Page 1 GN-GSV2401M Web Managed SWITCHING HUB USER GUIDE Gigabyte Ethernet Management Switching Hub with 24 10/100 Mbps Fast Ethernet Ports plus 2 Gigabit Ports Copyright ©2003 Gigabyte Technology Co., Ltd. All Rights Reserved.
Page 3: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limitations are designed to provide reasonable protection against harmful interference in a residential installation.
Page 4: Ce Mark Warning
Gigabyte has an on-going policy of upgrading its products and it may be possible that information in this document is not up-to-date. Please check with your local distributors for the latest information.
Page 5: Table Of Contents
CHAPTER 1 GETTING STARTED ... 1 1.1 U NPACKING NFORMATION 1.2 H OW TO USE THIS UIDE CHAPTER 2 INTRODUCTION TO THE GIGABYTE 2+24 PORTS 10/100/1000MBPS MANAGEMENT SWITCHING HUB ... 4 2.1 G ENERAL ESCRIPTION 2.3 T ...7 RONT ANEL 2.3 T...
Page 6: Chapter 1 Getting Started
Chapter 1 Getting Started...
Page 7: Unpacking Information, Checking Your Items
1.1 Unpacking Information, Checking Your Items Thank you for purchasing this powerful, high-performance Gigabyte 24+2 ports 10/100/1000 Mbps Gigabyte Management Switching Hub. Before getting started, please check the package to make sure all the following items are included. The package should include the following: •...
Page 8: How To Use This Guide
1.2 How to use this Guide The Gigabyte GN-GSV2401M User’ s Guide is divided into the follow chapters: Chapter 2, Introduction contains a general description and key functions of the 24+2 ports 10/100/1000 Mbps Gigabyte Management Switching Hub. Chapter 3, Installation explains the set -up procedures to make the gigabyte switching hub operational.
Page 9: Chapter 2 Introduction To The Gigabyte 2+24 Ports 10/100/1000Mbps Management Switching Hub
Chapter 2 Introduction to the Gigabyte 2+24 Ports 10/100/1000Mbps Management Switching Hub...
Page 10: General Description
2.1 General Description The Gigabyte GN-GSV2401M is a powerful, high-performance, Fast Ethernet switching hub, which acts as traffic controller for 24 local routes and 2 highways to connect your networks to other outside networks. With all 24 ports capable of 10 or 100 Mbps auto-negotiation operation (NWay) and 2 Gigabit Ethernet uplink ports, the switching hub can automatically negotiate with the connected partners for the network speed and duplex mode.
Page 11: Key Features
2.2 Key Features The Gigabyte Switching Hub provides the following key features: Twenty-four non-blocking 10/100 Mbps Auto-negotiation Ethernet ports Two non-blocking 10/100/1000 Mbps Auto-negotiation Ethernet ports Full or Half duplex transfer mode for each port Complies with the Flow Control support for Full-duplex specifications of the IEEE802.3x standard...
Page 12: The Front Panel
PCs and printer servers, at 10/100 Mbps. LEDs n POWER When the Power LED light is on, the GN-GSV2401M is receiving power. When the Power LED light is off, the power cord is improperly connected. Ports 1-24 LEDs Port LED indicators shows the operating status of each port.
Page 13 A collision is detected. Serial Port RS-232 Serial port (console port) for setting up and managing the Switch via a connection to a console terminal or PC using a terminal emulation program. (Please see Chapter 4.4 Management Functions for more details)
Page 14: Panel
2.4 The Rear Panel On/Off switch After plugging in the power source with the power cable, you may turn the switch to “I” for on and “O” for off. Power socket for connecting the power For compatibility with electric service in most areas of the world, the switching hub’...
Page 15: Chapter 3 Installing And Using The Switching Hub
Chapter 3 Installing and Using the Switching Hub...
Page 16: Installation
3.1 Installation The site where you place the GN-GSV2401M may greatly affect its performance. When installing, take the following into your consideration: Install the GN-GSV2401M in a fairly cool and dry place. See Physical Specification for the acceptable temperature and humidity operating ranges.
Page 17: Web-Based Management Function
3.2 Web-Based Management Function The GN-GSV2401M provides Web based configuration.You can manage and monitor the switch through your Internet Explorer browser or Netscape Communicator. Before you manage and monitor the switch, you will need to assign a Static IP Address to the computer that you are using to configure the switch on the same subnet.
