Summary of Contents for Wortmann Terra 2775W PV
- Page 1 LCD/LED 2775W PV USER MANUAL + GERMAN + ENGLISH + FRENCH + SPANISH + ITALIAN + RUSSIAN + P O L I S H + C Z E C H...
- Page 2 Operation Instructions Thank you for purchasing this monitor, a high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. This monitor has been tested and found compliant with the CE mark. These limits are designed to provide proper protection against harmful interference to a residential installation.
-
Page 3: Table Of Contents
Content Safety Precautions ....................... 1 First Setup ........................... 2 Quick Installation ......................... 3 Illustration for turning the high adjustable stand base ............4 Front View of the Product ....................5 Rear View of the Product ..................... 6 Using On Screen Display (OSD) Functions ................. 7 Supporting Timing Modes .................... -
Page 4: Safety Precautions
Pay attention to all cables connected to the monitor against stumble hazards. According to WEEE regulation, this monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information from our website to handle it. www.wortmann.de... -
Page 5: First Setup
First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories: AC Power cord ● DisplayPort cable USB-C cable ● Quick start guide Warranty card ● Screwdriver ... -
Page 6: Quick Installation
Quick Installation 1. Connect Video cable (DisplayPort cable) Make sure both monitor and computer are powered OFF. Connect the DisplayPort cable from DisplayPort output of computer to the DisplayPort input of the monitor. Or connect USB-C cable Connect the USB-C cable from USB-C output of computer to the USB-C input of the monitor. -
Page 7: Illustration For Turning The High Adjustable Stand Base
Illustration for turning the high adjustable stand base (1) Tilt Angle Tilt UP: 20° Tilt DOWN: -5° (2) Lift Range 130mm (3) Swivel Angle Left: 45° Right: 45° (4) Pivot Angle Right: 90° Note In order to avoid scratched footstand. Before rotate the screen, to tilt the screen ：... -
Page 8: Front View Of The Product
Front View of the Product ❶ ❷❸ ❹ ❺ ❻ ❶ OSD Menu On/Off ❷ Scroll Down/ Decrease ❸ Scroll Up/ Increase ❹ Confirm Select ❺ Power ON/OFF ❻ LED Indicator... -
Page 9: Rear View Of The Product
Rear View of the Product ❼ ❻ ❶ ❷ ❸ ❹ ❺ ❻ ❶ Power input ❷ Cable Management ❸ HDMI input ❹ DisplayPort input USB-C input ❺ Note: Support USB Power Delivery, Data, and Video signal. USB-A input ❻ Note: Connect your USB devices, USB-C cable must be connected first. -
Page 10: Using On Screen Display (Osd) Functions
Using On Screen Display (OSD) Functions Display main menu Exit from OSD menu Select the desired item when in OSD menu ▲ When not in OSD menu, directly enters the Anti Blue Light menu Select the desired item when in OSD menu ▼... - Page 11 Picture: To manually adjust the Brightness, Contrast, Sharpness, Over Drive, DCR and ECO Mode of screen image. Brightness: To adjust the luminance of the video. ▲: increase brightness, ▼: decrease brightness. Contrast: To adjust the foreground white level of screen image. ...
- Page 12 OSD Settings: To set up OSD H. Position, OSD V. Position, OSD Background and OSD Time Out. OSD H. Position: To horizontally adjust the OSD position. ▲: move OSD to the right, ▼: move OSD to the left. OSD V. Position: To vertically adjust the OSD position. ...
-
Page 13: Supporting Timing Modes
Supporting Timing Modes 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 14: Technical Information
Technical Information Technical Specification LCD Panel 68.6 cm (27″) VESA DPMS compatible Power Management Off Mode, ≤ 0.3 W WQHD 2560 x 1440 max. Displayable Resolution Vertical Frequency 60Hz max. Pixel Dimension 0.2331 x 0.2331 mm LCD Display Color 1.07B Active Display Area 596.736 mm x 335.664 mm Operating... -
Page 15: Care And Maintenance
Care and Maintenance Care Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place any heavy things on top of your monitor. Make certain your monitor is installed in a clean and moisture-free area. ... - Page 16 Pour plus d'information sur le recyclage, veuillez contacter votre centre de recyclage agréé. Votre attitude quand au recyclage améliorera l'avenir de la planète et créera un environnement de vie de qualité pour les générations futures. Wortmann AG Bredenhop 20 D-32609 Hüllhorst Tel.
- Page 17 License and to the absence of any warranty; and give any other recipients of the Program a copy of this WORTMANN AG License along with the Program.
- Page 18 with a work based on the Program) on a volume of a storage or distribution medium does not 10. If you wish to incorporate parts of the Program into other free programs whose distribution bring the other work under the scope of this License. conditions are different, write to the author to ask for permission.
