Summary of Contents for Wortmann Terra 2464W

  • Page 1 LCD/LED 2464W...
  • Page 2 Congratulations! This display is designed for both you and the planet! The display you have just purchased carries the TCO Certified label. This ensures that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world.

  • Page 3: Table Of Contents

    Content Safety Precautions ....................... 1 First Setup ........................... 2 Quick Installation ......................... 3 Installing the LCD Monitor ....................4 Front View of the Product ....................5 Rear View of the Product ..................... 6 Using On Screen Display (OSD) Functions ................. 7 Supporting Timing Modes ....................

  • Page 4: Safety Precautions

    According to WEEE regulation, this monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information from our website to handle it. www.wortmann.de...

  • Page 5: First Setup

    First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories: AC/DC Power Adapter (AC 100~240V Input / DC 12V Output)  ● DVI cable (24 pin) AC Power cord  ● User’s guide Audio cable ...

  • Page 6: Quick Installation

    Quick Installation 1. Connect Video cable (DVI cable) Make sure both monitor and computer are powered OFF. Connect the DVI cable from DVI output of computer to the DVI input of the monitor. Or connect VGA cable *Optional Connect the VGA cable from VGA output of computer to the VGA input of the monitor. Or connect HDMI cable *Optional Connect the HDMI cable from HDMI output of computer to the HDMI input of the monitor.

  • Page 7: Installing The Lcd Monitor

    Installing the LCD Monitor Installing the Stand Base 1. Place the monitor face down on a soft cloth or cushion on a table. 2. Install the stand base to the monitor, tighten the screw on base clockwise. Disconnecting the Stand Base 1.

  • Page 8: Front View Of The Product

    Front View of the Product ❶ ❷ ❸ ❹ ❺ ❻ ❶ OSD Menu On/Off ❷ Scroll Down/ Decrease ❸ Scroll Up/ Increase ❹ Confirm Select ❺ LED Indicator ❻ Power ON/OFF...

  • Page 9: Rear View Of The Product

    Rear View of the Product ❶ ❷ ❸ ❹ ❺ ❶ Power input (+12V DC in) ❷ DVI input (DVI-D 24 pin) ❸ HDMI input (HDMI 19 pin) ❹ VGA input (D-sub 15 pin) ❺ Audio input...

  • Page 10: Using On Screen Display (Osd) Functions

    Using On Screen Display (OSD) Functions Display main menu Exit from OSD menu Manual adjust mode select for VGA, DVI and HDMI mode Confirm the Select Select the desired item when in OSD menu ▼ When not in OSD menu, directly enters the Contrast/Brightness menu Select the desired item when in OSD menu ▲...
  • Page 11 Contrast/Brightness: To manually adjust the Contrast, Brightness, DCR and ECO of screen image. Contrast: To adjust the foreground white level of screen image.  ▲: increase contrast, ▼: decrease contrast. Brightness: To adjust the luminance of the video.  ▲: increase brightness, ▼: decrease brightness. DCR: To detect the distribution of the visual signals inputs, and create an ...
  • Page 12 Manual Image Adjustment: To manually adjust the H. / V. Position, Horizontal Size, Fine Tune, Sharpness and Video Mode Adjustment. H. / V. Position: To adjust the horizontal and vertical position of the video.  H. Position: ▲: move screen to the right, ▼: move screen to the left. V.

  • Page 13: Supporting Timing Modes

    Supporting Timing Modes 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA...

  • Page 14: Technical Information

    Technical Information Technical Specification 60.5 cm (23.8") LCD Panel Energy Star Power Management VESA DPMS compatible Off Mode, < 0.5 W Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.2745 x 0.2745 mm LCD Display Color 16.7M Active Display Area 527.04 mm x 296.46 mm...

  • Page 15: Care And Maintenance

    Care and Maintenance Care  Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare.  Put your monitor in a well ventilated area.  Do not place any heavy things on top of your monitor. ...
  • Page 16 Pour plus d'information sur le recyclage, veuillez contacter votre centre de recyclage agréé. Votre attitude quand au recyclage améliorera l'avenir de la planète et créera un environnement de vie de qualité pour les générations futures. Wortmann AG Bredenhop 20 D-32609 Hüllhorst Tel.
  • Page 17 License and to the absence of any warranty; and give any other recipients of the Program a copy of this WORTMANN AG License along with the Program.
  • Page 18 with a work based on the Program) on a volume of a storage or distribution medium does not 10. If you wish to incorporate parts of the Program into other free programs whose distribution bring the other work under the scope of this License. conditions are different, write to the author to ask for permission.
