Mechanical and Environmental
General
Material:
Size:
Weight:
Mounting:
Connectors/Indicators
RF Output:
FCC Compliance:
Serial Interface:
LAN Interface
Power:
Environmental
Operating Temp: -40 to 60 deg C
Storage:
Humidity:
NEMA Rating:
Shock:
STANDARD EXTERNAL POWER SUPPLY
24 Volt DC Power adapter and J-Box supplied in ODU-PKIT-1 accessory package.
Type:
Input:
Output:
Max current:
STANDARD ANTENNA
The unit is designed to operate with the AD5800-27-D dual linear polarized dish antenna.
See the product specification for more information.
10
Powdercoated Aluminum base with polycarbonate radome
12.5"x5"x8" including mounting studs
4 lb
Grey steel pole mount provided
Direct connect to antenna per Part 15C, 15.203.
The transceiver shall comply with the following:
RJ11 connector
Shielded RJ45 connector
Carried on 4 unused pins of Ethernet cable
-40 to 85 deg C
100 % When sealed properly
NEMA 4X
Sustain 3 axis drop from 5 feet
Linear wallmount transformer
120 VAC
20 VDC +/- 1 V
1200 mA
Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
FCC Part 15.247
FCC Part 15.207(a)
