M5800SB-SU-EXT Inputs and Outputs
1. POWER INPUT
Accepts a 10.5-24 Vdc power source such as the standard 20 Vdc adapter (supplied
with Sunstream part number ODU-PKIT-1).
2. ETHERNET DATA INTERFACE
Use a shielded cat 5 cable to connect the junction box to the transceiver unit. It is ok
to us UTP for the indoor connection to the switch or PC.
4. LED INDICATORS
These LEDs indicate when a data packet is transmitted(red) or received (green). The
yellow LED indicates the strength of the signal received from the base station.
CAUTION CAUTION
WHEN THE UNIT IS IN OPERATION AVOID STANDING DIRECTLY IN
FRONT OF THE ANTENNA. STRONG RF FIELDS ARE PRESENT WHEN
THE TRANSMITTER IS ON.
M5800SB-SU-EXT Specifications
Transmitter Section
Radio Section:
Frequencies:
Storable Channels:
Channel spacing:
Default channel plan-
RF Output Power:
EIRP:
Freq. Stability:
Freq. Plan:
Modulated Bandwidth:
nd
2 Harmonic atten:
LO Supression:
Symbol Rate:
Error Correction: None
8
32 memory locations
5.736 to 5.836 GHz in 2 MHz increments
Channel 1: 5.736 GHz
Channel 2: 5.756 GHz
Channel 3: 5.776 GHz
Channel 4: 5.796 GHz
Channel 5: 5.816 GHz
Channel 6: 5.836 GHz
Max: +18 dBm +/- 1 dB
Min: -8 dBm +/- 1 dB
+45 dBm (4 Watts) with 27 dBi dish (standard) antenna
.000435 % PLL Stabilized (4.35 ppm) over temp range
Single upconversion, 480 MHz IF
22 MHz (null to null, 20 dB)
Per CFR47 part 15.247 (–58 dBc min)
Per CFR47 part 15.247 ( -70 dBc min)
1.375 MSPS