Page 18 Web Management Home Page This is a Home Page. The main features include: Port Status, Port Statistics, Administrator, TFTP Update Firmware, Configuration Backup, Reset System and Reboot.
Page 19: Port Status
3.2.1 Port Status From here, you can observe every port status that depended on user setting and the negotiation result. State Display port statuses disable or enable. “unlink” will be treated as “off ”. Link Status Down is “No Link”, UP is “Link”. Auto Negotiation Display the auto negotiation mode: auto / force / nway-force.
Page 20: Port Statistics
Rate Control Display the rate control setting. Ingr： Display the port effective ingress rate of user setting. Egr：Display the port effective egress rate of user setting. Priority Display the port static priority status is High or Low or disable. Port Security Display the port security is enable or disable.
Page 21: Administrator
If the “Enable” is selected, user can get the IP Address information through the console management function. IP Address & Subnet Mask The values are the switch’ s IP Address and Subnet Mask. The default values are 192.168. 223.100 for the IP Address and 255.255.255.0 for the Subnet Mask.
Page 22 Description Display the name of device type. MAC Address The unique hardware address assigned by manufacturer (default) Firmware Version Display the switch’ s firmware version. ASIC Version Display the switch’ s Hardware version. PCBA version Display the board number. Serial number...
Page 23 Module Info This page will show you the information of the module card.
Page 24 This valid value are 1sec, 2 sec, 4 sec and off. Enable Low Queue Delay Bound Limit the low priority packets queuing time in switch. If the low priority packet stays in switch exceed Max Delay Time, it will be sent. The valid range is 1~255 ms. NOTE: Make sure of “Max bridge transit delay bound control”...
Page 25 These options represent the number of high priority packets sent before one low priority packet is sent. For example, 5 High : 2 Low means that the switch sends 5 high priority packets before sending 2 low priority packet.
Page 26 Misc Config Collisions Retry Forever “Disable”： In half duplex, if happen collision will retry 48 times and then drop frame. “Enable”：In half duplex, if happen collision will retry forever. Hash Algorithm Under this option two settings are possible: CRC-Hash or DirectMap. The default value is CRC-Hash.
Page 27 Console Port Info Console is a standard UART interface to communicate with Serial Port. User can use windows HyperTerminal program to link the switch. Connect To->Configure Bits per seconds: 9600 Data bits: 8 Parity: none Stop Bits: 1 Flow control: none...
Page 28 Port Controls The Port Controls allows you to change every port status. State User can disable or enable this port control. Auto Negotiation User can set auto negotiation mode is Auto, Nway (specify the speed/duplex on this port and enable auto-negotiation), Force of per port. Speed User can set 100Mbps or 10Mbps speed on Port1~Port24 and set 1000Mbps, 100Mbps or 10Mbps speed on Port25~Port26 (depend on module card mode).
Page 29 User can disable the port from learning any new MAC addresses, then use the static MAC addresses screen to define a list of MAC addresses that can use the secure port. Enter the desired settings and then click “Apply” button to save the new settings to the switch.
Page 30 IEEE 802.3ad. Aggregator Setting System Priority A value used to identify the active LACP. The switch with the lowest value has the highest priority and is selected as the active LACP. Group ID There are seven trunk groups to provided configure. Choose the "group id"...
Page 31 If LACP enable, you can configure LACP Active/Passive status in each ports on State Activity page. Enter the desired settings and then click “Apply” button to save the new settings to the switch. Aggregator Information When you are setting LACP aggregator, you can see relation information in here.
Page 32 This page is Static Trunking groups. This page is Actor and Partner trunking one group.
Page 33 State Activity Active (select) The port automatically sends LACP protocol packets. Passive (no select) The port does not automatically sends LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. 1. A link having either two active LACP ports or one active port can perform dynamic LACP trunking.
Page 34 Filter Database Forwarding and Filtering The GN-GSV2401M support IP multicast, you can enable IGMP protocol on web management’ s switch setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group ,VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.
Page 35 Static MAC Addresses When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
Page 36 In the MAC Address box, enter the MAC address that wants to filter. If tag-based (802.1Q) VLAN are set up on the switch, in the VLAN ID box, type the VID to associate with the MAC address.
Page 37 VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch. However, all the network devices are still plug into the same switch physically.
