ISTRUZIONI PER LA SICUREZZA ISTRUZIONI PER LA SICUREZZA Questo dispositivo STB è stato realizzato in modo tale da soddisfare gli standard di sicurezza. AVVERTENZA! Leggere attentamente le seguenti precauzioni relative alla sicurezza. 1. Per non danneggiare il cavo di alimentazione o la spina attenersi alle seguenti ALIMENTAZIONE DA RETE: CA 220-240V~, 50/60Hz indicazioni.
COLLEGAMENTO DELL’STB COLLEGAMENTO DELL’STB 1. POSIZIONAMENTO DEL RICEVITORE Schema di collegamento Il RICEVITORE deve essere posizionato in un ambiente adeguatamente ventilato. Non posizionarlo in un armadietto completamente chiuso per non bloccare il flusso dell’aria ed evitare surriscaldamenti. Il dispositivo deve essere protetto dalla luce diretta del sole, dall’eccessiva umidità, da manipolazioni improprie e dagli animali domestici.
DESCRIZIONE DESCRIZIONE Pannello anteriore Pannello posteriore 1. MODEM Il modem è un terminale che condivide una linea con un apparecchio Questo tasto serve per accendere e spegnere il ricevitore (Standby). telefonico utilizzando uno sdoppiatore. Viene utilizzato per la PPV e per il trasferimento di informazioni relative 2.
Passa dai canali TV a quelli Radio. 19. TV STANDBY/ON Consente di mettere l’televisore in modalità stand-by 20. APP È il tasto che consente di accedere al gestore dell’applicazione SAMSUNG. 21. CH.NUM INPUT Questi tasti servono per immettere i valori numerici della canal.
FUNZIONI DI BASE FUNZIONI DI BASE 1. Schermo 3. Selezione informazioni audio ● Premere il tasto ALT per visualizzare l’elenco delle Prima di visualizzare il programma televisivo, è necessario eseguire l’installazione. informazioni audio. In un primo tempo sarà infatti possibile vedere solo le immagini dei menu. Premere i tasti /...
FUNZIONI DI BASE FUNZIONAMENTO DEL RICEVITORE Menu principale 6. EPG Dopo avere installato il sistema dell’antenna e l’STB con i EPG - Guida elettronica avanzata ai programmi connettori appropriati: La guida elettronica al programma fornisce per tutti i canali le informazioni sul programma scelto.
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 1.3 Azzera alle impostazioni di fabbrica 1.1 Auto scansione Consente di tornare ai valori impostati in fabbrica nel caso Il sottomenu “Auto scansione” consente di scaricare in cui si verificassero dei problemi dopo la modifica di alcuni automaticamente i canali dal punto di caricamento valori relativi ai dati dei canali o per l’uso di valori errati.
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 2.4 Sposta e modifica canale 2. Organizzazione canale Il menu “Organizzazione canale” ha quattro opzioni: ● Selezionare l’elenco Interattivo/TV/RADIO premendo i tasti Il menu “Organizzazione canale” viene utilizzato per eliminare ¦/. Frequenze e Canali oppure per spostarli e modificarli in base ●...
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 3.2 Modifica codice PIN 3. Chiave elettronica Per modificare il codice PIN, selezionare la seconda opzione, La funzione “Chiave elettronica” consente di impostare le “Modifica codice PIN”. limitazioni della visualizzazione e impedisce l’accesso non autorizzato all’STB tramite l’uso del PIN (Personal Identification In questo modo si accederà...
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 4.3 Impostazioni media 4. Impostazioni di sistema È possibile definire varie impostazioni per i supporti. È possibile modificare le impostazioni predefinite del sistema in Posizionare il cursore sul sottomenu e premere il tasto OK. base alle proprie esigenze.
FUNZIONAMENTO DEL RICEVITORE FUNZIONAMENTO DEL RICEVITORE 4.8 Impostazione modem 4.5 Informazioni di sistema Per impostare il modem, seguire le istruzioni fornite di seguito. Nel caso in cui sia necessario contattare il service provider o un centro di assistenza, è possibile che vengano richieste alcune ●...
FUNZIONAMENTO DEL RICEVITORE NUMERI DISPONIBILI DEL FORNITORE 5.Servizi Pay Per View 1. Tasto della TV + codice dell'utente delle 3 cifre 2. Tasti di funzionamento della TV: TV STANDBY/ON, NUMERIC(0~9), CH+/- , VOL+/-, INPUT ● Mediaset Premium SEL., MUTE Mediaset Premium fornisce le informazioni della scheda per servizio di broadcasting di Mediaset.
Page 17
NUMERI DISPONIBILI DEL FORNITORE NUMERI DISPONIBILI DEL FORNITORE IT-28 IT-29...
Page 18
NUMERI DISPONIBILI DEL FORNITORE NUMERI DISPONIBILI DEL FORNITORE IT-30 IT-31...
Page 19
NUMERI DISPONIBILI DEL FORNITORE NUMERI DISPONIBILI DEL FORNITORE IT-32 IT-33...
N N o o t t a a : Per gestire questo prodotto con il vostro all'uscita video del televisore; telecomando attuale di Samsung TV, canale o uscita video non verificare l'uscita canale e video e dovete immettere il codice 014 nel...
