Related Manuals for Sharp XG-P25XU

Summary of Contents for Sharp XG-P25XU

  • Page 1 trusted dependable most name projector lamp sales. http://www.myprojectorlamps.com http://www.myprojectorlamps.ca http://www.myprojectorlamps.eu The following projector manual has not been modified or altered in any way.
  • Page 2 OPERATION MANUAL MODEL XG-P25X LCD PROJECTOR XG-P25X/CD/H(E) 02.3.19, 7:18 PM...
  • Page 3 IMPORTANT For your assistance in reporting the loss or theft of your Color LCD Projector, Model No.: XG - P25X please record the Serial Number located on the bottom of the projector and retain this information. Before recycling the packaging, please be sure Serial No.: that you have checked the contents of the carton thoroughly against the list of “Supplied Accessories”...
  • Page 4 The supplied CD-ROM contains operation instructions in English, German, French, Swedish, Spanish, Italian, Dutch, Portuguese, Chinese (Traditional Chinese and Simplified Chinese), Korean and Arabic. Carefully read through the operation instructions before operating the LCD projector. Die mitgelieferte CD-ROM enthält Bedienungsanleitungen in Englisch, Deutsch, Französisch, Schwedisch, Spanisch, Italienisch, Niederländisch, Portugiesisch, Chinesisch (Tradisionelles Chinesisch und einfaches Chinesisch), Koreanisch und Arabisch.

  • Page 5: Introduction

    2. CONSUMER PRODUCT SAFETY ACT To ensure that you will promptly receive any safety notification of inspection, modification, or recall that SHARP may be required to give under the 1972 Consumer Product Safety Act, PLEASE READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY” CLAUSE.
  • Page 6 BEFORE REMOVING THE SCREW, DISCONNECT POWER CORD. HOT SURFACE INSIDE ALLOW 1 HOUR TO COOL BEFORE REPLACING THE LAMP. REPLACE WITH SAME SHARP LAMP UNIT TYPE BQC-XGP25X//1 ONLY. UV RADIATION : CAN CAUSE EYE DAMAGE. TURN OFF LAMP BEFORE SERVICING.

  • Page 7: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION: Please read all of these instructions before you operate this product and save these instructions for later use. Electrical energy can perform many useful functions. This product has been engineered and manufactured to ensure your personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to defeat the safeguards incorporated into this LCD Projector, observe the following basic rules for its installation, use and servicing.
  • Page 8 IMPORTANT SAFEGUARDS 18. Damage Requiring Service 19. Replacement Parts Unplug this product from the wall outlet and refer servicing When replacement parts are required, be sure the service to qualified service personnel under the following technician has used replacement parts specified by the conditions: manufacturer or have the same characteristics as the a.
  • Page 9 Caution Concerning the Lamp Unit SEE OPERATION MANUAL. Potential hazard of glass particles if lamp ruptures. In case of lamp rupture, contact your nearest Sharp Authorized LCD Projector Dealer or Service Center for a replacement. See “Replacing the Lamp” on pages...
  • Page 10 IMPORTANT SAFEGUARDS Temperature Monitor Function If the projector starts to overheat due to setup problems or a dirty air filter, “TEMP.” and “ ” will blink in the lower- left corner of the picture. If the temperature continues to rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the projector will blink, and after a 90-second cooling-off period the power will shut off.

  • Page 11: Outstanding Features

    Outstanding Features 1. High-end LCD Projector with Ultra High Brightness • AC 270 W Lamp Use AC 270 W lamp for excellent color uniformity and ultra high brightness. 2. Computer Compatibility • Compatible with resolutions including VGA-SVGA (expanded), XGA (true resolution) and SXGA-UXGA (compressed) as well as DTV formats (480 , 480P, , 580P, 720P, 1035...
  • Page 12 • High Speed Auto Sync Technology 10. Useful Features • Picture-in-Picture, Digital Enlargement, Freeze • Customizable Startup Screen & Background Screen 11. Application Software • “Sharp Advanced Presentation Software Professional Edition” (Network and Remote Control) XG-P25X/CD (E)-a 02.3.19, 7:16 PM...

  • Page 13: Table Of Contents

    Contents Important Information Basic Operation Introduction .......... Using the GUI (Graphical User IMPORTANT SAFEGUARDS ....Interface) Menu Screen ....Outstanding Features ......Basic Operations ........Contents ..........Menu Bars ..........How to Access the PDF Operation Adjusting the Picture ......Manuals ..........
  • Page 14 Features ........... Maintenance & Troubleshooting Lamp/Maintenance Indicators ..... Replacing the Lamp ......Replacing the Air Filter ......Troubleshooting ........For SHARP Assistance ......Appendix Connecting Pin Assignments ..... (RS-232C) Specifications and Command Settings......Wired Remote Control Terminal Specifications ........Compatibility Chart ......