Page 38 VLAN ID based on not only default PVID but also other information about the packet, such as the protocol. GN-GSV2401M will support protocol-based VLAN classification by means of both built-in knowledge of layer 2 packet formats used by selected popular protocols, such as Novell IPX and AppleTalk’...
Page 39 User can create Tag-based VLAN, and enable or disable GVRP protocol. There are 256 VLAN groups to provide configure. Enable 802.1Q VLAN, the all ports on the switch belong to default VLAN, VID is 1. The default VLAN can’t be delete.
Page 40 From the Available ports box, select ports to add to the switch and click “Add >>” . If the trunk groups exist, you can see it in here (ex:TRK1,TRK2… ), and you can configure it is the member of the VLAN or not.
Page 41 Ingress Filtering Ingress filtering lets frames belonging to a specific VLAN to be forwarded if the port belongs to that VLAN. GN-GSV2401M have two ingress filtering rule as follows: Ingress Filtering Rule 1：Forward only packets with VID matching this port's configured VID.
Page 42 When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. You can enable Spanning-Tree Protocol on web management’s switch setting advanced item, select enable Spanning-Tree protocol. We are recommended that you enable STP on all switches ensures a single active path on the network.
Page 43 The parameter can be configured on each port , and then click “Apply” button to modify. Path cost Specifies the path cost of the port that switch uses to determine which port are the forwarding ports the lowest number is forwarding ports, the...
Page 44 You can make it more or less likely to become the root port, the rage is 0 -255, default setting is 128 the lowest number has the highest priority. STP Port Status You can view spanning tree status about the switch.
Page 45 Monitored Port All monitor port traffic will be copied to sinffer port. You can select max 25 monitor ports in the switch. User can choose which port want to monitored in only one sniffer mode. If you want to disable the function, you must select monitor port to none.
Page 46 You can define management stations as trap managers and to enter SNMP community strings. User can also define a name, location, and contact person for the switch. Fill in the system options data, then click “Apply” to update the settings.
Page 47 A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a...
Page 48 Security Manager Use this page, user can change web management user name and password. User name Type the new user name. Password Type the new password. Reconfirm password Retype the new password.
Page 49 The UDP port number used by the authentication server to authenticate. Accounting Port The UDP port number used by the authentication server to retrieve accounting information. Shared Key A key shared between this switch and authentication server. NAS Identifier A string used to identify this switch.
Page 50 Perport Configuration In this page, you can select the specific port and configure the authorization state. Each port can select four kinds of authorization state : Fu: force the specific port to be unauthorized. Fa: force the specific port to be authorized. Au: the state of the specific port was determinied by the outcome of the authentication.
Page 51 Misc Configuration In this page, you can change the default configuration for the 802.1x standard. Quiet Period used to define periods of time during which it will not attempt to acquire a supplicant(Default time is 60 seconds). Tx Period used to determine when an EAPOL PDU is to be transmitted (Default value is 30 seconds).
Page 52: Tftp Update Firmware
3.2.4 TFTP Update Firmware The following menu options provide some system control functions to allow a user to update firmware and remote boot switch system: Install TFTP Turbo98 and execution. Copy firmware update version image.bin to TFTP Turbo98 directory. In web management select administrator — TFTP update firmware.
Page 53: Configuration Backup
3.2.5 Configuration Backup TFTP Restore Configuration Use this page to set tftp server address. You can restore EEPROM value from here, but you must put back image in tftp server, switch will download back flash image. TFTP Backup Configuration Use this page to set tftp server ip address. You can save current EEPROM value from here, then go to the TFTP restore configuration page to restore the eeprom value.
Page 54: Reset System
3.2.6 Reset System From here, you can reset Switch to default configuration. 3.2.7 Reboot Reboot the Switch in software reset.
Page 55: Local Console Management
Make sure both the Switch and the computer are powered down. Next, plug one end of the serial cable into the console port of the GN-GSV2401M and the other end of the serial cable into the COM1 port on the back panel of your computer.
Page 56 Please enter a name which you like for this connection, then press “OK”. In the bottom drop down box labeled Connect using:, click the arrow and choose the COM port that the GN-GSV2401M will be connected to. In the example below, COM1 is the port selected. Press the “OK” button.
Page 57 Make sure the terminal or PC you are using to make this connection is configured to match these settings and then press “OK”. You will now be taken to the Set-Up page of the Gigabyte GN-GSV2401M Switching Hub, from where you can configure the GN-GSV2401M.
