SLI9 / SLI14 / SLI23 / SLI34
Installation/Operator Manual
WARNING: For your safety the information
in this manual must be followed to
minimize the risk of fire or explosion and
to prevent property damage, personal
injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your
building.
• Clear the room, building or area of
all occupants.
• Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a competent professional.
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
— Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareils.
• Ne touchez à aucun interrupteur.
• Évacuez la pièce, le bâtiment ou la
• Appelez immédiatement votre
• Si vous ne pouvez rejoindre le
— L'installation et l'entretien doivent
être assurés par un professionnel
compétent.
Girbau SA
Carretera Manlleu, KM 1
Vic, Barcelona 54380 Spain
Phone No. 3493 886 1100
Fax No. 34 93 886 0785
girbau@girbau.es
Ne pas vous servir des téléphones
se trouvant dans le bâtiment.
zone.
fournisseur de gaz depuis un voisin.
Suivez les instructions du
fournisseur.
fournisseur de gaz, appelez le
service des incendies.
Part No. 113432

Advertisement

Table of Contents
loading

Summary of Contents for GIRBAU SLI9

  • Page 1 SLI9 / SLI14 / SLI23 / SLI34 Installation/Operator Manual AVERTISSEMENT: Assurez-vous de bien WARNING: For your safety the information suivre les instructions données dans cette in this manual must be followed to notice pour réduire au minimum le risque minimize the risk of fire or explosion and d’incendie ou d’explosion ou pour éviter...
  • Page 2 _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ Replacement parts can be obtained from your reseller or the Girbau, SA factory. When ordering replacement parts from the factory, you can FAX your order to 34 93 886 0785 or telephone your order to 3493 886 1100.
  • Page 3: Table Of Contents

    Table of Contents _______ IMPORTANT You must disconnect and lockout the electric supply and the gas supply or the steam supply Safety Precautions ........ 4 before any covers or guards are removed from the machine to allow access for cleaning, Specifications ........
  • Page 4: Safety Precautions

    The frequency of inspection To reduce the risk of personal injury, install and cleaning can best be determined from experience at lockable doors to prevent public access to the rear each location. of the dryers. Girbau, SA 113432-1...
  • Page 5 If the appliance ___________________________________________ is converted (gas type is changed), a data plate amendment must be obtained from Girbau. ___________________________________________ This appliance may cause spillage of products of combustion from an open-flue appliance fitted in the same...
  • Page 6: Specifications

    SLI9 Specifications _________________________________________________________________ MAXIMUM CAPACITY (DRY WEIGHT) 20 lb 9.07 kg TUMBLER DIAMETER 25-3/4” 65.41 cm 60.96 cm TUMBLER DEPTH 24” 212.38 L TUMBLER VOLUME 7-1/2 cu ft TUMBLER/DRIVE MOTOR 1/4 hp 0.19 kW BLOWER/FAN MOTOR 1/3 hp 0.25 kW 49.21 cm...
  • Page 7 SLI9 Specifications _________________________________________________________________ 113432-1 girbau@girbau.es...
  • Page 8 BOILER HORSEPOWER (NORMAL LOAD) 1.75 Bhp SUPPLY CONNECTION 1/2” F.N.P.T. RETURN CONNECTION 1/2” M.N.P.T. Shaded areas are stated in metric equivalents 9/30/05 Note The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. Girbau, SA 113432-1...
  • Page 9 SLI14 Specifications ________________________________________________________________ 113432-1 girbau@girbau.es...
  • Page 10 BOILER HORSEPOWER (NORMAL LOAD) 3.75 Bhp SUPPLY CONNECTION 3/4” F.N.P.T. RETURN CONNECTION 3/4” M.N.P.T. Shaded areas are stated in metric equivalents 9/30/05 Note The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. Girbau, SA 113432-1...
  • Page 11 SLI23 Specifications ________________________________________________________________ 113432-1 girbau@girbau.es...
  • Page 12 BOILER HORSEPOWER (NORMAL LOAD) 4 Bhp SUPPLY CONNECTION 3/4” F.N.P.T. RETURN CONNECTION 3/4” M.N.P.T. Shaded areas are stated in metric equivalents 9/30/05 Note The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. Girbau, SA 113432-1...
  • Page 13 SLI34 Specifications ________________________________________________________________ 113432-1 girbau@girbau.es...
  • Page 14: Installation Procedures

    To remove the skid from Installation and Gas Plumbing) or Canadian Electrical Codes the SLI9, simply lift the unit off of the skid; for the SLI14, SLI23, Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION (for or SLI34, locate and remove the 2 bolts securing the base of Electrical Connections).
  • Page 15: Fresh Air Supply Requirements