  • Page 15: How To Access The Pdf Operation Manuals

    How to Access the PDF Operation Manuals PDF operation manuals in several languages are included in the Projector Manual and Technical Reference CD- ROM. To utilize these manuals, you need to install Adobe Acrobat Reader on your PC (Windows or Macintosh). If you have not installed Acrobat Reader yet, you can download it from the Internet (http://www.adobe.com) or install it from the CD-ROM.

  • Page 16: Part Names

    Part Names Numbers next to the part names refer to the main pages in this manual where the topic is explained. Projector Front View TEMPERATURE WARNING LAMP REPLACEMENT indicator indicator POWER indicator POWER buttons (ON/OFF) VOLUME buttons ( / ) MUTE button MENU button LENS button...
  • Page 17 Part Names Numbers next to the part names refer to the main pages in this manual where the topic is explained. Remote Control Front View POWER buttons (ON/OFF) LENS button MENU button ENTER button Adjustment (∂/ƒ/ß/©) buttons UNDO button ENLARGE buttons FREEZE button AUTO SYNC button GAMMA button...

  • Page 18: Using The Remote Control

    Using the Remote Control Inserting the batteries Press the tab and lift open the Insert two R-6 batteries (“AA” Insert the tabs on the end of battery cover in the direction of size, UM/SUM-3, HP-7 or the battery cover into their similar), making sure the slots and press the cover into the arrow.

  • Page 19: Accessories

    RS-232C serial control cable (32 10 (10.0 m)) AN-C10RS DVI to 15-pin D-sub adaptor (7.9 (20 cm)) AN-A1DV • All cables may not be available in all regions. Please check with your nearest Sharp Authorized LCD Projector Dealer or Service Center. E-15 XG-P25X/CD (E)-a 02.3.19, 7:17 PM...

  • Page 20: Connections

    Connections Power Supply Connecting the Power Cord Plug the supplied power cord into the AC socket on the rear of the projector. Power cord Make the necessary connections before proceeding. Connect the power cord to a wall outlet. The POWER indicator lights up red and the projector enters standby mode. POWER indicator •...

  • Page 21: Projecting Computer Images

    When connecting this projector to a computer, select “RGB” for “Signal Type” on the GUI menu. (See page • A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorized LCD Projector Dealer or Service Center.
  • Page 22 Projecting Computer Images • This projector uses a 5 BNC computer input to prevent deterioration of image quality. • Connect the R (P ), G/G sync (Y), B (P ), HD/C sync and VD cables (sold separately) to the correct input terminals on the projector and an RGB switcher (sold separately) connected to the computer, or connect a 5 BNC cable (sold separately) directly from the input terminals on the projector to the computer.
  • Page 23 • The wireless mouse or RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for details on setting up/installing the correct mouse driver. • A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorized LCD Projector Dealer or Service Center.

  • Page 24: Watching Video Images

    Watching Video Images Connecting to a VCR, laser disc player and other audiovisual equipment using the standard video Input S-video cable (sold separately) Example To S-video output terminal Video cable (sold separately) To video output terminal Laser disc player Audio cable (sold separately) To audio output terminals Connect the yellow RCA connectors to the corresponding yellow VIDEO INPUT 4 terminal on the projector and the Video output terminal on the video source.

  • Page 25: Watching Component Video Images

    Watching Component Video Images Connecting to a DVD video player, DTV* decoder and other component video equipment using the 5 BNC Input To audio output terminals Example Audio cable (ø3.5 mm stereo minijack to RCA DTV decoder cable, commercially available) Component cable (sold separately) DVD video player To analog component output terminals...

  • Page 26: Power On/Off

    Power ON/OFF Press POWER ON. Projector Remote control • The blinking green LAMP REPLACEMENT indicator shows that the lamp is warming up. Wait until the indicator stops blinking before operating the projector. POWER • If the power is turned off and then immediately turned on again, it may take a short while before the lamp turns on.

  • Page 27: Setting Up The Screen

    Setting Up the Screen Using the Adjustment Feet DOWN Press foot releases. Adjust height of projector Rotate feet to make minor changes. and remove hands from foot releases. • The projector is adjustable up to approximately 10° from the standard position. •...