Page 59 Login Enter the required password in the Log-in screen to access the command console. The password can be changed from Misc Configuration under the Switch Configuration menu. You can press the “Tab” key or “Enter” key to next item. The...
Page 60: Main Menu
3.3.1 Main Menu The main menu allows you access to all the GN-GSV2401M settings. To access each setting press the “Tab” key to select the desired setting and then press “Enter”. To return to the previous selection press “B kSpc” key.
Page 61 TFTP Update Firmware The GN-GSV2401M provides you the TFTP function to download image to update the latest Fireware. Logout The Logout function allows you to logout of the Gigabyte GN-GSV2401M.
Page 62: Switch Static Configuration
Trunk Configuration, VLAN Configuration, Misc Configuration, Administration Configuration, Port Mirroring Configuration, Priority Configuration and MAC Address Configuration. Press “Tab” key to select Switch Static Configuration from the Main Menu and press “Enter”. Port Configuration Enables any port, enables/disables flow control, and sets communication mode to auto-negotiation, full duplex, or half duplex.
Page 63 Administration Configuration The Administrator Configuration gives you configure the default settings of the device. You can Change Username, Change Password, Device information and IP Configuration. Port Mirroring Configuration The Port Mirroring Configuration provides you a method for monitor traffic in switched networks.
Page 64 3.3.2.1 Port Configuration The Port Configuration menu is displayed after selecting it from the Switch Static Configuration menu. Settings for each port can be adjusted in this menu. To access each port use the “Tab” key to select the desired port you wish to customize.
Page 65 100Mbps or 10Mbps speed on port25~port26 (depend on module card mode), and set full-duplex or half-duplex mode. Flow Control: Full User can set full flow control function (pause) is enable or disable. Half User can set half flow control function (backpressure) is enable or disable. NOTE: Pressing <Save>...
Page 66 To access each setting use the “Tab” key to select the desired port you wish to customize. Enter the desired settings and then “<save>” the new settings. The GN-GSV2401M can utilize up to 7 trunk groups. With up to 4 ports in each group, a potential bit rate of 800 Mbps can be achieved.
Page 67 3.3.2.3 VLAN Configuration The VLAN Configuration menu allows users to configure the Gigabyte GN-GSV2401M into their networks. VLANs can be assigned to different ports. Only one untagged VLAN can be assigned to one port alternatively multiple tagged VLANs can be assigned to the same port.
Page 68 VLAN 2 and has the Port VLAN ID number 2 (PVID=2). If the destination lies on another port (found through a normal forwarding table lookup), the switch then looks to see if the other port (Port 10) is a member of VLAN 2 (and can ther efore receive VLAN 2 packets).
Page 69 VLAN Configuration You can assign the PVID for any ports in a domain. PVID (Port VID : 1~255) Type the PVID. NonMember Drop It matches that Ingress Filtering Rule 1 on web. Forward only packets with VID matching this port’ s configured VID. Press “ Space” key to choose forward or drop the frame that VID not matching this port’...
Page 70 Create a VLAN Group Enter a VLAN Name and a VLAN ID, and then you can configure the VLAN tagging which indicates whether or not VLAN tags will be included on frames passing through this port. Edit/Delete a VLAN Group You can modify or delete the settings for an existing VLAN...
Page 71 Port-Based VLAN Port-based VLANs are VLANs where the packet forwarding decision is based on the destination MAC address and its associated port. You must define outgoing ports allowed for each port when using port-based VLANs. Note that VLAN only governs the outgoing traffic, in the other word, it is unidirectional. Therefore, if you wish to allow two subscriber ports to talk to each other, e.g., between conference rooms in a hotel, you must define the egress (outgoing port) for both ports.
Page 72 Create a VLAN Group Up to 26 port-based VLAN groups can be designated for the GN-GSV2401M. Individual ports can exit in two or more VLANs simultaneously, so VLAN groups can overlap or intersect. Edit/Delete a VLAN Group You can modify or delete the settings for an existing VLAN...
Page 73 Group Sorted Mode User can select VLAN groups sorted mode: (1) sorted by name (2) sorted by VID. In the Edit/Delete a VLAN group page will display the result.
