Operating Instructions
Installation Instructions provided
AW‑HN40HWPC
Model No.
AW‑HN40HKPC
Model No.
AW‑HN40HWE
Model No.
AW‑HN40HKE
Model No.
AW‑HN38HWPC
Model No.
AW‑HN38HKPC
Model No.
AW‑HN38HWE
Model No.
AW‑HN38HKE
Model No.
HD Integrated Camera
<Basics>
ENGLISH
DVQX1549ZA
Advertisement
Table of Contents
Related Manuals for Panasonic AW-HN40HKPC
Summary of Contents for Panasonic AW-HN40HKPC
- Page 1 Avant d’utiliser cet appareil, assurez-vous de lire la section « Lire ces informations en premier ! ». FRANÇAIS Pour de plus amples informations, visiter le site Web de Panasonic (http://pro-av.panasonic.net/manual/en/index. html) et consulter le mode d’emploi (PDF). Antes de usar este producto, asegúrese de leer “Lea este documento en primer lugar!”.
- Page 2 Ελληνικά σημαντικές ειδοποιήσεις που αφορούν το προϊόν σας, επισκεφτείτε τον ιστότοπο που ακολουθεί. Besök följande webbplats för säkerhetsinformation Svenska och viktiga meddelanden om produkten. A termékkel kapcsolatos biztonsági információkért Magyar és fontos értesítésekért látogasson el az alábbi weboldalra. http://pro-av.panasonic.net/manual/en/index.html...
- Page 3 P. 106 of the <Operations and Settings> is performed. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0 or...
-
Page 4: Table Of Contents
When mounting the unit on a tripod System example 7 (USB connection, Web camera) Appearance Operating Instructions Read this first! Concerning the wireless remote control (For AW-HN40HWPC, AW-HN40HKPC, (optional accessory) AW-HN38HWPC, AW-HN38HKPC) Parts and their functions Read this first! Camera unit... -
Page 5: Installation Instructions
To prevent injury, this apparatus must be securely This camera intended for use only with the Mount attached to the floor/wall in accordance with the Bracket enclosed with the unit and Panasonic Direct installation instructions. Ceiling Mount Bracket, WV-Q105A. Use with other apparatus is capable of resulting in instability causing possible injury. -
Page 6: Installation Precautions
Installation precautions Panasonic does not accept any responsibility for accident or damage during installation if procedure in this manual is not followed. To installation personnel Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely. Also, always read the “Read this first!” (page 5) of this manual as they contain important information. - Page 7 (page 14). run each cable through its own metal conduit. (The metal conduits must be grounded.) * : For AW-HN40HWPC, AW-HN40HKPC, When installing, transferring or disposing of the unit, be AW-HN38HWPC, AW-HN38HKPC absolutely sure to hold it by its pedestal area.
-
Page 8: How To Install And Connect The Unit
How to install and connect the unit Be absolutely sure to read through the “Read this first!” (page 5) and “Installation precautions” (pages 6 to 7). The procedure given here is for the kind of installation where the unit is suspended from an overhead surface, but the same steps are followed for a stand-alone installation. - Page 9 How to install and connect the unit (continued) Mount the mount bracket onto the installation surface. ● Use the bracket mounting screws [M4, bind-head: 10 mm (13/32 inches) long] supplied with the unit. ● For proper clamping torque, securely attach the screws using the specified tools. Screw diameter Clamping torque 1.47 N ·...
- Page 10 How to install and connect the unit (continued) Mount the unit. ● Align the position of the hole for checking the positioning with the status display lamp. ● Align the holes on the camera main unit used to insert the bottom panel with the protrusions on the mount bracket used for inserting the camera, push the camera to the bracket firmly, and rotate the main unit by about 15 degrees in the direction of the arrow.
- Page 11 How to install and connect the unit (continued) Connect the rear panel connectors. Anchor the AC adaptor cable in place using the cable clamp. ● How to secure the AC adaptor cable Loosely secure the cable clamp. Cable clamp AC adaptor cable LAN cable RS-232C cable...
-
Page 12: When Using The Wv-Q105A (Optional Accessory)
How to install and connect the unit (continued) ■ When using the WV-Q105A (optional accessory) It is recommended that you provide an inspection opening or other such space for access purposes in the area near where the equipment is installed in order to facilitate installation and the wiring connections work. Before mounting the mount bracket, check that the installation location is strong enough to withstand the total mass (approx. - Page 13 How to install and connect the unit (continued) When installing the unit on a wall (installation example) Before proceeding, fashion an L-shaped mounting fixture, and attach the fixture securely to the wall where the unit will be installed. IMPORTANT ● Before installing the unit, check that the surface of the wall where the unit will be installed is strong enough to bear not only the total weight (approx.