  • Page 28: Lens Button

    LENS Button Digital Image Adjustments Projector Remote control This function can be used to adjust the focus, zoom, keystone, v-size and digital shift settings. LENS Press LENS to select mode. Each time LENS is pressed, the screen changes as shown on the left. ∂/ƒ/ß/©...

  • Page 29: Adjusting The Projection Distance

    • A polarizing screen cannot be used with this projector. Two optional lenses from Sharp are also available for specialized application. Please see your local Sharp Authorized LCD Projector Dealer to details on all the lenses. (Refer to the lens operation manual when attaching a lens.) Also, be sure to have service personnel install the AN-P9MX and AN-P48EZ optional lenses.
  • Page 30 Adjusting the Projection Distance Upper and Lower Lens Shift Position • This projector is equipped with a lens shift function that lets you adjust the projection height. • Adjust to match the setup configuration. Screen size: 100 inches (254 cm) STRETCH Mode: 16:9 Standard Lens as an example Screen...
  • Page 31 Adjusting the Projection Distance Standard Lens Throw distance ratio 1:1.8 to 2.4 NORMAL Mode (4:3) Screen size (4:3) (X) Projection distance (L) Lens center to the lower edge of the screen (H) Diag. Width Height Maximum (l Minimum (l Upper lens shift position (h Lower lens shift position (h 48 2 (14.7 m)
  • Page 32 Adjusting the Projection Distance AN-P9MX Throw distance ratio 1:0.9 NORMAL Mode (4:3) Screen size (4:3) (X) Projection distance (L) Lens center to the lower edge of the screen (H) Diag. Width Height 18 1 (5.5 m) (228.6 cm) 12 0 (3.7 m) (152.4 cm) (2.7 m)
  • Page 33 Adjusting the Projection Distance AN-P48EZ Throw distance ratio 1:4.6 to 6.1 NORMAL Mode (4:3) The formula for screen size and projection distance x: Screen size (diag.) (X) (inches) (Max.) = (0.1214x 0.1272) 3.28 (Min.) = (0.0927x 0.1233) 3.28 l: Projection distance (L) (feet) (Upper) = 0.3x h: Lens center to the lower edge of the screen (H) (inches) (Lower) = 0...

  • Page 34: Image Projection

    Ceiling-mount Projection • It is recommended that you use the optional Sharp ceiling-mount bracket for this installation. • Before mounting the projector, contact your nearest...

  • Page 35: Using The Operation Buttons

    Using the Operation Buttons Selecting the Input Signal Source Projector Remote control Press INPUT 1.2.3 or INPUT 4.5 on the projector or INPUT (1, 2, 3, 4 or 5) on the remote control to change the mode. • When no signal is received, “NO SIGNAL” will be displayed. INPUT When a signal that the projector is not preset to receive is received, “NOT REG.”...

  • Page 36: Superimposing A Black Screen

    Superimposing a Black Screen Projector Remote control This function can be used to superimpose a black screen over the projected image. Blacking out the Projected Image Press BLACK SCREEN. The screen turns black and BLACK “BLACK SCREEN” is displayed on the screen. To return SCREEN to the original projected image, press BLACK SCREEN again.

  • Page 37: Magnifying A Specific Portion Of An Image

    Magnifying a Specific Portion of an Image Remote control This function allows you to magnify a specific portion of an image. This is useful when you want to display a detailed portion of the image. Press ENLARGE ( ) to zoom in. (Press ENLARGE ) to zoom out.) ∂/ƒ/ß/©...

  • Page 38: Display And Setting The Break Timer

    Displaying and Setting the Break Timer Remote control This function can be used to show the remaining time for break during meeting. Press BREAK TIMER. The timer starts to count down from 5 minutes. • You can set the Break Timer 1 to 60 minutes with ∂/ƒ. The timer starts to count down as soon as ∂/ƒ...

  • Page 39: Adjusting The Picture Aspect Ratio

    Adjusting the Picture Aspect Ratio Projector Remote control This function allows you to modify or customize the picture display mode to enhance the input image. Depending on the input signal, you can choose UNDO NORMAL, FULL, DOT BY DOT, BORDER, STRETCH or SMART STRETCH image.
  • Page 40 Adjusting the Picture Aspect Ratio VIDEO NORMAL BORDER STRETCH SMART STRETCH 4:3 aspect ratio , 480P, 580 , 580P, 1024 576* 1024 576* NTSC, PAL, SECAM Letter box, squeeze 1024 576* 720P, 1035 , 1080 16:9 aspect ratio – – –...