Page 74 Broadcast Storm Filtering, Max bridge transmit delay bound, Port Security, Collisions Retry Forever, Hash Algorithm and IFG Compensation. The Misc Configuration Menu is displayed after selecting it from the Switch Static Configuration menu. Settings for each port can be adjusted in this menu.
Page 75 Description of each Misc Configuration function: MAC Age Interval The time the Gigabyte GN-GSV2401M will retain a MAC address that has had no buffer memory activity. The valid range is 300~765 seconds. Default is 300 seconds.
Page 76 Broadcast Storm Filtering To configure broadcast storm control, set the upper threshold for individual ports. The threshold is the percentage of the port's total bandwidth used by broadcast traffic. When broadcast traffic for a port rises above the threshold you set, broadcast storm control becomes active. The valid threshold value are 5%, 10%, 15%, 20%, 25% and NO.
Page 77 1sec, 2sec, 4sec and off. Default is off. Low Queue Delay Bound Limit the low priority packets queuing time in switch. If enable, the low priority packet stays in switch exceed Low Queue Max Delay Time, it will be sent. Press “Space ” key to enable or disable this function.
Page 78 Port Security A port in security mode will be “locked” without permission of address learning. Only the incoming packets with SMAC already existing in the address table can be forwarded normally. User can disable the port from learning any new MAC addresses, then use the static MAC addresses screen to define a list of MAC addresses that can use the secure port.
Page 79 Collisions Retry Forever Enable or Disable the Collisions Retry Forever function. “Disable”： In half duplex, if happen collision will retry 48 times and then drop frame. “Enable”：In half duplex, if happen collision will retry forever.
Page 80 Hash Algorithm Under this option two settings are possible: CRC-Hash or DirectMap. The default value is CRC-Hash.
Page 81 IFG Compensation It means Interframe Gap (96 bits) compensation between two continue frames according to IEEE 802.3ad. “Enable” the IFG compensation will improve the collision case, “Disable” IFG compensation might get more throughput, but can't improve the collision case.
Page 82 The Administration Configuration menu allows the user to Change Username, Change Password, edit the Device Information and IP Configuration. The Administration Configuration is deplayed after selecting it from the Switch Static Configuration menu. Settings for each port can be adjusted in this menu.
Page 83 Change Username Use this page, you can change the username. Enter the user name. (It is a text string with a maximum of 10 alphanmeric characters) Change Password You can change the login password, please enter the old password, a new password an then enter the new password again.
Page 84 Device Information From this page, you can configure the device information. IP Configuration User can configure the IP setting and fill in the new value.
Page 85 The port you want to monitor. All monitor port will be copied to sniffer port. You can select max 25 monitor ports in the switch. User can choose which port want to monitored in only one sniffer mode. “V” is the member, “-” not the member.
Page 86 The Priority Configuration menu allows the user access to Port Static Priority and 802.1p priority. The Priority Configuration Menu is displayed after selecting it from the Switch Static Configuration menu. Settings for each port can be adjusted in this menu.
Page 87 Port Static Priority The static priority based on port, if you set the port is high priority, income frame from this port always high priority frame. 802.1p Priority There are 0~7 priority level can map to high or low queue.
Page 88 Address and Filtering MAC Address. The MAC Address Configuration Menu is displayed after selecting it from the Switch Static Configuration menu. Settings for each port can be adjusted in this menu. Select MAC Address Configuration from the Main Menu and press enter.
Page 89 Static MAC Address When you add a static MAC address, it remains in the switch’ s address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device’ s MAC address when the disconnected or powered-off decive is active on the network again.
Page 90 Filtering MAC Address MAC address filtering allows the switch to drop unwanted traffic. Traffic is filtered based on the destination addresses.
Page 91: Protocol Related Configuration
3.3.3 Protocol Related Configuration The Protocol Related Configuraton menu gives you to configure the Protocol, including STP, SNMP, GVRP, IGMP, LACP and 802.1x. Select one protocol you want to configure from the menu and then press Enter.
Page 92 3.3.3.1 STP The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1D ) for avoiding loops in switched networks. When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. The Spanning-Tree Protocol (STP) menu is displayed after selecting it from the Protocol Related Configuration menu.
Page 93 STP Enable You can enable or disable Spanning-Tree Protocol . We are recommended that you enable STP on all switches ensures a single active path on the network.
