TABLE OF CONTENTS
1.
1.1. PREFACE............................................................................................................ 1-1
1.2. KEY FEATURES ................................................................................................. 1-1
1.3. PERFORMANCE LIST........................................................................................ 1-2
1.4. BLOCK DIAGRAM............................................................................................... 1-3
1.6. What is AGP ...................................................................................................... 1-4
2.
2.1. HARDWARE ....................................................................................................... 2-1
2.2. SOFTWARE........................................................................................................ 2-2
2.3. ENVIRONMENT.................................................................................................. 2-2
3.
3.1. UNPACKING ....................................................................................................... 3-1
3.2. MAIN BOARD LAYOUT ...................................................................................... 3-1
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS................................ 3-2
3.4. DRAM INSTALLATION ....................................................................................... 3-6
3.5. CPU SPEED SETUP........................................................................................... 3-6
3.6. CMOS RTC & ISA CFG CMOS SRAM............................................................... 3-7
3.7. SPEAKER CONNECTOR INSTALLATION........................................................ 3-8
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION ...................... 3-8
3.9. POWER LED CONNECTOR INSTALLATION................................................... 3-8
Socket 370 Processor ............................ 1-4
1
Table of Contents
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gigabyte GA-6ZM7A
Summary of Contents for Gigabyte GA-6ZM7A
-
Page 1: Table Of Contents
TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE... 1-1 1.2. KEY FEATURES ... 1-1 1.3. PERFORMANCE LIST... 1-2 1.4. BLOCK DIAGRAM... 1-3 1.5. INTRODUCE THE INTEL Celeron 1.6. What is AGP ... 1-4 SPECIFICATION 2.1. HARDWARE ... 2-1 2.2. SOFTWARE... 2-2 2.3. ENVIRONMENT... 2-2 HARDWARE INSTALLATION 3.1. - Page 2 6ZM7/6ZM7A 3.10. IDE & ATAPI DEVICE INSTALLATION ... 3-8 3.11. PERIPHERAL DEVICE INSTALLATION ... 3-8 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION... 3-8 BIOS CONFIGURATION 4.1. ENTERING SETUP... 4-1 4.2. CONTROL KEYS ... 4-1 4.3. GETTING HELP ... 4-2 4.3.1. Main Menu ... 4-2 4.3.2.
-
Page 3: Introduction
1. INTRODUCTION 1.1. PREFACE Welcome to use the 6ZM7/6ZM7A motherboard. It is a Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
6ZM7/6ZM7A 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel Celeron... -
Page 5: Block Diagram
Hi-End 1.4. BLOCK DIAGRAM 66MHz PGA 370 SLOT Host Bus AGP Bus 82443ZX CHIPSET 14.318 MHz PCI Bus PIIX4 SOLO-1 82371EB L-IN CHIPSET L-OUT Game Port ISA Bus Ultra DMA/33 IDE Ports Introduction 24.4 14.318MHz 3.3V EDO/SDRAM DIMM Sockets DRAM Bus 33MHz 66MHz ICS 9148BF-... -
Page 6: Introduce The Intel Celeron Tm Socket 370 Processor
6ZM7/6ZM7A 1.5. INTRODUCE THE INTEL Celeron Socket 370 Processor Figure 1: INTEL Celeron Socket370 Processor 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. -
Page 7: Specification
2. SPECIFICATION 2.1. HARDWARE Celeron 66MHz Socket 370 on board. Speaker Alarm when detect "CPU FAN Failure" or PROTECTION “ CPU Overheat” . Automatically slow down CPU speed when "CPU Overheat". H/W monitor power status ( 5V, 12V, VGTL,5VSB, CPU voltage & CMOS battery voltage).(Optional) 66 MHz system speed. -
Page 8: Software
6ZM7/6ZM7A Supports 2 16550 COM ports. I/O PORTS Supports 1 EPP/ECP LPT port. Supports 1 1.44/2.88 MB Floppy port. Supports 2 USB ports. Supports PS/2 Mouse & Keyboard. 1x Line in Audio Ports 1x Line out (Optional) 1x Mic in 1x Game Port 2x CD Line in 1x TEL... -
Page 9: Hardware Installation
HARDWARE INSTALLATION 3.1. UNPACKING The main board package should contain the following: The 6ZM7/6ZM7A main board. USER'S MANUAL for main board. Cable set for IDE, Floppy devices. CD for main board Utility. (Bus Master + Sound Driver + LDCM + Utility) The main board contains sensitive electric components, which can be easily damaged by static electricity, so the main board should be left in its original packing until it is installed. -
Page 10: Quick Reference For Jumpers & Connectors
6ZM7/6ZM7A ISA 1 PCI1 PCI3 PCI2 PIIX4E BIOS SYSTEM RING PWR ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. IDE1 For Primary IDE port. IDE2 For Secondary IDE port. PS/2 For PS/2 Mouse & Keyboard port. FLOPPY For Floppy port. - Page 11 IR : INFRARED Connector (IR) -- Function Option Pin No. IR Data Output IR Data Input POWER (+) CPU FAN : CPU cooling FAN Power Connector Pin No. GND. +12V SENSE PWR FAN: Power FAN Connector Pin No. GND. +12V SENSE System FAN: System FAN Connector Pin No.
- Page 12 6ZM7/6ZM7A J13 : CLEAR CMOS Pin No. 1-2 Close Clear CMOS 2-3 Close Normal operation (Default). JP7 : Onboard Sound Function (Optional) Pin No. 1-2 short Onboard Sound Enabled.(Default) 2-3 short Onboard Sound Disabled. Wake on LAN Pin No. +5V SB Signal SB-LINK : For PCI Audio / Sound Card use only--Optional Pin No.
- Page 13 RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System P+P P : Power LED PIN 1 : anode (+) PIN 2 : cathode ( ) PIN 3 : cathode ( ) SPKR: Speaker Connector PIN 1 : VCC (+) PIN 2 : VCC PIN 3 : Data PIN 4 : Data ( )
-
Page 14: Dram Installation
6ZM7/6ZM7A GD: Green LED PIN 1 : LED anode (+) PIN 2 : LED cathode ( ) 3.4. DRAM INSTALLATION The main board can be installed with 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO &... - Page 15 X 7.5 X 8.5 X 9.5 Set System Bus Speed SW2: (O:ON / X:OFF) Please set the CPU host frequency in accordance with your processor’s specifications. We don’t recommend you to set the system bus frequency over the CPU’s specification because these specific bus frequencies are not the standard specifications for CPU, chipset and most of the peripherals.
-
Page 16: Speaker Connector Installation
6ZM7/6ZM7A M Dispose of used batteries according to the manufacturer’ s instructions. 3.7. SPEAKER CONNECTOR INSTALLATION There is a speaker in AT system for sound purpose. The 4 - Pins connector SPKR is used to connect speaker. Pin2-3 short is internal speaker (Default value).
