6ZX7

TABLE OF CONTENTS

1.1. PREFACE ...................................................................................................... 1-1
1.2. KEY FEATHERS............................................................................................ 1-1
1.3. PERFORMANCE LIST .................................................................................. 1-2
1.4. BLOCK DIAGRAM......................................................................................... 1-3
1.6. WHAT IS AGP .............................................................................................. 1-4
2.1. HARDWARE .................................................................................................. 2-1
2.2. SOFTWARE................................................................................................... 2-2
2.3. ENVIRONMENT ............................................................................................ 2-2
3.1. UNPACKING.................................................................................................. 3-1
3.2. MAINBOARD LAYOUT ................................................................................. 3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS.......................... 3-2
3.4. DRAM INSTALLATION ................................................................................. 3-5
3.5. CPU SPEED SETUP ..................................................................................... 3-5
3.6. CMOS RTC & ISA CFG CMOS RAM ........................................................... 3-7
3.7. SPEAKER CONNECTOR INSTALLATION .................................................. 3-7
3.9. POWER LED CONNECTOR INSTALLATION ............................................. 3-7
3.10. IDE & ATAPI DEVICE INSTALLATION ...................................................... 3-7
3.11. PERIPHERAL DEVICE INSTALLATION .................................................... 3-8
Socket 370 Processor..................... 1-4
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-6ZX7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte GA-6ZX7

Summary of Contents for Gigabyte GA-6ZX7

  • Page 1: Table Of Contents

    6ZX7 TABLE OF CONTENTS 1. INTRODUCTION 1.1. PREFACE ... 1-1 1.2. KEY FEATHERS... 1-1 1.3. PERFORMANCE LIST ... 1-2 1.4. BLOCK DIAGRAM... 1-3 1.5. INTRODUCE THE INTEL Celeron 1.6. WHAT IS AGP ... 1-4 2. SPECIFICATION 2.1. HARDWARE ... 2-1 2.2.
  • Page 2 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION... 3-8 4. BIOS CONFIGURATION 4.1. ENTERING SETUP ... 4-1 4.2. CONTROL KEYS... 4-1 4.3. GETTING HELP... 4-2 4.3.1. Main Menu ... 4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu... 4-2 4.4. THE MAIN MENU ... 4-2 4.5.

  • Page 3: Introduction

    6ZX7 1. INTRODUCTION 1.1. PREFACE Welcome to use the 6ZX7motherboard. It is a Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.

  • Page 4: Performance List

    1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (Different Hardware & Software configuration will result in different benchmark testing results.) Intel Celeron...

  • Page 5: Block Diagram

    6ZX7 1.4. BLOCK DIAGRAM PGA 370 Host Bus INTEL 82443ZX AGP Bus CHIPSET 66MHz Ultra DMA/33 IDE Ports PCI Bus PIIX4 82371EB CHIPSET IDE Bus ISA Bus 14.318MHz 3.3V SDRAM DIMM Sockets 66 / 66 / 100 MHz 100 MHz 33MHz 66 / 100 MHz...

  • Page 6: Introduce The Intel Celeron Tm Socket 370 Processor

    Introduction 1.5. INTRODUCE THE INTEL Celeron Socket 370 Processor Figure 1: INTEL Celeron Socket370 Processor 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory.

  • Page 7: Specification

    6ZX7 SPECIFICATION 2.1. HARDWARE Celeron 370 pins 66MHz socket on board. 66/100MHz system speed. SPEED 66 MHz AGP bus speed. (2X mode 133MHz) 33 MHz PCI-Bus speed. 8 MHz AT bus speed. 2 banks 168 pins DIMM module sockets on board. DRAM MEMORY Use 16 / 32 / 64 / 128 / 256 MB DIMM module DRAM.

  • Page 8: Software

    Suspend mode support. GREEN FUNCTION Green switch & Green LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH RAM. BIOS Supports Plug & Play, DMI Function. ATX Form Factor, 4 layers PCB. DIMENSION 2.2.

  • Page 9: Hardware Installation

    6ZX7 HARDWARE INSTALLATION 3.1. UNPACKING The main board package should contain the following: The 6ZX7main board. USER’ S MANUAL for main board. Cable set for IDE, Floppy devices. A CD for mainboard Utility. The main board contains sensitive electric components, which can be easily damaged by static electricity, so the main board should be left in its original packing until it is installed.

  • Page 10: Mainboard Layout

    3.2. MAINBOARD LAYOUT JP10 WAKE ON LAN LINLK PIIX4 PIIX4 6ZX7 RING PWR BIOS SYSTME FAN ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. PS/2 For PS/2 Keyboard and Mouse port. IDE 1 For Primary IDE port. IDE 2 For Secondary IDE port.
  • Page 11 6ZX7 PWR FAN : Power FAN Power Connector Pin No. Function GND. +12V. Signal. System FAN : System FAN Power Connector Pin No. Function GND. +12V. Signal. JP1 : Keyboard Power On Selection Pin No. Function 1-2 close Enable Keyboard power on. 2-3 close Disable Keyboard power on.(Default) WAKE ON LAN : Wake on LAN Connector...
  • Page 12 JP9 : Clear CMOS Pin No. Function 1-2 close Clear CMOS . 2-3 close Normal.(Default) JP10 : CASE OPEN Pin No. Function Signal SB-LINK : For PCI Audio / Sound Card use only Pin No. Function Signal Signal Signal JP4 : 2*11PIN Jumper PW P+P P PW : Soft Power Connector On –...

  • Page 13: Dram Installation

    6ZX7 P+P P : Power LED PIN 1: anode (+) PIN 2: cathode ( ) PIN 3: cathode ( ) HD: IDE Hard Disk Active LED PIN 1: LED anode (+) PIN 2: LED cathode ( ) GN: Green Switch Open: Normal operation Short: Entering Green Mode GD: Green Function Active LED...
  • Page 14 The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than CPU's. SW1: (O:ON / X:OFF) FREQ. RATIO X 3.5 X 4.5 X 5.5 X 6.5 X 7.5 X 8.5 X 9.5 Set System Bus Speed SW2: (O:ON / X:OFF)

  • Page 15: Cmos Rtc & Isa Cfg Cmos Ram

    6ZX7 3.6. CMOS RTC & ISA CFG CMOS RAM There're RTC & CMOS RAM on board; they have a power supply from external battery to keep the DATA inviolate & effective. The RTC is a REAL- TIME CLOCK device, which provides the DATE & TIME to system. The CMOS RAM is used for keeping the information of system configuration, so the system can automatically boot OS every time.

  • Page 16: Peripheral Device Installation

    3.11. PERIPHERAL DEVICE INSTALLATION After the I/O device installation and jumpers setup, the main board can be mounted into the case and fixed by screw. To complete the main board installation, the peripheral device could be installed now. The basic system needs a display interface card.