    ) for each SLI14, and 40 6-inch (15.24 cm) clearance between the back guard and the inch (258 cm ) for each SLI9. (Based on 1 inch [6.5 cm ] per first bend in the ductwork for ease of servicing. Single or 1,000 Btu [252 kcal].)
  • Page 16 0 and must not exceed 0.6 in WC (1.48 12 feet (3.66 meters). The minimum diameter of this ductwork mb). must be at least 4-inches (10.16 cm) for SLI9, 6-inches (15.24 cm) for SLI14, and 8-inches (20.32 cm) for SLI23 and SLI34. Note...
  • Page 17: Electrical Information

    1 elbow in it. requirements of the National Electrical Code ANSI/NFPA NO. A = SLI9 4-inch (10.16 cm) 70-LATEST EDITION or in Canada, the Canadian Electrical SLI14 6-inch (15.24 cm) Codes Parts 1 &...
  • Page 18 SERVICE WIRE APPROX. AMP DRAW CIRCUIT 3ø 13.5 37.6 — PHASE VOLTAGE SERVICE BREAKER 60 Hz 50 Hz 1ø — 41.3 SLI9 Gas 1ø 12.4 — 59.1 3ø 11.3 — 22.6 1ø — 1ø 3ø 12.4 — 23.1 1ø —...
  • Page 19 380-416V, 50 Hz. Caution The dryer must be grounded. A ground lug has been provided for this purpose. Input connection wiring must be sized properly to handle the dryer’s current draw. This information is printed on the dryer’s data label. 113432-1 girbau@girbau.es...
  • Page 20: Gas Information

    Pipe joint compounds that resist the action of Failure to comply with these codes or ordinances, natural, propane, and butane gases must be used. and/or the requirements stipulated in this manual, can result in personal injury and improper operation of the dryer. Girbau, SA 113432-1...
  • Page 21 Pressure Heat Input Pressure Model (Injector) Type Quantity B tu /ft in WC Btu/hr in WC Natural 1,000 7.0-13.0 40,000 11.72 3.264 SLI9 *Liquid Propane 2,500 11.0 40,000 11.72 1.854 10.0 Natural 1,000 7.0-13.0 55,000 16.12 3.988 SLI14 11.0 16.12 2.184...
  • Page 22 Important Piping/Connections Pipe joint compounds that resist the action of SLI9 SLI14 SLI23 SLI34 natural, L.P., and butane gases must be used. 3/8” 3/8” 1/2” 1/2” Test all connections for leaks by brushing on a soapy water solution (liquid detergent works well).
  • Page 23: Converting From One Family Of Gas To Another

    Required for unregulated propane or butane only. Never test for leaks with an open flame!!! Use a *** SLI9 and SLI14 will require 1; SLI23 and SLI34 will require 2. soapy water solution or product intended for that **** Required for regulated LPG or propane only.
  • Page 24 * Refer to page 21 for orifice (injector) size. To adjust gas valve’s internal regulator, remove the regulator ** SLI9 and SLI14 will require 1; SLI23 and SLI34 will require 2. vent cap with the regulator adjustment tool, which is located...
  • Page 25: Gas Pressure Testing

    Remove manometer. Tighten screw inside the pressure tap, Important or install plug. Turn gas cock to “ON” position and check for leaks with soap Coil failure due to improper pH level will void the solution with main burner “ON.” warranty. 113432-1 girbau@girbau.es...
  • Page 26: Water Information

    Consumption (Approx.) Inlet / Heat Input Model Maximum @ 125 psi (8.6 bar) Return (Normal Load) Water Information _____________________ SLI9 150 psig* 1.0 MPa 1.2 Bhp 45 lb/hr 20.41 kg/hr 1/2” / 1/2” SLI14 150 psig* 1.0 MPa 1.75 Bhp...
  • Page 27: Preparation For Operation/Start-Up

    (program) selections. If computer program • STEAM MODELS – Check to ensure all steam shutoff changes are required, refer to the computer programming valves are open. manual which was shipped with the dryer. 113432-1 girbau@girbau.es...
  • Page 28: Preoperational Instructions

    L.E.D. display will read COOL DOWN TEMP ___/ ___ MINUTES remaining. At the end of the heat cycle, the dryer will shut off the heat and continue the fan and tumbler until the Cool Down Time or temperature is reached. Girbau, SA 113432-1...
  • Page 29: Routine Maintenance

    Warning To avoid the hazard of electrical shock, discontinue electrical supply to the dryer. Steam Dryers Clean the steam coil fins. It is suggested that compressed air and a vacuum cleaner with brush attachment be used. 113432-1 girbau@girbau.es...
  • Page 30: Data Label Information

    CE Label Standard Label When contacting Girbau, the information on the data label is required to ensure proper service/parts assistance. The data label is located at the upper left rear of the dryer behind the back guard. 1. Model Number – This describes the style of dryer and type of heat (gas, electric, or steam).
  • Page 31 NOTES _____________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ 113432-1 girbau@girbau.es...
  • Page 32 Part No. 113432 1 - 01/25/06 -0...
