DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-7ZM
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Jun. 10, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates,
uses,
and
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment
can
radiate
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-7ZM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte GA-7ZM

  • Page 1 Product Name: Mother Board generates, GA-7ZM Model Number: frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    EN 60335 Safety of household and similar electrical appliances Manufacturer/Importer Date : Jun. 10, 2000 (Stamp) (full address) GA-7ZM EN 61000-3-2* Disturbances in supply systems caused EN60555-2 by household appliances and similar electrical equipment “Harmonics” EN61000-3-3* Disturbances in supply systems caused...
  • Page 3 Athlon AGP Motherboard USER'S MANUAL Athlon Socket A Processor Motherboard REV. 2.2 Third Edition R-22-03-000721...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM 7) BIOS Setup 8) Appendix Manual revision information Product item list Product information &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 7ZM Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation Memory Installation Page Index for BIOS Setup Appendix P.21 P.22...
  • Page 8: Revision History

    7ZM Motherboard Revision History Revision Revision Note Initial release of the 7ZM motherboard user’s manual. Second release of the 7ZM motherboard user’s manual. Third release of the 7ZM motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 7ZM motherboard Cable for IDE / floppy device Diskettes or CD (TUCD) for motherboard driver & utility Internal USB Cable (Optional) Cable for SCSI device 7ZM user’s manual...
  • Page 10: Summary Of Features

    7ZM Motherboard Summary Of Features Form Factor 24.3 cm x 22.6 cm Micro ATX size form factor, 4 layers PCB. AMD Athlon (K7) Socket A Processor 256K/64K 2 Supports 500MHz ~ 1GHz and faster Chipset Apollo KT133 ,consisting of: VT8363 Memory/AGP/PCI Controller(PAC) VT82C686A PCI Super-I/O Integrated Peripheral Controller (PSIPC) Clock Generator...
  • Page 11 PS/2 Connector  PS/2 BIOS Licensed AMI BIOS, 2M bit flash ROM Additional Features Support Wake-On-LAN (WOL) Support Internal / External Modem Ring On Support USB KB/MS Wake up from S3 Includes 3 fan power connectors Poly fuse for keyboard over-current protection Support STR (Suspend-To-RAM) function Summary of Features ...
  • Page 12: 7Zm Motherboard Layout

    7ZM Motherboard 7ZM Motherboard Layout PS/2 Socket A CPU VT8363 AGP 1 PCI1 PCI2 PCI3 BAT1 Clock Generator VT82C BIOS 686A USB2 LED1...
  • Page 13: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COM B / LPT Port USB 1 Connector USB 2 Connector PS/2 Keyboard & PS/2 Mouse Connector JP3 (CPU Fan) JP6 (Power Fan) J2 (System Fan)
  • Page 14: Cpu Speed Setup

    7ZM Motherboard CPU Speed Setup The system bus speed is selectable at 100~133MHz. The user can select the system bus speed by DIP switch SW1. If your clock generator ( in Motherboard) is ICS 9248-141. You can follow the below reference. SW1: (ICS 9248-141) O : ON, X : OFF If your clock generator ( in Motherboard) is ICW W230.
  • Page 15: Connectors

    Connectors Connectors Game & Audio Port GAME Port Line Out Line In COM A / COM B / LPT Port LPT PORT COM A COM B...
  • Page 16: Definition

    7ZM Motherboard USB 1 Connector USB 2 Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+ 1 2 3 4 Pin No. Definition 5V-SB USB D2- USB D2+ USB D3- USB D3+ 5V-SB...
  • Page 17: Ps/2 Keyboard & Ps/2 Mouse Connector

    PS/2 Keyboard & PS/2 Mouse Connector PS/2 Keyboard J3: CPU Fan PS/2 PS/2 Mouse Mouse/Keyboard Pin No. Definition VCC(+5V) Clock Pin No. Definition Control +12V SENSE Connectors Data...
  • Page 18: Jp6: Power Fan

    7ZM Motherboard JP6: Power Fan J2: Sysem Fan Pin No. Definition Control +12V Pin No. Definition Control +12V SENSE...
  • Page 19: Atx Power

    ATX Power Floppy Port Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) Red Line FDD1 Connectors...
  • Page 20: Ide1(Primary), Ide2(Secondary) Port

    7ZM Motherboard IDE1(Primary), IDE2(Secondary) Port J8 TEL: The connector is for Modem with internal voice connector Red Line IDE 1 IDE 2 Pin No. Definition Signal-In Signal-Out...
  • Page 21: J7 (Aux_In)

    J7 : AUX_IN J9 : CD Audio Line In Connectors Pin No. Definition AUX-L AUX-R Pin No. Definition CD-L CD-R...
  • Page 22: J13 (Ring Power On)

    7ZM Motherboard J13 : Ring Power On (Internal Modem Card Wake Up) J12: Wake On LAN Pin No. Definition Signal Pin No. Definition +5V SB Signal...
  • Page 23: Jp8 / Led1(Str Led Connector & Dimm Led)