-
Page 14: Removing The Camera
Removing the camera Turn off the circuit breaker and power. Disconnect the cables. Disconnect the power cable, video cable, and control cable, etc. Remove the main unit mounting screw used to secure the unit and mount bracket. Push the unit (A). Turn it approximately 15 degrees away from the installed position (B), and remove it (C). -
Page 15: Stand-Alone Installation
Stand-alone installation (when the mount bracket is going to be used) The same steps are followed as for the kind of installation where the unit is suspended from an overhead surface (pages 8 to 11). Check the mounting space. Note ●... - Page 16 Stand-alone installation (when the mount bracket is going to be used) (continued) Check the mounting. Connect the rear panel connectors. ● How to secure the AC adaptor cable A Loosely secure the cable clamp. Cable clamp LAN cable (for RS-422) HDMI cable Loosely secure the cable clamp in the area shown above.
-
Page 17: When Installing The Unit On A Desktop
Stand-alone installation (when the mount bracket is not going to be used) ■ When installing the unit on a desktop Place the unit flat on the surface. Notes ● Install the unit in a stable location which will not be susceptible to shaking. If the unit is installed in a location which is susceptible to shaking, this will cause the unit’s images to shake in turn. -
Page 18: Connections
Connections ■ Connecting an NDI|HX compatible switcher AW-HN40/AW-HN38 AW-HN40/AW-HN38* Supplied AC adaptor LAN cable Switching hub NDI|HX compatible switcher External DC power supply Remote Camera Controller AW-RP120 Monitor Monitor *: The AC adaptor provided with the unit is not shown in the above figure. -
Page 19: Connecting A Controller (Aw-Rp50/Aw-Rp120)
Connections (continued) ■ Connecting a controller (AW-RP50/AW-RP120) (IP connection example) LAN cable Pan-tilt head / camera control signal AW-HN40/AW-HN38 Remote Camera Controller HDMI/SDI signal AW-RP50 SIGNAL GND POWER TO PAN/TILT HEAD 12V IN TALLY/GPI BOOT Monitor Supplied AC adaptor Supplied AC adaptor Remote Camera Controller AW-RP120 External DC... -
Page 20: System Example
Connections (continued) ■ System example 1 (connection with commercially available controller, RS-232C daisy-chain connection) AW-HN40/AW-HN38* Up to 7 Commercially available controller RS-232C connector RS-232C Supplied AC adaptor Supplied AC adaptor Supplied AC adaptor connector * You can connect up to seven cameras to a single controller. ●... -
Page 21: System Example
Connections (continued) ■ System example 2 (connection with commercially available controller, RS-422 connection) AW-HN40/AW-HN38 RS-422 communication connector Commercially available controller Supplied AC adaptor ● Configure the service switches at the bottom of the unit. For details on the service switches, see “Service switch settings” (page 42). Camera address Set to AUTO or 1 to 7. -
Page 22: System Example 3 (Serial Control)
Connections (continued) ■ System example 3 (serial control) AW-HN40/AW-HN38 AW-HN40/AW-HN38* RS-422 connector Supplied AC adaptor HDMI/SDI converters Pan-tilt head / camera (commercially control signal available) (LAN cable (straight cable)) Monitor 1 Monitor 2 Monitor Monitor Supplied AC System tally adaptor Compact Live Switcher AW-HS50 External DC... -
Page 23: System Example 4 (Ip Control)
Connections (continued) ■ System example 4 (IP control) AW-HN40/AW-HN38 AW-HN40/AW-HN38* IP video display Mobile terminal Supplied AC adaptor HDMI/SDI converters Wireless (commercially access available) point LAN cable IP video display Monitor 2 Switching hub Monitor 1 LAN cable (straight cable) Personal computer Monitor Monitor... -
Page 24: System Example 5 (Infrared Output Connection)
Connections (continued) ■ System example 5 (infrared output connection) You can point the infrared remote control of a commercially available controller toward the camera to operate it. Remote camera control signal RS-232C cable Commercially available controller (including infrared remote AW-HN40/AW-HN38 control signals) RS-232C connector... -
Page 25: System Example 7 (Usb Connection, Web Camera)
Connections (continued) ■ System example 7 (USB connection, Web camera) AW-HN40/AW-HN38 Communication software (optional accessory) Supplied AC Microphone adaptor USB cable (A-mini B type) Personal computer ● Use a USB cable that is compatible with the USB 2.0 specification. Connect a mini B connector to the unit. ●... -
Page 26: Appearance
Appearance Unit: mm (inch) 160 (6-5/16) 80 (3-5/32) 77 (3-1/32) 166 (6-17/32) -
Page 27: Aw-Hn38Hwpc, Aw-Hn38Hkpc)
Canada. Operation at a voltage other than 120 V AC may require the use of a different AC plug. Please contact either a local or foreign Panasonic authorized service center for assistance in selecting an alternate AC plug. indicates safety information. - Page 28 Read this first! (For AW-HN40HWPC, AW-HN40HKPC, AW-HN38HWPC, AW-HN38HKPC) (continued) FCC NOTICE (USA) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 29: Aw-Hn38Hwe, Aw-Hn38Hke)
Read this first! (For AW-HN40HWE, AW-HN40HKE, AW-HN38HWE, AW-HN38HKE) WARNING: CAUTION: • To reduce the risk of fire or electric shock, do not In order to maintain adequate ventilation, do not expose this equipment to rain or moisture. install or place this unit in a bookcase, built-in cabinet •... - Page 30 3. Change the connection method used for the apparatus. 4. Connect the apparatus to another power outlet where the power is not shared by any other appliances. Інформація для покупця Виробник: Panasonic Corporation Панасонік Корпорейшн Адреса виробника: Kadoma, Osaka, Japan Кадома, Осака, Японія...
