Perle IDS-509C Quick Start Manual

___________________________________________________
This guide covers basic installation and configuration and is intended for first time
setup or product evaluation.
Complete details can be found in the following guides at www.perle.com/downloads.

IDS-509C Hardware Installation Guide

IDS Managed Switches User Guide – Pro Feature Set

IDS Managed Switches CLI Guide – Pro Feature Set
What's in the box?

The IDS switch

Quick Start Guide (this document)

Hardware Overview

Front View
1 – Terminal Block for Power 1, 2
2 – Status LEDs
3 – Console Port – serial
4 – Console Port – USB
5 – DIP switches
6 – Combo Ports - Ethernet/SFP*
*
Combo ports share a common status LED located on the Ethernet connector.
IDS-509C Switches
Quick Start Guide
Back View
7 – Ethernet Ports
8 – SD card slot
9 – Terminal Block – Relay, I/O
10 – Reset / FS (Fast Setup)
11 – Wall Mount Bracket Screw Holes
12 – DIN Rail Clip
