SB-2000 Pro
SUBWOOFER
Line Level Connection – Stereo Receiver or Preamplifier Left/Right Channels (cont'd)
RECEIVER/PREAMP
LINE LEVEL OUTPUTS
Enable and adjust the on-board low pass filter of the SB-2000 Pro for a smooth blend with the
main speakers.
NOTE: For additional guidance on speaker/subwoofer crossover settings, please consult our SVS Sound
Experts or our Merlin subwoofer matching tool at www.svsound.com/merlin.
www.svsound.com • custservice@svsound.com • (877) 626-5623
CONNECTING & CONTROLLING YOUR SUBWOOFER
REAR FRONT
L
R
LINE LEVEL
L R
LFE
+
30Hz 40Hz 60Hz 90Hz
0° 90°
_
VOL
LOW
PASS
LOW PASS
140Hz LFE
PHASE
180°
PHASE