    JP8 / LED1: STR LED Connector & DIMM LED J4: IR Connectors STR LED Connector External. DIMM LED Pin No. Definition VCC (+5V) IR Data Input IR Date Output...
  • Page 24: Panel And Jumper Definition

    7ZM Motherboard Panel and Jumper Definition J2 : 2x11 Pins Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) SPK (Speaker Connector) Pin 1: VCC(+)
  • Page 25: Jp4 :Usb Device Wake Up Selection

    J16 /J17/J18 : AMR (Primary or Secondary) Select (Optional) (AMR Audio Modem Riser) Onboard AC97 AMR (Primary) Onboard AC97 MR (Secondary) (Default) JP4 :USB Device Wake up Selection Panel and Jumper Definition Pin No. Definition 1-2 Close Normal (Default) 2-3 Close USB Device Wake up (If you want to use “USB Dev Wakeup from S3~S5”...
  • Page 26: Jp7:Str Function Enabled

    7ZM Motherboard JP7:STR Function Enabled Pin No. Definition Open Normal (Default) Close STR Enabled JP9 : Write Protect Function Pin No. Definition Write Protect Enable Write Protect Disable (Default)
  • Page 27: Bat1 (Battery)

    BAT1 : Battery Panel and Jumper Definition Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 28: Performance List

    AMD K7 Athlon(Thunderbird) 950MHz processor (64x2) MB SDRAM (Mosel 9928PR V54C365804VCT7) DRAM 256KB included in CPU CACHE SIZE Gigabyte GF2000 DDR DISPLAY Onboard IDE (IBM-DTLA-307045) STORAGE Windows NT O.S. Display Driver at 1024 x 768 x 64K colors x 75Hz.
  • Page 29: Block Diagram

    Block Diagram Socket A 2X/4X System Bus 100MHz VT8363 66MHz 66MHz 3 PCI ATA66 IDE Channels 4 USB Ports VT82C 686A AC97 CODEC IR Floppy PS/2 Block Diagram 100 MHz 3.3V SDRAM 100 / 133MHz 100 / 133MHz 100 / 133MHz 33MHz ICS 9248-141 Or ICW W230...
  • Page 30: Suspend To Ram Installation

    7ZM Motherboard Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 31 Step 2: (If you want to use STR Function, please set jumper JP7 Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ Type : S3 / STR”.
  • Page 32 7ZM Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B. Choose the “Stand by” item and press “OK”...
  • Page 33 Suspend To RAM Installation Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 34 7ZM Motherboard C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 35 A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100 compliant. Jumper JP8 is provided to connect to the STR LED in your system chassis.
  • Page 36: Memory Installation

    7ZM Motherboard Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 37: Page Index For Bios Setup

    Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Supervisor Password / User Password IDE HDD Auto Detection Save &...
  • Page 38: Entering Setup

    7ZM Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 39: Getting Help

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 40 7ZM Motherboard Chipset Features Setup This setup page includes all the items of chipset special features. Power Management Setup This setup page includes all the items of Green function features. PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources. Load BIOS Defaults Bios Defaults indicates the value of the system parameter which the system would be in the safe configuration.
  • Page 41: Standard Cmos Setup

    Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 42 7ZM Motherboard Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 43 Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 44: Bios Features Setup

    7ZM Motherboard BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device Floppy 2nd Boot Device IDE-0 3rd Boot Device CDROM S.M.A.R.T. for Hard Disks Disabled BootUp Num-Lock Floppy Drive Seek Enabled Password Check...
  • Page 45 S.M.A.R.T. for Hard Disks Enable Enable S.M.A.R.T. Hard for Disks. Disable Disable S.M.A.R.T. Hard for Disks. (Default Value) Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks.
  • Page 46: Chipset Features Setup

    7ZM Motherboard Chipset Features Setup AMIBIOS SETUP – CHIPSET FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *********DRAM Timing*** Top Performance Disabled DRAM Frequency 100MHz SDRAM CAS# Latency AGP Mode AGP Comp. Driving Auto Manual AGP Comp. Driving AGP Aperture Size 64MB PCI Delay Transaction...
  • Page 47 BIOS Setup AGP Mode Set AGP Mode to 4X.
  • Page 48 7ZM Motherboard BIOS Flash Protection Enable BIOS Flash Write Protection. Disable Normal. (Default Value) DRAM Drive Strength Auto Set DRAM Drive Strength to Auto. Manual Set DRAM Drive Strength to Manual. If DRAM Drive Strength is Manual, then you can adjust item below. MD Bus Strength High Set MD Bus Strength to High.
  • Page 49 CAS# Drive 8 mA Set CAS# Drive to 8 mA 12 mA Set CAS# Drive to 12 mA RAS# Drive 16 mA Set RAS# Drive to 16 mA 24 mA Set RAS# Drive to 24 mA BIOS Setup...
  • Page 50: Power Management Setup