Page 94 System Configuration You can view spanning tree information about the Root Bridge on the panel of the left-hand. On the panel of right-hand, user can set new value for STP parameter. Priority A value used to identify the root bridge. The bridge with the lowest value has the highest priority and is selected as the root.
Page 95 Display spanning tree status about the switch for per port is forwarding or blocking. PathCost Specifies the path cost of the port that switch uses to determine which port are the forwarding ports. Priority This is mean port priority, you can make it more or less likely to become the...
Page 96 The SNMP Configuration allows you to define management stations as trap managers and to enter SNMP community strings. User can also define a name, location, and contact person for the switch. The SNMP Configuration menu is displayed after selecting it from the Protocol...
Page 97 “ Enter”. Enter the desired settings and then press “ Enter” to save the new settings. Description of each System Options Configuration function: System Name Type a name to be used for the switch. System Contact Type the name of contact person or organization. System Location...
Page 98 Community Strings Community strings serve as passwords. Community Name The name of current strings. Write Access Enable the rights is read only or read write. “Restricted”：Read only, enables requests accompanied by this string to display MIB-object information. “Unrestricted”：Read write, enables requests accompanied by this string to display MIB-object information and to set MIB objects.
Page 99 A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a...
Page 100 Protocol) allows automatic VLAN configuration between the switch and nodes. If the switch is connected to a device with GVRP enabled, you can send a GVRP request using the VID of a VLAN defined on the switch, the switch will automatically add that device to the existing VLAN.
Page 101 IP manages multicast traffic by using switches, routers, and hosts that support IGMP. Enabling IGMP allows the ports to detect IGMP queries and report packets and manage IP multicast traffic through the switch. IGMP have three fundamental types of message as follows:...
Page 102 3.3.3.5 LACP The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems on a link to allow their Link Aggregation Control instances to reach agreement on the identity of the Link Aggregation Group to which the link belongs, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner.
Page 103 Working Ports Setting From this page, you can set the actually work ports in trunk group. Group Display the trunk group ID. LACP Display the trunk group’ s LACP status. LACP Work Port Num The max number of ports can be aggregated at the same time. If LACP static trunking group, the exceed ports is standby and able to aggregate if work ports fail.
Page 104 State Activity Active The port automatically sends LACP protocol packets. Passive The port does not automatically send LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. If us er set LACP mode in the trunk group, all of the member ports of this trunk group will set "Active"...
Page 105 LACP Status When you setting trunking group, you can see relation information in here. Static trunk group LACP Trunk Group...
Page 106 3.3.3.6 802.1x Protocol The 802.1x Protocol menu gives you access to 802.1x Model, System Configuration, Perport Configuration and Misc Configuration.
Page 107 802.1x Model From this page, the user can enable or disable the 802.1x protocol function. System Configuration 802.1x makes use of the physical access characteristics of IEEE802 LAN infrastructures in order to provide a means of authenticating and authorizing devices attached to a LAN port that has point-to-point connection characteristics, and of preventing access to that port in cases in which the authentication and authorization process fails.
Page 108 Accounting Port The UDP port number used by the authentication server to retrieve accounting information. Shared Key A key shared between this switch and authentication server. NAS Identifier A string used to identify this switch. Perport Configuration In this page, you can select the specific port and configure the authorization state.
Page 109 Misc Configuration In this page, you can change the default configuration for the 802.1x standard : Quiet Period used to define periods of time during which it will not attempt to acquire a supplicant(Default time is 60 seconds). Tx Period used to determine when an EAPOL PDU is to be transmitted(Default value is 30 seconds).
Page 110: Status And Counters
3.3.4 Status and Counters The Status and Counters menu allows the user to view every port the current status, statistics and system information.
Page 111 Port Status This page display every port status Link Status Display the port is link or no link. InRate Display the input rate control (100K/unit) setting value. OutRate Display the output rate control (100K/unit) setting value. Enabled Display the port is enabled or disable depended on user setting. Enable will be display “Yes”, disable will be display “No”.
Page 112 The following information provides a view of the current status of the unit. System Information MAC Address The unique hardware address assigned by manufacturer. Firmware Version Display the switch’ s firmware version. ASIC Version Display the switch’ s Hardware version.
Page 113 PCBA version Display the board number. Serial number Display the serial number assigned by manufacturer. Module 1 Type Display the module 1 type :1000Tx or 100Fx ext. Depend on module card mode. Module 1 information Display the information saved in eeprom of module1. Module 2 Type Display the module 2 type :1000Tx or 100Fx ext.