  • Page 41: Gamma Correction Function

    CINEMA Gives greater depth to darker portions of image for a more exciting theater experience. Allows you to adjust gamma value using Sharp CUSTOM Advanced Presentation Software. Press GAMMA. Each time GAMMA is pressed, the gamma level toggles as shown on the left.

  • Page 42: Using The Gui (Graphical User Interface) Menu Screen

    Using the GUI (Graphical User Interface) Menu Screen Basic Operations This projector has two sets of menu screens that allow you to adjust the image and various projector settings. These menu screens can be operated from the projector or the remote control with the following procedure.

  • Page 43: Menu Bars

    Sharp frequency figures displayed above are for example purposes only. Custom • “Color”, “Tint”, and “Sharp” appear only when None Component input is selected in INPUT 1 or 2 mode. For Economy Mode INPUT 3 (DVI), in “Picture” menu, only “CLR Temp” is Power Save [LOW POWER/STANDARD] active and the other menus are displayed in gray.
  • Page 44 Sub menu Sub menu Picture Contrast Options (2) Lamp Timer Bright PRJ Mode Front Color Ceiling Front Tint Rear Sharp Ceiling Rear Normal Stack Setting Blue Master CLR Temp Slave Reset Keylock Level Normal Progressive Mode 2D Progressive Level A...

  • Page 45: Adjusting The Picture

    • The adjustments can be stored separately in the INPUT 1 to 5 modes. • Depending on the type of signal received, “Sharp” may not be adjustable for COMPONENT input in INPUT 1 or 2 mode. Adjusting the Color Temperature This function can be used to adjust the color temperature to suit the type of image input to the projector (video, computer image, TV broadcast, etc.).
  • Page 46 Adjusting the Picture Progressive Mode This function allows you to select the progressive display of a video signal. The progressive display projects a smoother video image. See page for the procedure details. Selects the progressive conversion mode. 2D Progressive This function is useful to display fast-moving images such as sports and action films.

  • Page 47: Adjusting The Computer Images (Rgb Menu Only)

    Adjusting the Computer Images (RGB menu only) When displaying computer patterns which are very detailed (tiling, vertical stripes, etc.), interference may occur between the LCD pixels, causing flickering, vertical stripes, or contrast irregularities in portions of the screen. Should this occur, adjust “Clock”, “Phase”, “H-Pos” and “V-Pos” for the optimum computer image.
  • Page 48 Adjusting the Computer Images (RGB menu only) Special Mode Adjustment Ordinarily, the type of input signal is detected and the correct resolution mode is automatically selected. However, for some signals, the optimal resolution mode in “Special Modes” on the “Fine Sync” menu screen may need to be selected to match the computer display mode.
  • Page 49 Adjusting the Computer Images (RGB menu only) Auto Sync Adjustment • Used to automatically adjust a computer image. • Auto Sync adjustment can be made manually by pressing AUTO SYNC, or automatically by setting “Auto Sync” to “Normal” or “High Speed” in the projector’s GUI menu. See page for the procedure details.

  • Page 50: Adjusting The Sound

    Adjusting the Sound This projector’s audio is factory preset to standard settings. However, you can adjust it to suit your own preferences by adjusting the following audio settings. See page for the procedure details. ß button © button Selected item Balance Increased audio from the left speaker Increased audio from the right speaker...

  • Page 51: Displaying Dual Pictures (Rgb Menu Only)

    Displaying Dual Pictures (RGB menu only) Picture in Picture function allows you to display two pictures on the same screen. You can display the image input from INPUT 4 or 5 as an inset picture overlapping the main picture input from INPUT 1, 2 or 3.

  • Page 52: Turning On/Off The On-Screen Display

    Turning On/Off the On-screen Display This function allows you to turn on or off the on-screen messages that appear during input select. See page for the procedure details. Selected item Description Normal All On-screen Display are displayed. Level A Input/Custom/Freeze/Enlarge/Auto sync/Volume/Mute/ Black screen functions are not displayed.

  • Page 53: Selecting A Background Image

    A custom image (e.g. your company logo) can be uploaded to the projector via an RS-232C cable. See page in this operation manual, and also the supplied Sharp Advanced Presentation Software operation manual on the CD-ROM for detailed instructions. See page for the procedure details.

  • Page 54: Selecting The Economy Mode

    Monitor Out/RS-232C on CAUTION • Set “MNTR Out/RS232C” to “ ” when using the Sharp Advanced Presentation Software (supplied). Automatic Power Shutoff Function When no input signal is detected for more than 15 minutes, the projector will automatically shut off. The on-screen message, “Power OFF in 5 min.”...

