV Output connector : IEC male Ant. O/P connector : IEC female Tuning method : PLL frequency synthesizer...