Page 114: Reboot Switch
“Restart” function will restart the Gigabyte GN-GSV2401M. The Restart function is accessed from the Switch Static Configuration menu. Default The Default option will reset the Gigabyte GN-GSV2401M to the original factory settings. After finished load default setting, switch will reboot automatically. Restart...
Page 115 After a successful reboot the System Diagnosis menu will reappear.
Page 116: Tftp Update Fireware
3.3.6 TFTP Update Fireware The GN-GSV2401M provide user to update firmware or restore EEPROM value or upload current EEPROM value.
Page 117 TFTP Update Firmware This page provides user use TFTP to update firmware. When save successfully and the image file download finished. Please Restart switch. TFTP Restore Configuration This page user can restore EEPROM value, save image file before, form TFTP server. When save successfully and the image file download finished.
Page 118 TFTP Backup Configuration This page user can save current EEPROM value to image file. Then go to the update configure page to restore the EEPROM value. When save successfully and the image file download finished. Please Restart switch.
Page 119: Chapter 4 Product Specifications
Chapter 4 Product Specifications...
Page 120: Product Specifications For 10/100Base -Xport
Standards: IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3z, and IEEE802.3ab Interface: Twenty-four 10/100 Mbps NWay ports Two 1000 Base ports NWay Protocal support: Network speed: 10M, 100M and 1000 Mbps Duplex mode: Full and Half (10M/100Mbps) Full (1000 Mbps) 4.1 Product Specifications for 10/100BASE-X port Functions •...
Page 121: Product Specification For Management Functions
• RS-232 port interface for Console management & System configuration Console Program The 24 port switch has an RS-232 console port for direct console management (RS-232 DB-9), DTE/male connector) When connecting a terminal directly to the switching hub, use either a null modem cable or a null modem adapter on a serial (straightthrough) cable.
Page 122: Appendix A Configuration Of The Pcs
Appendix A Configuration of the The Settings Under Windows2000 Step 1. Click “ Start” in the desktop of the Windows to select “ Settings”, and then click “Control Panel”. Step 2. Double click the “Network and Dial-up Connections”.
Page 123 Step 3. Double click the “LAN CONNECTION”. Step 4. Click “Properties” in the box under LAN CONNECTION Status.
Page 124 Step 5. Double click “Internet Protocol (TCP/IP)”. Step 6. Please assign a static IP address and the same subnet as Access Point to the computer (e.g, IP address is 192.168.223.156 and Subnet Mask is 255.255.255.0), and then click the “OK” button to return to Local Area Connection Properties.
Page 125: Setup Under The Windows 95/98/Me
Setup Under the Windows 95/98/Me Step 1. Click “Start” at the desktop of the Windows, and select “Settings”, and then the “Control Panel”. Step 2. Double click “Network”.
Page 126 Step 3. Under Network, double click the “Configuration”, and choose your appropriate setting “TCP/IP -> and your network card” below. Step 4. Select the “IP Address” tab. Please assign a static IP address and the same subnet as Access Point to the computer (e.g, IP address is 192.168.
Page 127 Step 5. Click the “OK” button again. Windows will ask you to restart your PC. Please click the “Yes” button. If Windows does not ask you to restart , please restart your computer anyway. Note: The Windows may ask you for the original Windows installation disk or additional files.
Page 128: Setup Under Windows Xp
Setup Under Windows XP Step 1. Click the “Start” at the desktop of the Windows, and select the “Control Panel”. Step 2. Double click the “Network Connections”...
Page 129 Step 3. Double click the “Local Area Connection”. Step 4. Click the “Properties” in the box under Local Area Connection Status.
Page 130 Step 5. Double click the “Internet Protocol(TCP/IP)”. Step 6. Please assign a static IP address and the same subnet as Access Point to the computer (e.g, IP address is 192.168.223.156 and Subnet Mask is 255.255.255.0), and then click the “OK” button to return to Local Area Connection Properties.
Page 131: Limited Warranty
Gigabyte may replace or repair the adapter product with either new or reconditioned parts. Repaired or replaced adapter products will be returned to you at the same revision level as received or higher at Gigabyte’ s option. Gigabyte reverses the right to replace discounted adapter products with an equivalent generation adapter product.