  • Page 55: Confirming The Lamp Usage Time

    Confirming the Lamp Usage Time This function allows you to check the accumulated lamp usage time. See page for the procedure details. • It is recommended that the lamp be replaced after approximately 1,400 cumulative hours of use. See pages lamp replacement.

  • Page 56: Setting The Stacking Mode

    Setting the Stacking Mode You can double the brightness of an image by stacking two projectors and projecting same picture simultaneously. To control two projectors, assign one as the master and one as the slave. The slave projector will duplicate any operational settings made to the master projector. See page for the procedure details.

  • Page 57: Deselecting Inputs

    Deselecting Inputs This function allows you to deselect unwanted signal input. See page for the procedure details. • When stack projecting, multi-screen projecting and so on, this function can be used to cancel the RS-232C control. • Up to two input signals can be blocked for both Input 1, 2, 3 or Input 4, 5. •...

  • Page 58: Controling Multiple Projectors With Id Numbers

    Controling Multiple Projectors with ID Numbers This projector can form a network of up to 250 projectors. To identify separately and control specified projector, you need to set ID No.. The ID No. is factory preset to “001”. See page for the procedure details.

  • Page 59: Protecting Important Settings With A Password

    Protecting Important Settings with a Password A password can be set by the user and used with the keylock level to prevent adjustments to certain settings on the GUI. See page for the procedure details. • When password is set, you need to enter the password to use “PRJ Mode”, “Stack Setting”, “Keylock Level”, “Set Inputs”, “RS-232C”...

  • Page 60: Selecting The On-Screen Display Language

    Selecting the On-screen Display Language English is the preset language for the On-screen Display; however, this can be changed to German, Spanish, Dutch, French, Italian, Swedish, Portuguese, Chinese, Korean or Japanese. See page the procedure details. Displaying the Adjustment Settings This function can be used to display all the adjusted settings on the screen simultaneously.

  • Page 61: Using Extended Functionality Features

    RS-232C connection. Output terminals are provided (RS-232C on the projector) enabling a daisy chain configuration and eliminating the need for a distributor. This projector is also equipped with a function to send status information (lamp usage time, etc.) to a Sharp Service Center or outside contractor for quick and efficient customer service.
  • Page 62 Video Source 2 This projector can be used in a network of projectors managed from a single PC with the accompanied Sharp Advanced Presentation Software Professional Edition. Projectors in conference rooms on the first and third floors of a building, for example, can be used for video presentations, while projectors on the second floor can be used for PC-assisted presentations.
  • Page 63 Using Extended Functionality Features Simultaneous multiple projector control for stacking and videowall projection Stack Projection Stack Setting Set Inputs Master Master INPUT1 INPUT1 OUTPUT INPUT2 INPUT2 INPUT3 INPUT4 INPUT4 INPUT5 RS-232C IN RS-232C OUT INPUT5 Distributor Stack Setting Set Inputs Slave Slave INPUT1...
  • Page 64 • For more information on this feature, see the operation manuals accompanying the Sharp Advanced Presentation Software Professional Edition. • When UXGA signal is displayed, the videowall can not be set by Sharp Advanced Presentation Software Professional Edition. E-60 XG-P25X/CD (E)-f...

  • Page 65: Lamp/Maintenance Indicators

    • Clogged air filter. • Clean the filter. (See page • Cooling fan breakdown. • Take the projector to your nearest Sharp • Internal circuit failure. Authorized LCD Projector Dealer or Service Center for repair. • Burnt-out lamp.

  • Page 66: Replacing The Lamp

    BQC-XGP25X//1 from your nearest Sharp Authorized LCD Projector Dealer or Service Center. Then carefully change the lamp by following the instructions below. If you wish, you may have the lamp replaced at your nearest Sharp Authorized LCD Projector Dealer or Service Center.
  • Page 67 Replacing the Lamp Replace the air filter. Replace the filter Remove the lamp cage cover. cover. Place the air filter underneath the Insert the tab on the end of the Turn over the projector and tabs on the filter frame. filter cover into the filter cover loosen the user service screw opening and press the filter...

  • Page 68: Replacing The Air Filter

    • The air filters should be cleaned every 100 hours of use. Clean the filters more often when the projector is used in a dusty or smoky location. • Have your nearest Sharp Authorized LCD Projector Dealer or Service Center exchange the filter (PFILD0080CEZZ) when it is no longer possible to clean it.