    7ZM Motherboard Power Management Setup AMIBIOS SETUP – POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type S1/POS USB Dev Wakeup From S3~S5 Disabled Suspend Time Out(Minute) Disabled Display Activity Ignore IRQ3 Monitor IRQ4 Monitor IRQ5...
  • Page 51 Suspend Time Out (Minute.) Disabled Disabled Suspend Time Out Function. (Default Value) Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min. Enabled Suspend Time Out after 20min.
  • Page 52 7ZM Motherboard Resume On Ring / LAN Disabled Disabled Resume On Ring / LAN. Enabled Enabled Resume On Ring / LAN. (Default Value) PME Event Wake Up Disabled Disable PME Event Wake Up. Enabled Enabled PME Event Wake Up. (Default Value) Resume On RTC Alarm You can set “Resume On RTC Alarm”...
  • Page 53 PnP/PCI Configurations AMIBIOS SETUP – PNP / PCI CONFIGURATION ( C ) 1999 American Megatrends, Inc. All Rights Reserved PnP OS Installed Reset Configuration Data VGA Boot from PCI AGP Palette Snoop Disabled Figure 6: PnP/PCI Configuration PnP OS Installed Enable PNP OS Installed function.
  • Page 54: Pnp/Pci Configuration

    7ZM Motherboard Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Load BIOS Defaults (Y/N)? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 55: Load Setup Defaults

    Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load SETUP Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 56: Integrated Peripherals

    7ZM Motherboard Integrated Peripherals AMIBIOS SETUP – INTEGRATED PERIPHERALS ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard Serial Port A Auto OnBoard Serial Port B Auto Serial PortB Mode Normal *Duplex Mode Auto OnBoard Parallel Port Parallel Port Mode Parallel Port DMA Auto Parallel Port IRQ...
  • Page 57 Serial Port B Mode Normal Normal operation. (Default Value) IrDA Onboard I/O chip supports IRDA ASK IR Onboard I/O chip supports ASK IR. Duplex Mode IR Function Duplex Half. Half Duplex Disabled this function (Default Value). IR Function Duplex Full. Full Duplex OnBoard Parallel port Enable On Board LPT port and address to 378.
  • Page 58 7ZM Motherboard AC97 Audio Auto Enabled On Board AC’97 Audio. (Default Value) Disabled Disabled On Board AC’97 Audio. MC97 Modem Auto Enabled On Board MC’97 Modem. (Default Value) Disabled Disabled On Board MC’97 Modem. OnBorard Legacy Audio Enabled Enabled OnBoard Legacy Audio. (Default Value) Disabled Disabled OnBoard Legacy Audio.
  • Page 59 MUP-401 I/O Address 330h-333h Set MUP-401 I/O Address to 330h-333h. (Default Value). 300h-303h Set MUP-401 I/O Address to 300h-303h. 310h-313h Set MUP-401 I/O Address to 310h-313h. 320h-323h Set MUP-401 I/O Address to 320h-323h. Game Port (200h-207h) Disabled Disabled Game Port (200h-207h) Enabled Enabled Game Port (200h-207h) (Default Value).
  • Page 60: Hardware Monitor

    7ZM Motherboard Hardware Monitor AMIBIOS SETUP – HARDWARE MONITOR SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. Disabled CPU Temperature 32 C/89 F System Temperature 32 C/89 F CPU Fan Speed 7123 RPM System Fan Speed 0 RPM Vcore...
  • Page 61 BIOS Setup CPU FAN Speed Detect CPU Fan speed status automatically . System FAN Speed Detect System Fan speed status automatically . Voltage (V) Vcore / Vdd / Vcc3 / +5V / +12V Detect system’s voltage status automatically.
  • Page 62: Set Supervisor / User Password

    7ZM Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.22 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 63: Ide Hdd Auto Detection

    IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave : Not Installed Sec Master : Not Installed...
  • Page 64: Save & Exit Setup

    7ZM Motherboard Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.22 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION SAVE to CMOS and EXIT(Y/N)? Y LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 65: Exit Without Saving

    Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.22 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Quit without saving (Y/N) ? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 66: Appendix

    7ZM Motherboard Appendix Appendix A : VIA Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Utility”...
  • Page 67 7.Click “Next”. 9.Click “Next”. Appendix 8.Click “Next”. 10.Click “Finish” to restart computer. (10)
  • Page 68 7ZM Motherboard Appendix B: VIA Sound Driver A. AC’97 Audio Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Audio 1.Click “AC’97 Audio Driver”...
  • Page 69 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> Once the process is finished, reboot the system Note: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file. Appendix...
  • Page 70 7ZM Motherboard Appendix D: Issues To Beware Of When Installing AMR Please use inverse AMR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Inverse AMR Card (Default) PCI Slot Figure B: Non inverse AMR Card...
  • Page 71 Appendix E: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting Integrated Dual Channel Enhanced...
  • Page 72 7ZM Motherboard Acor. Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...