SPECIFICHE TECNICHE SPECIFICHE TECNICHE Alimentazione Uscita A/V SCART TV : VIDEO (CVBS, RGB), AUDIO R&L Tipo : SMPS SCART VCR : VIDEO (CVBS), AUDIO R&L Tensione di ingresso : CA 220-240V~, 50/60Hz SPDIF : Uscita audio digitale Potenza fusibili : 250V T1.6AH RCA : VIDEO, AUDIO R&L...
Page 22
WARRENTY MEMO Questo prodotto Samsung e’ garantito per un periodo di dodici (12) mesi dalla data di acquisto, da difetti di fabbricazione o nei materiali. Nel caso di riparazione, il prodotto dovra’ essere riportato presso il rivenditore dal quale si e’ effettuato l’acqusito. Comunque tutti i rivenditori e i centri di assistenza tecnica autorizzata Samsung presenti nei paesi dell’...
Page 23
Instructions for use ..... GB DTB-B570E...
Page 24
DTB-B570E Instructions for use DIGITAL TERRESTRIAL RECEIVER...
SAFETY INSTRUCTIONS This STB has been manufactured to satisfy international safety standards. WARNING! Please read the following recommended safety precautions carefully. 1. Follow these directions in order not to damage the power cord or plug. MAINS SUPPLY: ● AC 220-240V~, 50/60Hz Do not modify or process the power cord or plug arbitrarily.
CONNECTING YOUR “STB” CONNECTING YOUR STB 1. LOCATION OF THE RECEIVER Connecting Figure Your RECEIVER should be placed under proper ventilation. Don’t put in completely enclosed cabinet that will restrict the flow of air, resulting in overheating. The location should be safeguarded from direct sunlight, excess moisture, rough handling or household pets.
DESCRIPTION DESCRIPTION Front Panel Rear Panel 1. MODEM Modem is a terminal which shares a line with a phone using splitter. This key is used to turn the receiver on and off (Standby). It is used for handling PPV and transferring subscription information. 2.
Toggle between the TV and Radio channel. 19. TV STANDBY/ON Puts the TV in stand-by mode. 20. APP This key is the hard key for accessing the SAMSUNG application manager. 21. CH.NUM INPUT Used to enter channel number 22. CONAX Select when you use Conax service.
BASIC FUNCTIONS BASIC FUNCTIONS 1. Display Screen 3. Select Soundtrack ● Press the ALT key to see the soundtrack list. Before you can view the television program, you must perform the installation. Press the / and OK keys to select one. ●...
BASIC FUNCTIONS OPERATING THE RECEIVER Main Menu 6. EPG (Electronic Program Guide) After installing your antenna system and STB with appropriate EPG-Electronic Program Guide connectors. The electronic program guide gives you a channel list for the channels. ● Plug in the AC main power and switch on the receiver. ●...
OPERATING THE RECEIVER OPERATING THE RECEIVER 1.3 Reset to Factory Defaults 1.1 Auto Scanning This is to restore the factory set values in case the user has The sub menu “Auto Scanning” will enable download of encountered some problems after changing any values of the channels automatically from the preprogrammed load.
OPERATING THE RECEIVER OPERATING THE RECEIVER 2.4 Move & Edit Channel 2. Channel Organising The “Channel Organising” menu has four functions: ● Select the TV/RADIO/Interactive list with¦/¤keys. The “Channel Organising” menu is used to delete the ● Select the TV/RADIO/Interactive list with/or CH+/CH- Frequencies and Channels or move&edit channel as you want.
OPERATING THE RECEIVER OPERATING THE RECEIVER 3.2 Change PIN Code 3. Parental Lock To change the PIN Code, select the second option This “Parental Lock” feature sets viewing restrictions and “Change PIN Code”. prevents unauthorized access to your STB through the PIN (Personal Identification Number), which is a 4 digit number.
OPERATING THE RECEIVER OPERATING THE RECEIVER 4.3 Media Settings 4. System Setup You can set the various media settings you want. This option enables you to change the factory preset system Place the cursor on this sub menu and press the OK key. settings as per your requirements.
OPERATING THE RECEIVER OPERATING THE RECEIVER 4.8 Modem Setup 4.5 System Information If you have to contact your service provider or a service center If you want to setup Modem, please follow the instruction below. they might ask for information available from this menu. ●...
OPERATING THE RECEIVER AVAILABLE MANUFACTURER NUMBERS 5.Pay Per View Ser. 1. TV button + 3-Digit User Code 2. TV Operating buttons: TV STANDBY/ON, NUMERIC(0~9), CH+/- , VOL+/-, INPUT SEL., ● Mediaset Premium MUTE Mediaset Premium provides the Card Information for Mediaset broadcasting service.
Page 38
AVAILABLE TV MANUFACTURER NUMBERS AVAILABLE TV MANUFACTURER NUMBERS GB-28 GB-29...
Page 39
AVAILABLE TV MANUFACTURER NUMBERS AVAILABLE TV MANUFACTURER NUMBERS GB-30 GB-31...
Page 40
AVAILABLE TV MANUFACTURER NUMBERS AVAILABLE TV MANUFACTURER NUMBERS GB-32 GB-33...
N N o o t t e e : In order to control this product with your to video output of television; existing Samsung TV Remote control, incorrect channel or video Check channel and video output you must input Code 014 into the TV...