  • Page 69: Troubleshooting

    Troubleshooting Problem Check Power cannot be turned on or • Keylock level is set to “Level A” or “Level B”, preventing operation of some or all off using the POWER buttons buttons. (See page (ON/OFF) on the projector. Cannot be operated by •...

  • Page 70: For Sharp Assistance

    For SHARP Assistance If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting” section on page . If this operation manual does not answer your question, please contact the SHARP Service Department listed below. U.S.A.

  • Page 71: Connecting Pin Assignments

    Connecting Pin Assignments INPUT 1 RGB and OUTPUT (INPUT 1, 2) Signal Ports: 15-pin Mini D-sub female connector RGB Input Analog 1. Video input (red) 8. Earth (blue) 2. Video input 9. Not connected (green/sync on green) 10. GND 11. GND 3.

  • Page 72: (Rs-232C) Specifications And Command Settings

    (RS-232C) Specifications and Command Settings PC control A computer can be used to control the projector by connecting an RS-232C cable (cross type, sold separately) to the projector. (See page for connection.) Communication conditions Set the serial port settings of the computer to match that of the table. Signal format: Conforms to RS-232C standard.
  • Page 73 INPUT 4 (VIDEO 1) TINT ( 30 – OK OR ERR RGB GAMMA : STANDARD OK OR ERR INPUT 4 (VIDEO 1) SHARP ( 30 – OK OR ERR RGB GAMMA : PRESENTATION OK OR ERR INPUT 4 (VIDEO 1) CLR TEMP ( 3 –...
  • Page 74 LANGUAGE SELECTION : SVENSKA OK OR ERR BACKGROUND SELECTION : NONE OK OR ERR LANGUAGE SELECTION : OK OR ERR STARTUP IMAGE SELECTION : SHARP OK OR ERR LANGUAGE SELECTION : PORTUGUÊS OK OR ERR STARTUP IMAGE SELECTION : CUSTOM OK OR ERR...

  • Page 75: Wired Remote Control Terminal Specifications

    • System codes C1 to C5 are fixed at “10110”. are complex and are, therefore, not listed here. • Codes C14 and C15 are reverse confirmation bits, with “10” indicating “Front” and “01” indicating “Rear”. Sharp remote control signal format Transmission format: 15-bit format 67.5 ms 67.5 ms Wave form of output signal: Output using Pulse Position Modulation 26.4 µs...

  • Page 76: Compatibility Chart

    Compatibility Chart Computer Horizontal Frequency: 15–126 kHz / Vertical Frequency: 43–200 Hz / Pixel Clock: 12–230 MHz Compatible with sync on green and composite sync signals UXGA and SXGA compatible in advanced intelligent compression or intelligent compression AICS (Advanced Intelligent Compression and Expansion System) resizing technology Horizontal Vertical Horizontal...

  • Page 77: Dimensions

    Dimensions Rear View Side View Side View Top View (155) (26.5) (319) (3.5) (23) Front View (34) (248) (88.5) 2 (74.5) Bottom View Units: inches (mm) (20.27) E-73 XG-P25X/CD (E)-h 02.3.19, 7:14 PM...

  • Page 78: Specifications

    UDSKAA005WJZZ), LCD projector operation manual (TINS-A133WJZZ), Quick reference guides, Sharp Advanced Presentation Software installation guide (TINS-A139WJZZ), ID number seal (TLABZ0781CEZZ) This SHARP projector uses LCD (Liquid Crystal Display) panels. These This unit has some inactive TFTs within acceptable tolerances which very sophisticated panels contain 786,432 pixels ( RGB) TFTs (Thin may result in illuminated or inactive dots on the picture screen.

  • Page 79: Glossary

    Glossary Aspect ratio Width and height ratio of an image. The normal aspect ratio of a computer and video image is 4:3. There are also wide images with an aspect ratio of 16:9 and 21:9. Auto Sync Optimizes projected computer images by automatically adjusting certain characteristics. Background Initial setting image projected when no signal is being input.

  • Page 80: Index

    Index AC socket ................ Network Function ............Adjusting the Picture ............Adjustment Feet .............. On-screen display ............Air filter ................On-screen display Language ......... Aspect ratio ..............OUTPUT port ..............Audio ................Audio cable ..............Password ................ AUDIO INPUT terminal ........... PDF .................
  • Page 81 SHARP CORPORATION XG-P25X/CD (E)-h 02.3.19, 7:15 PM...