- Page 31 Figure A Figure B Fuse Fuse (5 ampere) (5 ampere) indicates safety information. Manufactured by: Panasonic Corporation, Osaka, Japan Importer’s name and address of pursuant to EU rules: Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany...
-
Page 32: Before Use
8.0 / 9.0 / ® ® viewing the camera images on the screen. 10.0 / 11.0 * ● Connection with a Panasonic camera controller is also possible via Panasonic’s proprietary serial communication OS X v10.8 format. Safari 6.2 OS X v10.9 ●... -
Page 33: Disclaimer Of Warranty
IN NO EVENT SHALL Panasonic Corporation BE LIABLE ● After accessing the unit as an administrator, be sure to TO ANY PARTY OR ANY PERSON, EXCEPT FOR close all web browsers. -
Page 34: Characteristics
● The unit is equipped with functions that allow clean and pan-tilt head unit systems currently available from Panasonic Corporation so that an existing system can be and clear reproduction of images in a wide range of applications, such as high dynamic range (HDR) and... - Page 35 Easy connections and settings courtesy of IP control ● Up to a hundred units can be operated by IP connection from a Panasonic controller (AW-RP50, AW-RP120 and AK-HRP200). (The maximum length of the LAN cables is 100 meters [328 ft].)
-
Page 36: Controller Supported
■ ■ AC adaptor ......1 Power cable (1.5 m [4.92 ft]) for AW-HN40HWPC, for AW-HN40HWE, AW-HN40HKE, AW-HN40HKPC, AW-HN38HWE, AW-HN38HKE .............3 AW-HN38HWPC, AW-HN38HKPC ....1 ● For U.K. and Saudi Arabia ● For India only ● This product is equipped with ●... -
Page 37: Operating Precautions
Operating precautions Shoot under the proper lighting conditions. When using the automatic functions ● If “Full Auto” has been selected as the setting for Scene To produce pictures with eye-pleasing colors, shoot under the proper lighting conditions. on the camera menu, for example, all the auto settings The pictures may not appear with their proper colors when will be turned on, and manual operations will no longer be shooting under fluorescent lights. - Page 38 Operating precautions (continued) Color bars Do not point the camera directly at the sun or a laser beam no matter whether it is turned on or not. Color bars are used to adjust the color phase, and the widths and positions of these bars may differ from other models. Taking images of the sun, laser beams, or other brightly lit subjects for prolonged periods of time may damage the MOS sensor.
-
Page 39: Concerning The Wireless Remote Control (Optional Accessory)
Concerning the wireless remote control (optional accessory) ● If the unit is installed near fluorescent lights, plasma The unit can be operated by remote control using a wireless remote control (model number: AW-RM50G) monitors or other such products or if the unit is purchased separately. -
Page 40: Parts And Their Functions
Parts and their functions ■ Camera unit Mount bracket for installation surface (supplied accessory) Mount this bracket onto the installation surface, and then attach the camera main unit to the bracket. Drop-prevention wire Pull out the wire from the bottom panel of the camera main unit, and attach it to the hook of the mount bracket. - Page 41 Parts and their functions (continued) LAN connector for IP control [LINK/ACT] RS-422 connector [RS-422] This LAN connector (RJ-45) is connected when exercising This RS-422 connector (RJ-45) is connected when IP control over the unit from an external device. exercising serial control over the unit from an external Use a cable with the following specifications for the device.
- Page 42 When this is set to ON, standard serial communication is communication enabled. Always leave at OFF (used for factory When this is set to OFF, Panasonic’s proprietary serial adjustments) communication is enabled. SW6 Infrared output Disable Enable (3) SW5: Maintenance switch...
-
Page 43: Wireless Remote Controller (Optional Accessory)
Parts and their functions (continued) ■ Wireless remote controller MENU button Each time this is pressed for 2 seconds, operation (optional accessory) switches between displaying the unit’s camera menu and exiting the camera menu. When it is pressed quickly (for less than 2 seconds) while a menu is displayed, the setting change is canceled. - Page 44 Parts and their functions (continued) PRESET/LIMIT button M/FOCUS button This is used to register the settings in the preset This is used when manually adjusting the lens focus. memories or set or release the limiters. The FOCUS buttons ([F] and [N]) are used when When a preset memory call button is pressed while the performing the actual adjustment.
-
Page 45: Setting The Remote Control Ids
Setting the remote control IDs The wireless remote control (optional accessory) is capable of operating up to four units. IDs are used to set which units are selected when the [CAM1], [CAM2], [CAM3] and [CAM4] buttons on the wireless remote control have been pressed. ●... -
Page 46: Network Settings [When Using Windows]
Easy IP Setup Software supplied. You can obtain Easy IP Setup Software (EasyIPSetup.exe) by downloading it from the following website. http://pro-av.panasonic.net/ To establish the settings for a multiple number of units, the settings must be selected for each camera involved. -
Page 47: Installing The Plug-In Viewer Software
Network settings [When using Windows] (continued) ■ Installing the plug-in viewer Input the network items, and click the [Save] button. software To view IP images from the unit on a web browser, the “Network Camera View 4S” plug-in viewer software (ActiveX ®... -
Page 48: User Authentication
Network settings [When using Windows] (continued) ■ User authentication User name and password management ● Use a combination of characters and numbers that is The unit can be configured to allow access from the internet. To prevent infringement of privacy and personality difficult to guess. -
Page 49: Troubleshooting
Troubleshooting ● Operation Reference Symptom Cause and remedial action pages ● Is the AC adaptor securely connected to the AC outlet? ––– ● If the power plug of the AC adaptor connected properly? ––– ● Is the network cable for the PoE+ (IEEE802.3at) compatible power P.35 No power supply device and the unit connected properly? - Page 50 Troubleshooting (continued) Reference Symptom Cause and remedial action pages ● Is the unit connected to the controller properly? P.19 to 24 Refer to the Operating Instructions of the controller. ● The user authorization must be set to OFF when the AW-RP50, <Operations and AW-RP120, and AK-HRP200 remote camera controllers are Settings>...
-
Page 51: Specifications
● VIERA Link is not supported. Finish: [AW-HN40HWPC], [AW-HN40HWE], [AW-HN38HWPC], [AW-HN38HWE] ■ Pearl white INPUT/OUTPUT [AW-HN40HKPC], [AW-HN40HKE], [AW-HN38HKPC], [AW-HN38HKE] Input/Output connector Metallic black LAN: LAN connector for IP control (RJ-45) Controller supported: AW-RP50, AW-RP120, AK-HRP200 Equipped with straight/crossover ●... - Page 52 Specifications (continued) ■ FUNCTIONS AND PERFORMANCE Synchro scan: 59.94 Hz 59.94 Hz to 660.09 Hz [Camera unit] 50 Hz 50.00 Hz to 570.12 Hz Imaging sensors: 1/2.3-type MOS Gamma: Off, Normal (Low, Mid, High), Cinema Lens: [AW-HN40] Motorized 30x zoom, F1.6 to F4.7 White balance: AWB A, AWB B, ATW, 3200K, [f=4.3 mm (11/64 inches) to 129 mm...
- Page 53 Specifications (continued) [Pan-tilt head unit] [Network] Transfer modes: Installation method: Stand-alone (Desktop) or Frame rate* suspended (Hanging) ● To ensure safety, the unit must be System System Image Resolution frequency frequency secured using the mount bracket 59.94 Hz 50 Hz supplied.
- Page 54 Specifications (continued) ■ AC adaptor Input: 100 V to 240 V, 1.2 A, 50/60 Hz Output: DC 12 V, 3.0 A, 36 W indicates safety information. Mass: Approx. 220 g (0.485 lb) Dimensions (W x H x D): 115 mm x 37 mm x 57 mm (4-17/32 inches x 1-59/128 inches x 2-31/128 inches) The symbols on this product (including the accessories) represent the following:...
-
